Automatic Transaxle - 4T45-E - Introduction (2 of 2): Specifications Saturn Aura I

Automatic Trans 32 illustrations ~113 words

Transmission Fluid Temperature Sensor Specifications

TemperatureTemperatureMinimum ResistanceNominal ResistanceMaximum ResistanceSignal
°F°COhmsOhmsOhmsVolts
4040906361007071107785.00
22304741652684579524.78
4202580928677315454.34
14101455816176177943.89
32084819423103653.45
50105104567162383.01
68203164351538672.56
86302013223724611.80
104401313145916051.10
1225087697310703.25
140606006677342.88
158704204675142.56
176802993323652.24
194902172412651.70
2121001591771951.42
2301101191321451.15
24812089.999.9109.90.87
26613069.176.884.50.60
28414053.859.865.80.32
30215042.547.251.90.00

Fastener Tightening Specifications

Description of UsageRef No.*QtySizeSpecification
MetricEnglish
Auxiliary Fluid Pump Check Valve227125.5 N.m18.8 lb ft
Auxiliary Fluid Pump Outlet Pipe229122.5 N.m16.6 lb ft
Bottom Pan to Case8112M6x1.0x19.012 N.m106 lb in
Channel Plate to Case82M6x1.0x63.014 N.m124 lb in
Channel Plate to Case256M6x1.0x28.012 N.m106 lb in
Channel Plate to Driven Sprocket Support252M6x1.0x28.014 N.m124 lb in
Detent Spring Assembly to Channel Plate8051M6x1.0x19.012 N.m106 lb in
Drive Sprocket Support Assembly to Case536M6x1.0x17.012 N.m106 lb in
Input Speed Sensor to Case151M6x1.0x15.012 N.m106 lb in
Intermediate 4th Servo Cover to Case253M6x1.0x28.012 N.m106 lb in
Line Pressure Plug to Case4811/8-27NPTF12 N.m106 lb in
Lo/Reverse Servo Cover to Case253M6x1.0x28.012 N.m106 lb in
Oil Level Control Plug to Case6511/8-27NPTF12 N.m106 lb in
Oil Tube Assembly To Case812M6x1.0x19.012 N.m106 lb in
Oil Tube Assembly to Forward Clutch811M6x1.0x19.012 N.m106 lb in
Oil Tube Assembly to Lo/Reverse Servo Cover811M6x1.0x19.012 N.m106 lb in
Output Shaft Speed Sensor to Case611M6x1.0x16.012 N.m106 lb in
Pipe to Case Bolts1323M8x1.25x25.025 N.m18 lb ft
Pump to Case91M6x1.0x103.012 N.m106 lb in
Pump to Channel Plate81M6x1.0x63.012 N.m106 lb in
Pump to Channel Plate126M6x1.0x90.012 N.m106 lb in
Pump to Side Cover Bolt1314M8x1.25x30.025 N.m18 lb ft
Retainer Clip Bolts1332M4x0.74.5 N.m40 lb in
Side Cover to Case310M8x1.25x28.028 N.m22 lb ft
Side Cover to Case (Stud)41M8x1.25x28.028 N.m22 lb ft
Spacer to Driven Sprocket Support202M6x1.0x70.014 N.m124 lb in
TFP Switch Assembly to Case122M6x1.0x90.014 N.m124 lb in
TFP Switch to Channel Plate163M6x1.0x51.014 N.m124 lb in
TFP Switch to Channel Plate81M6x1.0x63.014 N.m124 lb in
Transmission Fluid Cooler Hose Pipe-to-Radiator Fittings16 N.m12 lb ft
Transmission Fluid Cooler Hose Pipe-to-Transaxle Nut9 N.m80 lb in
Valve Body to Case92M6x1.0x103.014 N.m124 lb in
Valve Body to Case125M6x1.0x90.014 N.m124 lb in
Valve Body to Channel Plate165M6x1.0x51.014 N.m124 lb in
Wiring Harness Clip to Case151M6x1.0x15.012 N.m106 lb in
* Reference Number refers to the callout number on the disassembled view.

