Scheme 13
Test Description
The numbers below refer to the step numbers on the diagnostic table.
- 1: Diagnostic System Check
- 2: This step checks DTC status as current or history in Remote Function Actuation Menu on scan tool.
- 3: This step identifies the key fob #, transmitter, with a low battery signal.
- 4: This step verifies that the battery replacement corrected the fault.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Keyless Entry Schematics | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. Select the body control module (BCM) display DTCs function on the scan tool. Does the scan tool display DTC B3109 as a current DTC? | Go to Step 3 | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems |
| 3 | With a scan tool, observe the Key Fob Low Voltage parameters for each transmitter in the door lock information data list to identify the programmed transmitter that set the code. Replace the batteries on the indicated transmitters. Refer to Transmitter Battery Replacement . Did you complete the batteries replacement? | Go to Step 4 | |
| 4 | Use the scan tool in order to clear DTCs. Operate for 3 consecutive times the transmitters that had the battery replaced. Does the DTC reset? | Go to Step 5 | System OK |
| 5 | Inspect for poor connections at the battery connection of the transmitters that set the DTC. Did you find and correct the condition? | System OK | Go to Step 6 |
| 6 | Replace the transmitters. Ensure that the replacement transmitters is the correct model for the vehicle. All transmitters must be programmed at the same time. Refer to Transmitter Programming . Did you complete the replacement? | Go to Step 7 | |
| 7 | Use scan tool in order to clear the DTCs. Operate the replacement transmitters 3 consecutive times. Does the DTC reset? | Go to Step 8 | System OK |
| 8 | Replace the integrated body control module (IBCM). Refer to Control Module References in Computer/Integrating Systems for replacement, setup, and programming. Did you complete the replacement? | System OK | |
DTC B3109
Symptoms - Keyless Entry
| IMPORTANT | The following steps must be completed before using the symptom tables. |
- Perform «Diagnostic System Check - Vehicle»(ref-196940-S27536559152005101000000) in Vehicle DTC Information, before using the Symptom Tables in order to verify that all of the following are true: No DTCs are set. The control modules can communicate via the serial data link.
- Review the system operation in order to familiarize yourself with the system functions. Refer to «Keyless Entry System Description and Operation»(ref-196959-S22174068142005101000000) .
Unlock All Doors - Second Operation
Momentarily press the UNLOCK button a second time, within 5 seconds of the first press, in order to perform the following functions
- Unlock the remaining doors.
- Illuminate the interior lamps for approximately 20 seconds or until the ignition is turned ON.
