Lighting: Removal & Installation Scion tC I

REPLACEMENT

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. Installation is in the reverse order of removal.

Scheme 62

Scheme 63

1. REMOVE OUTER REAR VIEW MIRROR ASSY LH (See «OUTER REAR VIEW MIRROR ASSY LH»(ref-224791-S39200432592006031100000) )
2. REMOVE SIDE TURN SIGNAL LAMP LENS LH Remove the 4 claws and the cover. Remove the 2 screws. Disconnect the connector and remove the side turn signal lamp lens LH.

HINT

Installation is in the reverse order of removal.

Scheme 64

1. REMOVE STEERING COLUMN COVER (See «OVERHAUL»(ref-224783-S00337131492006031100000) )
2. REMOVE HEADLAMP DIMMER SWITCH ASSY Disconnect the connector. Disengage the claw and remove the headlamp dimmer switch assy. NOTE: Do not push the claw strongly, otherwise it will be damaged.