Fastener Tightening Specifications

Transmission General Specifications

NameHydra-Matic® 4T45-E
RPO CodesMN5 - ME7 Hybrid
Production LocationWindsor, Ontario, Canada
Vehicle Platform Engine/Transmission Usage3A, A, Z, Z-SUV, A-SUV
Transmission DriveTransverse Mounted Front Wheel Drive
Maximum Engine Torque4T45-E 290 N.m (215 lb ft)
Maximum Shift Speed1-2 6,500 RPM 2-3 6,500 RPM 3-4 6,500 RPM
1st Gear Ratio2.960:1
2nd Gear Ratio1.626:1
3rd Gear Ratio1.000:1
4th Gear Ratio0.681:1
Reverse2.143:1
Torque Converter Size - Diameter of Torque Converter Turbine245 mm
Pressure TapsLine Pressure
Transmission Fluid TypeDEXRON® VI
Transmission Fluid Capacity - ApproximateBottom Pan Removal: 6.6 L (7.0 qts) Complete Overhaul: 9.0 L (9.5 qts) Dry: 12.2 L (12.9 qts)
Transmission Type: 4Four Forward Gears
Transmission Type: TTransverse Mount
Transmission Type: 45Product Series
Transmission Type: EElectronic Controls
Position QuadrantModel Dependent
Case MaterialDie Cast Aluminum
Transmission Weight Dry75.1 kg (165.6 lbs)
Transmission Weight Wet85.5 kg (188.5 lbs)
Maximum Trailer Towing Capacity487 kg (1,000 lbs)
Maximum Gross Vehicle Weight (GVW)1,826 kg (4,100 lbs)
Ratios
ChainFinal DriveEffective - Overall
32/383.293.91
32/383.053.63
35/353.293.29
35/353.053.05

Fluid Capacity Specifications

ApplicationSpecification
MetricEnglish
Bottom Pan Removal6.6 liters7.0 quarts
Complete Overhaul9.0 liters9.5 quarts
Dry12.2 liters12.9 quarts
Measurements are approximate.

Fluid Capacity Specifications (4T45-E)

End Play Specifications

Recorded MeasurementWasher SelectionWasher Dimension
100.40-100.70 mm (3.952-3.964 in)Brown1.50-1.60 mm (0.059-0.062 in)
100.71-100.99 mm (3.965-3.975 in)Grey1.80-1.90 mm (0.070-0.075 in)
101.00-101.29 mm (3.976-3.987 in)Natural2.09-2.19 mm (0.082-0.086 in)
101.30-101.59 mm (3.988-3.999 in)Black2.39-2.49 mm (0.094-0.098 in)
101.60-101.88 mm (4.00-4.011 in)Orange2.68-2.78 mm (0.105-0.109 in)
101.89-102.18 mm (4.012-4.022 in)Violet2.98-3.08 mm (0.117-0.121 in)
102.19-102.48 mm (4.023-4.034 in)Yellow3.28-3.38 mm (0.129-0.133 in)
102.49-102.77 mm (4.035-4.046 in)Red3.57-3.67 mm (0.140-0.144 in)
102.78-103.07 mm (4.047-4.058 in)Green3.87-3.97 mm (0.152-0.156 in)

End Play Specifications (Selective Washer Table)

Clutch Plate Selection Specifications

Broadcast CodesQuantity
SteelFiber
BAJ66
BBJ66
ELJ66
EPJ66

Direct Clutch Plate Selection Specifications

Scheme 297

Scheme 297: Automatic Transmission Controls Schematics (MN5)
Scheme 297: Automatic Transmission Controls Schematics (MN5)

Scheme 298

Scheme 298
Scheme 298

Scheme 299

Scheme 299
Scheme 299

Scheme 300

Scheme 300
Scheme 300

Scheme 301

Scheme 301
Scheme 301

Scheme 302

Scheme 302: Automatic Transmission Controls Schematics (ME7)
Scheme 302: Automatic Transmission Controls Schematics (ME7)

Scheme 303

Scheme 303
Scheme 303

Scheme 304

Scheme 304
Scheme 304

Scheme 305

Scheme 305
Scheme 305

Scheme 306

Scheme 306
Scheme 306

Scheme 307

Scheme 307: Automatic Transmission Electronic Component Views
Scheme 307: Automatic Transmission Electronic Component Views
CalloutComponent Name
13TFP Manual Valve Position Switch Assembly
46Input Speed Sensor
62Output Speed Sensor
1384-3 Solenoid - L4 Hybrid
225Auxiliary Pump - L4 Hybrid
3051-2 and 2-3 Shift Solenoid Valves
3051-2 and 2-3 Shift Solenoid Valves
312Pressure Control Solenoid
335TCC Control PWM Solenoid

