Windows / Glass (Service Information): Overview Scion FR-S I

Scheme 19

Scheme 20

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL [07/2013 - ] - Step 1»(/scion/fr-s/i-2012-2016/remont/body-electrical/#charging-system-service-information)
2. REMOVE DOOR ARMREST COVER LH. Refer to «DISASSEMBLY [07/2013 - 12/2013] - Step 2»(ref-612393-S31114778102014042900000)
3. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH. Refer to «DISASSEMBLY [07/2013 - 12/2013] - Step 3»(ref-612393-S31114778102014042900000)
4. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL. Refer to «DISASSEMBLY [07/2013 - 12/2013] - Step 5»(ref-612393-S31114778102014042900000)
5. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY Using a screwdriver with its tip wrapped in protective tape, disengage the 4 claws and remove the power window regulator master switch assembly. TEXT IN ILLUSTRATION *1 Protective Tape

Scheme 21

1. INSTALL POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY Engage the 4 claws and install the power window regulator master switch assembly.
2. INSTALL POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL. Refer to «REASSEMBLY [07/2013 - 12/2013] - Step 31»(ref-612393-S03451195772014042900000)
3. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH. Refer to «REASSEMBLY [07/2013 - 12/2013] - Step 34»(ref-612393-S03451195772014042900000)
4. INSTALL DOOR ARMREST COVER LH. Refer to «REASSEMBLY [07/2013 - 12/2013] - Step 35»(ref-612393-S03451195772014042900000)
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf)
6. INITIALIZE POWER WINDOW CONTROL SYSTEM Refer to «INITIALIZATION [07/2013 - ]»(ref-612250-S35237050992014042900000)
7. INSPECT POWER WINDOW OPERATION Refer to «INSPECTION [07/2013 - ]»(ref-612430-S39510651692014042900000)

Scheme 22

Scheme 23

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL [07/2013 - ] - Step 1»(/scion/fr-s/i-2012-2016/remont/body-electrical/#charging-system-service-information)
2. REMOVE DOOR ARMREST COVER RH HINT: Use the same procedure as for the LH side. Refer to «DISASSEMBLY [07/2013 - 12/2013] - Step 2»(ref-612393-S31114778102014042900000).
3. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY RH HINT: Use the same procedure as for the LH side. Refer to «DISASSEMBLY [07/2013 - 12/2013] - Step 3»(ref-612393-S31114778102014042900000).
4. REMOVE POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL. Refer to «DISASSEMBLY [07/2013 - 12/2013] - Step 5»(ref-612393-S31114778102014042900000)
5. REMOVE POWER WINDOW REGULATOR SWITCH ASSEMBLY Using a screwdriver with its tip wrapped in protective tape, disengage the 4 claws and remove the power window regulator switch assembly. TEXT IN ILLUSTRATION *1 Protective Tape

Scheme 24

1. INSTALL POWER WINDOW REGULATOR SWITCH ASSEMBLY Engage the 4 claws to install the power window regulator switch assembly.
2. INSTALL POWER WINDOW REGULATOR SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL. Refer to «REASSEMBLY [07/2013 - 12/2013] - Step 32»(ref-612393-S03451195772014042900000)
3. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY RH HINT: Use the same procedure as for the LH side. Refer to «REASSEMBLY [07/2013 - 12/2013] - Step 34»(ref-612393-S03451195772014042900000).
4. INSTALL DOOR ARMREST COVER RH HINT: Use the same procedure as for the LH side. Refer to «REASSEMBLY [07/2013 - 12/2013] - Step 35»(ref-612393-S03451195772014042900000).
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf)
6. INITIALIZE POWER WINDOW CONTROL SYSTEM Refer to «INITIALIZATION [07/2013 - ]»(ref-612250-S35237050992014042900000)
7. INSPECT POWER WINDOW (POWER WINDOW OPERATION) Refer to «INSPECTION [07/2013 - ]»(ref-612430-S39510651692014042900000)

Scheme 25

Scheme 26
