Lighting: Other Scion tC I

PRECAUTION

Note. When disconnecting the battery terminal, initialize the following system after the terminal is reconnected.

SYSTEM DESCRIPTION

1. PRECAUTION OF HEADLIGHT BULB REPLACEMENT If even a thin film of oil is left on the surface of the halogen lamp, its service life will be shortened because the lamp will burn at a higher temperature. Handle any halogen lamp with great care. Dropping, hitting or damaging the bulb, in any way, may result in it exploding and shattering because the internal pressure is high. Always prepare a new bulb for immediate replacement. While replacing the bulb, the lens may attract dust and moisture if removed from the vehicle for too long. Always use a bulb of the same wattage for replacement. Firmly reinstall the socket after bulb replacement. The lens may become cloudy or the light cavity may be filled with water through the gaps around the socket.

REPAIR

HINT

1. See «COMPONENTS»(ref-224788-S06821684332006031100000) .
2. Use the same procedures for the RH side and LH side.
3. The procedures listed below are for the LH side.
4. Installation is in the reverse order of removal.

Scheme 87

Scheme 88

1. REMOVE FRONT FENDER LINER LH (See «REPLACEMENT»(ref-224797-S33489282952006031100000) )
2. REMOVE FRONT FENDER LINER RH (See «REPLACEMENT»(ref-224797-S33489282952006031100000) )
3. REMOVE FRONT BUMPER COVER (See «REPLACEMENT»(ref-224797-S33489282952006031100000) )
4. REMOVE LH HEADLAMP ASSY (See «OVERHAUL»(ref-224788-S39656017302006031100000) )
5. INSTALL HEADLAMP PROTECTOR RETAINER UPPER LH HINT: If the installation area of the LH headlamp assy is damaged, use the supply bracket for low-cost repair. Ensure that the LH headlamp assy is not damaged. Cut off the part shaded in (Scheme 87) and sand smooth with sandpaper. NOTE: After cutting off the part, place the headlamp protector retainer upper LH against the bosses and gradually file away until installation is possible. Install the headlamp protector retainer upper LH with the 2 screws.
6. VEHICLE PREPARATION FOR HEADLAMP AIM ADJUSTMENT (See «ADJUSTMENT»(ref-224788-S35200508082006031100000) )
7. PREPARATION FOR HEADLAMP AIMING (Using a tester) (See «ADJUSTMENT»(ref-224788-S35200508082006031100000) )
8. PREPARATION FOR HEADLAMP AIMING (Using a screen) (See «ADJUSTMENT»(ref-224788-S35200508082006031100000) )
9. HEADLAMP AIMING INSPECTION (See «ADJUSTMENT»(ref-224788-S35200508082006031100000) )
10. HEADLAMP AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-224788-S35200508082006031100000) )