Scheme 308

Scheme 308: Disassembled Views
Scheme 308: Disassembled Views
CalloutComponent Name
1Side Cover (Structural)
2Axle Oil Seal
3Side Cover Bolt
4Side Cover Stud
5Side Cover Gasket
6Side Cover Oil Level Control Gasket
7Thrust Washer (Side Cover to Driven Sprocket)
8Oil Pump Bolt
9Oil Pump Bolt
10Transaxle Oil Pump Assembly
11Transaxle Wiring Assembly
12TFP Manual Valve Position Switch Assembly Bolt
13TFP Manual Valve Position Switch Assembly
15Wiring Harness Bracket Bolt/Input Speed Sensor Bolt
51Transaxle Case
52Vent Cap
55Torque Converter Assembly
61Output Speed Sensor Stud
62Output Shaft Speed Sensor
63O-Ring Seal (Output Speed Sensor)
64Band Anchor Pin (Lo/Reverse)
65Oil Level Control Plug
81Tube Assembly Bolt/Bottom Pan Bolt
84Transaxle Oil Filter Seal
85Transaxle Oil Filter Assembly
86Oil Level Control Valve
87Transaxle Bottom Pan Gasket
88Transaxle Oil Pan
89Chip Collector Magnet
126Side Cover Stud

Scheme 309

Scheme 309
Scheme 309
CalloutComponent Name
1Side Cover (Structural)
2Axle Oil Seal
3Side Cover Bolt
4Side Cover Stud
5Side Cover Gasket
6Side Cover Oil Level Control Gasket
7Thrust Washer (Side Cover to Driven Sprocket)
8Oil Pump Bolt
9Oil Pump Bolt
10Transaxle Oil Pump Assembly
11Transaxle Wiring Assembly
12TFP Manual Valve Position Switch Assembly Bolt
13TFP Manual Valve Position Switch Assembly
15Wiring Harness Bracket Bolt/Input Speed Sensor Bolt
51Transaxle Case
52Vent Cap
55Torque Converter Assembly
61Output Speed Sensor Stud
62Output Shaft Speed Sensor
63O-Ring Seal (Output Speed Sensor)
64Band Anchor Pin (Lo/Reverse)
65Oil Level Control Plug
81Tube Assembly Bolt/Bottom Pan Bolt
84Transaxle Oil Filter Seal
85Transaxle Oil Filter Assembly
86Oil Level Control Valve
87Transaxle Bottom Pan Gasket
88Transaxle Oil Pan
89Chip Collector Magnet
126Side Cover Stud
130A/Trans Auxiliary Fluid Pump Assembly
131Auxiliary Trans Fluid Pump Bolts
132Auxiliary Pump Pipe Bolts

