Hybrid Control System: Specifications Saturn Aura I

Body Electrical 2 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
36-Volt Terminal Block Nut to Generator Control Module10 N.m89 lb in
Generator Control Module 3 Phase Cable Bracket Bolt8 N.m71 lb in
Generator Control Module 3 Phase Cable Bracket to Clip Bolt10 N.m89 lb in
Generator Control Module 3 Phase Cable to Generator Starter Nut8 N.m71 lb in
Generator Control Module 3 Phase Cable Terminal Block Nut8 N.m71 lb in
Generator Control Module Bracket to Module Bolt10 N.m89 lb in
Generator Control Module Bracket Nut10 N.m89 lb in
Generator Control Module Bracket Reinforcement Bolt/Nut10 N.m89 lb in
Generator Control Module Cover Bolt10 N.m89 lb in
Generator Control Module Ground Strap Nut10 N.m89 lb in
Generator Starter Bolt58 N.m43 lb ft
Generator Starter Cover Bolt5 N.m44 lb in
Rear Generator Control Module 3 Phase Cable Bolt8 N.m71 lb in

Scheme 161

Scheme 161: Hybrid Controls Schematics
Scheme 161: Hybrid Controls Schematics

Scheme 162

Scheme 162
Scheme 162
