Wipers and Washers: Specifications Saab 9-7X I

Wiper/washer Systems 18 illustrations ~167 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Air Inlet Panel Grille Nuts4 N.m35 lb in
Front Wiper Arm Nuts30 N.m22 lb ft
Front Wiper Motor Cover Screws3 N.m27 lb in
Rear Wiper Arm Nut20 N.m15 lb ft
Rear Wiper Arm Park Ramp Bolts9 N.m79 lb in
Rear Wiper Motor Bolts8 N.m71 lb in
Rear Wiper Motor Shaft Nut8 N.m71 lb in
Washer Solvent Container Assembly Nuts10 N.m89 lb in
Wiper Transmission Assembly Bolts8 N.m71 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Wiper/Washer Schematics
Scheme 1: Wiper/Washer Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6: Wiper/Washer Component Views
Scheme 6: Wiper/Washer Component Views
CalloutComponent Name
1Windshield Washer Fluid Level Switch
2Headlamp Washer Fluid Pump (CE4)
3Windshield Washer Fluid Pump
4Rear Window Washer Fluid Pump
5Air Cleaner Housing

Scheme 7

Scheme 7
Scheme 7
CalloutComponent Name
1Instrument Panel Harness
2Windshield Wiper Motor

Scheme 8

Scheme 8
Scheme 8
CalloutComponent Name
1Rear Window Wiper/Washer Switch
2I/P Dimmer Switch
3Interior Lamp Defeat Switch
4Instrument Panel Cluster (IPC)
5Driver Information Center (DIC) Switch
6Radio
7Inflatable Restraint I/P Module
8HVAC Control Module

Scheme 9

Scheme 9
Scheme 9
CalloutComponent Name
1Turn Signal/Multifunction Switch
2Windshield Wiper/Washer Switch
3C201

Scheme 10

Scheme 10
Scheme 10
CalloutComponent Name
1Rear Window Defogger Grid C2
2C905
3C900
4C904
5Rear Window Defogger Grid C1
6S901
7Liftglass Ajar Switch
8Liftgate Harness
9Liftgate Module (LGM)
10C901
11License Lamp Harness
12Liftgate Latch Assembly
13Rear Window Wiper Motor

Scheme 11

Scheme 11: Headlamp Washer Fluid Pump (CE4)
Scheme 11: Headlamp Washer Fluid Pump (CE4)
Connector Part Information OEM: 15324474 Service: 15306394 Description: 2-Way F Receptacle 6.3 Series Sealed (BK)
Terminal Part Information Terminal/Tray: 344070-1/17 Core/Insulation Crimp: 2/B Release Tool/Test Probe: 12094429/J-35616-42 (RD)

Headlamp Washer Fluid Pump (CE4) Connector Parts Information

PinWire ColorCircuit No.Function
1BK250Ground
2PU1197Headlamp Washer Pump Control

Headlamp Washer Fluid Pump (CE4) Connector Terminal Identification

Scheme 12

Scheme 12: Rear Window Washer Fluid Pump
Scheme 12: Rear Window Washer Fluid Pump
Connector Part Information OEM: 12020599 Service: 12102664 Description: 2-Way F Metri-Pack 280 Series Sealed (BK)
Terminal Part Information Terminal/Tray: 12077411/2 Core/Insulation Crimp: 2/5 Release Tool/Test Probe: 12094430/J-35616-4A (PU)

Rear Window Washer Fluid Pump Connector Parts Information

PinWire ColorCircuit No.Function
ABK250Ground
BD-GN392Rear Window Washer Pump Control

Rear Window Washer Fluid Pump Connector Terminal Identification

Scheme 13

Scheme 13: Rear Window Wiper Motor
Scheme 13: Rear Window Wiper Motor
Connector Part Information OEM: 12041429 Service: 12167129 Description: 5-Way F Metri-Pack 280 Series Unsealed (BK)
Terminal Part Information Pins: A Terminal/Tray: 12015858/4 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: 12094430/J-35616-4A (PU) Pins: C Terminal/Tray: 12034046/2 Core/Insulation Crimp: C/D Release Tool/Test Probe: 12094430/J-35616-4A (PU) Pins: E Terminal/Tray: 12034046/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094430/J-35616-4A (PU)