Scheme 310

Scheme 310
Scheme 310
CalloutComponent Name
16Control Valve Body Bolt
18Control Valve Body Assembly
19Oil Pump Drive Shaft
20Spacer Plate Support Bolt
21Spacer Plate Support
25Channel Plate Bolt/Servo Cover Bolt
25Channel Plate Bolt/Servo Cover Bolt
25Channel Plate Bolt/Servo Cover Bolt
26Checkballs (7)
27Channel Plate
28Case To Channel Plate Gasket
29Accumulator Piston (1-2, 2-3 and 3-4)
29Accumulator Piston (1-2, 2-3 and 3-4)
29Accumulator Piston (1-2, 2-3 and 3-4)
30Accumulator Piston Seal (1-2, 2-3 and 3-4)
30Accumulator Piston Seal (1-2, 2-3 and 3-4)
30Accumulator Piston Seal (1-2, 2-3 and 3-4)
311-2 Accumulator Piston Spring
322-3 and 3-4 Accumulator Piston Spring
322-3 and 3-4 Accumulator Piston Spring
45Dowel Pin
472-3 Accumulator Piston Cushion Spring
48Line Pressure Tap Plug
49Cooler Pipe Seal
51Transaxle Case
66Servo Return Spring (Lo/Reverse)
67Servo Apply Pin (Lo/Reverse)
68Servo Cushion Spring
68Servo Cushion Spring
69Servo Piston (Lo/Reverse)
70Servo Snap Ring
70Servo Snap Ring
71Servo Piston Seal (Lo/Reverse)
72Servo Cover Seal (Lo/Reverse)
73Servo Cover (Lo/Reverse)
75Servo Return Spring (Intermediate/4th)
76Servo Apply Pin (Intermediate/4th)
77Servo Piston (Intermediate/4th)
78Servo Piston Seal (Intermediate/4th)
79Servo Cover Seal (Intermediate/4th)
80Servo Cover (Intermediate/4th)
81Tube Assembly Bolt/Bottom Pan Bolt
81Tube Assembly Bolt/Bottom Pan Bolt
81Tube Assembly Bolt/Bottom Pan Bolt
82Oil Feed Tube Assembly Seal
82Oil Feed Tube Assembly Seal
82Oil Feed Tube Assembly Seal
82Oil Feed Tube Assembly Seal
83Oil Feed Tube Assembly
90Spacer Plate with Bonded Gaskets - Model Dependent
1251-2 Accumulator Piston Cushion Spring and Retainer Assembly
1334-3 Downshift On/Off Solenoid Bolt - L4 Hybrid
1344-3 Downshift On/Off Solenoid Clip - L4 Hybrid
1354-3 Downshift On/Off Solenoid Assembly - L4 Hybrid
1364-3 Downshift On/Off Solenoid Seal - L4 Hybrid
1374-3 Downshift On/Off Solenoid Body Assembly - L4 Hybrid
1384-3 Downshift On/Off Solenoid and Body Assembly - L4 Hybrid
139Servo Cushion Spring
139Servo Cushion Spring

Scheme 311

Scheme 311
Scheme 311
CalloutComponent Name
2Axle Oil Seal
15Wiring Harness Bracket Bolt/Input Speed Sensor Bolt
33Turbine Shaft To Channel Plate Sleeve Seal
34Thrust Washer (Channel Plate to Drive Sprocket)
35Snap Ring (Turbine Shaft To Drive Sprocket)
36Drive Link Assembly
37Drive Sprocket
38Thrust Washer (Drive Sprocket to Support)
39Turbine Shaft
40Turbine Shaft to Support Seal
41O-Ring Seal (Torque Converter)
42Drive Sprocket Support Bearing
43Drive Sprocket Support
44Drive Sprocket Support Bushing
46Input Speed Sensor
51Transaxle Case
53Drive Sprocket Support Screw
54Converter Seal
56Output/Stub Shaft Sleeve
56Output/Stub Shaft Sleeve
57Output/Stub Shaft Snap Ring
57Output/Stub Shaft Snap Ring
57Output/Stub Shaft Snap Ring
58Output Stub Shaft
60Case To Final Drive Bushing
91Driven Sprocket
92Thrust Washer (Driven Sprocket to Support)
94Output Shaft
95Driven Sprocket Support Assembly
962nd Clutch Plate (Waved)
972nd Clutch Plate (Steel)
982nd Clutch Plate (Fiber)
992nd Clutch Plate (Backing)
100Intermediate/4th Band
101Thrust Washer (Support To Reverse Input Clutch)
102Reverse Input Clutch Assembly
103Thrust Bearing
104Thrust Washer (Selective)
105Direct and Coast Clutch Assembly
106Input Carrier Assembly
107Thrust Bearing
108Input Flange and Forward Clutch Hub Assembly
109Thrust Washer
110Forward Clutch Assembly
111Lo/Reverse Band
112Snap Ring (Forward Clutch Support to Case)
113Thrust Bearing
114Forward Clutch Support Assembly
115Final Drive Sun Gear
116Differential and Final Drive Assembly
117Thrust Bearing
118Final Drive Internal Gear
119Internal Gear to Case Fretting Ring

Scheme 312

Scheme 312
Scheme 312
CalloutComponent Name
200Oil Pump Bearing and Seal Assembly
201Oil Pump Base
202Oil Pump Vane Ring
202Oil Pump Vane Ring
203Oil Pump Vane
204Oil Pump Rotor
205Pivot Pin (Oil Pump Slide)
206Oil Pump Slide
207Oil Pump Slide Seal Support
208Oil Pump Slide Seal
209O-Ring Seal (Oil Pump Slide)
210Fluid Seal Ring (Slide to Body)
212Oil Pump Priming Spring
213Locating Pin
214Pressure Relief Ball
215Pressure Relief Spring
216Oil Pump Body
217Pump Cover

Scheme 313

Scheme 313
Scheme 313
CalloutComponent Name
132Bolt
225A/Trans Auxiliary Fluid Pump
226A/Trans Auxiliary Fluid Pump Check Valve Seal
227A/Trans Auxiliary Fluid Pump Check Valve
228A/Trans Auxiliary Fluid Pump Outlet Pipe Seal
229A/Trans Auxiliary Fluid Pump Outlet Pipe
230A/Trans Auxiliary Fluid Pump Outlet Pipe Spacer
231A/Trans Auxiliary Fluid Pump Inlet Pipe
232A/Trans Auxiliary Fluid Pump Inlet Pipe Seal

Scheme 314

Scheme 314
Scheme 314
CalloutComponent Name
300Control Valve Body Assembly
300Control Valve Body Assembly
3011-2 Shift Valve Spring
3021-2 Shift Valve
303Shift Solenoid O-Ring (1-2 and 2-3)
303Shift Solenoid O-Ring (1-2 and 2-3)
304Retainer Clip
304Retainer Clip
304Retainer Clip
304Retainer Clip
304Retainer Clip
304Retainer Clip
304Retainer Clip
304Retainer Clip
304Retainer Clip
304Retainer Clip
305Shift Solenoid (1-2 and 2-3)
305Shift Solenoid (1-2 and 2-3)
3062-3 Shift Valve Spring
3072-3 Shift Valve
308Torque Signal Regulator Valve Spring
309Torque Signal Regulator Valve
310Pressure Control Solenoid O-Ring
311Pressure Control Solenoid O-Ring
312Pressure Control Solenoid
313Actuator Oil Filter O-Ring
314Actuator Oil Filter
315Actuator Feed Limit Valve
316Actuator Feed Limit Valve Spring
317Bore Plug
3183-4 Shift Valve Spring
3193-4 Shift Valve
3203-4 Shift Valve Plug O-Ring
321Bore Plug
3231-2/3-4 Accumulator Valve
324Pressure Regulator Boost Valve Bushing
325Pressure Regulator Boost Valve
326Isolator Spring
327Pressure Regulator Valve Spring
328Pressure Regulator Valve
333TCC Control Valve Spring
334TCC Control Valve
335TCC Control PWM Solenoid
337TCC Control Solenoid O-Ring
338TCC Control Solenoid O-Ring
339TCC Regulated Apply Valve
340TCC Regulated Apply Valve Spring
341Bore Plug

Scheme 315

Scheme 315
Scheme 315
CalloutComponent Name
400Driven Sprocket Support Bearing
401Driven Sprocket Support
402Driven Sprocket Support Bushing
403Oil Seal Ring
4042nd Clutch Piston Assembly
4052nd Clutch Spring Assembly
4062nd Clutch Spring Retaining Ring
407Reverse Intermediate Clutch Housing Valve Assembly

Scheme 316

Scheme 316
Scheme 316
CalloutComponent Name
4502nd Roller Clutch Retainer
4512nd Roller Clutch Cam
4522nd Roller Clutch Assembly
453Reverse Clutch Bushing
454Reverse Clutch Housing
455Reverse Clutch Bushing
456Reverse Clutch Center Retainer and Seal Assembly
457Reverse Clutch Piston Assembly
458Reverse Clutch Spring and Retainer Assembly
459Snap Ring (Reverse Clutch Spring Retainer)
460Reverse Clutch Plate (Waved)
461Reverse Clutch Plate (Steel)
462Reverse Clutch Plate (Fiber)
463Reverse Clutch Backing Plate
464Snap Ring (Reverse Clutch)