Rear Window Wiper Motor Connector Parts Information

PinWire ColorCircuit No.Function
ABK1550Ground
BNot Used
COG4440Battery Positive Voltage
DNot Used
ED-GN2269Rear Window Motor Speed Signal

Rear Window Wiper Motor Connector Terminal Identification

Scheme 14

Scheme 14: Rear Window Wiper/Washer Switch
Scheme 14: Rear Window Wiper/Washer Switch
Connector Part Information OEM: 12059800 Service: 15306169 Description: 5-Way F Metri-Pack 150 Series Unsealed (BK)
Terminal Part Information Pins: A-C, E Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-2A (GY)

Rear Window Wiper/Washer Switch Connector Parts Information

PinWire ColorCircuit No.Function
AWH228312-Volt Reference
BBK2250Ground
CBN/WH230Instrument Panel Lamps Dimming Control
DNot Used
EGY391Rear Window Wiper Switch Signal

Rear Window Wiper/Washer Switch Connector Terminal Identification

Scheme 15

Scheme 15: Windshield Washer Fluid Level Switch
Scheme 15: Windshield Washer Fluid Level Switch
Connector Part Information OEM: 15336024 Service: 88987993 Description: 2-Way F GT 150 Series Sealed (BK)
Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/4 Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Windshield Washer Fluid Level Switch Connector Parts Information

PinWire ColorCircuit No.Function
1BK/WH174Low Washer Fluid Indicator Signal
2BK250Ground

Windshield Washer Fluid Level Switch Connector Terminal Identification

Scheme 16

Scheme 16: Windshield Washer Fluid Pump
Scheme 16: Windshield Washer Fluid Pump
Connector Part Information OEM: 12052641 Service: 12102747 Description: 2-Way F Metri-Pack 150 Series Sealed (BK)
Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-2A (GY)

Windshield Washer Fluid Pump Connector Parts Information

PinWire ColorCircuit No.Function
ARD228Windshield Washer Pump Control
BBK250Ground

Windshield Washer Fluid Pump Connector Terminal Identification

Scheme 17

Scheme 17: Windshield Wiper Motor
Scheme 17: Windshield Wiper Motor
Connector Part Information OEM: 15401343 Service: 88986271 Description: 9-Way F GT 150 280 Series Sealed (BK)
Terminal Part Information Pins: C-E, J Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) Pins: F, M Terminal/Tray: 15304716/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-4A (PU) Pins:G Terminal/Tray: 15304716/8 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: 15315247/J-35616-4A (PU)

Windshield Wiper Motor Connector Parts Information

PinWire ColorCircuit No.Function
ANot Used
BNot Available
CPK94Windshield Wiper Switch Signal 1
DD-BU477Windshield Wiper Switch High Signal
EGY478Windshield Wiper Switch Supply Voltage
FYE143Accessory Voltage
GD-GN113Windshield Wiper Switch Signal 2
HNot Available
JOG2268Windshield Washer Relay Control
KNot Used
LNot Available
MBK850Ground

Windshield Wiper Motor Connector Terminal Identification

Scheme 18

Scheme 18: Windshield Wiper/Washer Switch
Scheme 18: Windshield Wiper/Washer Switch
Connector Part Information OEM: 15339096 Service: See Catalog Description: 7-Way F Metri-Pack 150 Series Unsealed (BK)
Terminal Part Information Pins: G-H, L, N Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Windshield Wiper/Washer Switch Connector Parts Information

PinWire ColorCircuit No.Function
GGY478Windshield Wiper Switch Supply Voltage
HPU94Windshield Washer Switch Signal
J-KNot Used
LD-BU/WH477Windshield Wiper Switch High Signal
MNot Used
NBK2250Ground

Windshield Wiper/Washer Switch Connector Terminal Identification