Scheme 317

Scheme 317
Scheme 317
CalloutComponent Name
500Input Shaft Oil Seal Ring
501Input Shaft Bushing
502Direct and Coast Clutch and Input Shaft Housing
503Direct Clutch Housing to Output Shaft Bushing
504Coast Clutch Piston Assembly
505Coast Clutch Release Spring
506Coast Clutch Spring Retainer
507Snap Ring (Coast Clutch Spring Retainer)
508Coast Clutch Plate (Steel)
509Coast Clutch Plate (Fiber)
510Thrust Bearing
511Input Sun Gear Shaft and Inner Race Assembly
512Outer Race (Input Sprag)
514Sprag Clutch End Bearings (2)
514Sprag Clutch End Bearings (2)
515Input Sprag Assembly
516Snap Ring (Outer Race to Sprag Assembly)
517Snap Ring (Direct/Coast Clutch Retaining)
518Direct Clutch Piston Assembly
519Direct Clutch Spring and Retainer Assembly
520Direct Clutch Spring Retainer Ring
521Direct Clutch Plate (Steel) - 7 or 6 - Model Dependent
522Direct Clutch Plate (Fiber) - 5 or 6 - Model Dependent
523Direct Clutch Plate (Backing)
524Thrust Bearing
525Reaction Carrier Shaft Bushing
526Reaction Carrier Shaft Shell
527Thrust Bearing (Carrier Shaft to Shell)
528Reaction Sun Gear Bushing
529Reaction Sun Shell
531Reaction Carrier Assembly
532Thrust Bearing (Reaction Carrier to Sun Gear)
533Input Sun Gear
534Snap Ring

Scheme 318

Scheme 318
Scheme 318
CalloutComponent Name
550Reaction Carrier
551Thrust Bearing
552Planetary Pinion Gear Pin
553Pinion Thrust Reaction Washer
553Pinion Thrust Reaction Washer
554Pinion Thrust Inner Washer
554Pinion Thrust Inner Washer
555Roller Needle Bearing
556Reaction Planetary Pinion Gear

Scheme 319

Scheme 319
Scheme 319
CalloutComponent Name
560Internal Gear (Input and Reaction)
561Thrust Bearing
562Input Carrier
563Snap Ring (Input Carrier to Internal Gear)
564Planetary Pinion Gear Pin
565Pinion Thrust Input Washer
565Pinion Thrust Input Washer
566Pinion Thrust Inner Washer
566Pinion Thrust Inner Washer
567Roller Needle Bearing
568Input Planetary Pinion Gear

Scheme 320

Scheme 320
Scheme 320
CalloutComponent Name
560Internal Gear (Input and Reaction)
575Input Flange Bushing
577Input Flange and Forward Clutch Hub
578Snap Ring (Input Internal Gear to Input Flange)

Scheme 321

Scheme 321
Scheme 321
CalloutComponent Name
600Snap Ring (Forward Clutch)
601Forward Clutch Plate (Backing)
602Forward Clutch Plate (Fiber)
603Forward Clutch Plate (Steel)
604Forward Clutch Plate (Waved)
605Snap Ring (Forward Clutch Spring Assembly)
606Forward Clutch Return Spring Assembly
607Forward Clutch Piston Assembly
608Forward Clutch Inner Seal and Sleeve Assembly
609Forward Clutch Housing
610Forward Clutch Support Bushing
611Forward Clutch Support Bushing

Scheme 322

Scheme 322
Scheme 322
CalloutComponent Name
650Final Drive Sun Shaft Bushing
651Final Drive Sun Shaft
652Lo Roller Clutch Assembly
654Oil Seal Ring (Forward Clutch Support)
656Forward Clutch Support
658Thrust Bearing (Forward Support to Park Gear)
659Park Lock Gear
660Snap Ring (Final Drive Sun Shaft)
661Parking Lock Pawl Shaft
662Parking Lock Pawl Return Spring
663Parking Lock Pawl

Scheme 323

Scheme 323
Scheme 323
CalloutComponent Name
115Sun Gear (Final Drive)
700Thrust Bearing
701Spiral Pin Retaining Ring
702Differential and Final Drive Carrier
703Differential Pinion Shaft
704Differential Pinion Shaft Retaining Pin
705Speed Sensor Rotor
706Thrust Washer (Differential Pinion)
706Thrust Washer (Differential Pinion)
707Differential Pinion Gear
707Differential Pinion Gear
708Thrust Washer (Differential Side Gear)
708Thrust Washer (Differential Side Gear)
709Differential Side Gear
709Differential Side Gear
710Pinion Thrust Washer
710Pinion Thrust Washer
711Pinion Gear (Final Drive Planetary)
712Roller Needle Bearing
713Pinion Needle Bearing Spacer
714Planetary Pinion Gear Pin

Scheme 324

Scheme 324
Scheme 324
CalloutComponent Name
51Transaxle Case
800Manual Valve
801Manual Valve to Link Clip
802Manual Valve to Detent Lever Link
803Manual Shaft to Case Pin
804Manual Detent Spring and Roller Assembly
805Spring and Roller Assembly to Channel Plate Bolt
806Manual Shaft and Detent Lever Assembly
807Parking Lock Actuator Assembly
809Manual Shaft to Case Seal
810Actuator Guide Spring Pin
811Actuator Guide Seal
812Actuator Guide

Scheme 325

Scheme 325: Component Location
Scheme 325: Component Location
CalloutComponent Name
1TFP Manual Valve Position Switch Assembly
2Control Valve Body Assembly
3Torque Converter Assembly
4Manual Shaft and Detent Lever Assembly
52nd Clutch
6Reverse Clutch
7Coast Clutch
8Direct Clutch
9Reaction Planetary Gear Set
10Input Planetary Gear Set
11Forward Clutch
12Lo Roller Clutch
13Parking Lock Actuator Assembly
14Differential and Final Drive Assembly
15Output Stub Shaft
16Output Speed Sensor
17Lo/Reverse Servo Assembly
18Lo/Reverse Band
19Oil Feed Tube Assembly
20Input Sprag Clutch Assembly
21Oil Filter Assembly
222nd Roller Clutch
23Oil Level Control Valve
24Drive Link Assembly
25Driven Sprocket
26Output Shaft
27Channel Plate Assembly
28Input Speed Sensor
294-3 Solenoid
30Drive Sprocket
31Control Valve Body Assembly
32Oil Pump Assembly
33Auxiliary Pump

Scheme 326

Scheme 326
Scheme 326
CalloutComponent Name
7Thrust Washer (Side Cover to Driven Sprocket)
34Thrust Washer (Channel Plate to Drive Sprocket)
38Thrust Washer (Drive Sprocket to Support)
42Drive Sprocket Support Bearing
92Thrust Washer (Driven Sprocket to Support)
101Thrust Washer (Support to Reverse Input Clutch)
103Thrust Bearing
104Selective Thrust Washer
107Thrust Bearing
109Thrust Washer
113Thrust Bearing
117Thrust Bearing
200Oil Pump Bearing and Seal Assembly
400Driven Sprocket Support Bearing
510Thrust Bearing
524Thrust Bearing
527Thrust Bearing (Carrier Shaft to Shell)
532Thrust Bearing (Reaction Carrier to Sun Gear)
551Thrust Bearing
561Thrust Bearing
658Thrust Bearing (Forward Support to Park Gear)
700Thrust Bearing

Scheme 327

Scheme 327
Scheme 327
CalloutComponent Name
2Axle Oil Seal
2Axle Oil Seal
30Accumulator Piston Seal (1-2, 2-3 and 3-4)
33Seal (Turbine Shaft to Channel Plate Sleeve)
40O-Ring Seal (Turbine Shaft to Support)
41O-Ring Seal (Torque Converter)
54Converter Seal
63O-Ring Seal (Output Speed Sensor)
71Servo Piston Seal (Lo/Reverse)
72Servo Cover Seal (Lo/Reverse)
78Servo Piston Seal (Intermediate/4th)
79Servo Cover Seal (Intermediate/4th)
403Oil Seal Ring
4042nd Clutch Piston Assembly
456Reverse Clutch Center Retainer and Seal Assembly
457Reverse Clutch Piston Assembly
500Oil Seal Ring- Input Shaft
504Coast Clutch Piston Assembly
518Direct Clutch Piston Assembly
607Forward Clutch Piston Assembly
608Forward Clutch Inner Seal and Sleeve Assembly
654Oil Seal Ring (Forward Clutch Support)
811Actuator Guide Seal

Scheme 328

Scheme 328
Scheme 328
CalloutComponent Name
1364-3 Downshift On/Off Solenoid Seal - L4 Hybrid
226A/Trans Auxiliary Fluid Pump Check Valve Seal
228A/Trans Auxiliary Fluid Pump Outlet Pipe Seal
228A/Trans Auxiliary Fluid Pump Outlet Pipe Seal
230A/Trans Auxiliary Fluid Pump Outlet Pipe Spacer
232A/Trans Auxiliary Fluid Pump Inlet Pipe Seal
232A/Trans Auxiliary Fluid Pump Inlet Pipe Seal

More articles — Automatic Transaxle - 4T45-E - Introduction (2 of 2)
