Power Seats: Specifications Saab 9-7X I

Seats 15 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Seat Control Module Screw3 N.m26 lb in
Seat Cushion Frame Nut25 N.m18 lb ft
Seat Belt Buckle Bolt55 N.m41 lb ft

Fastener Tightening Specifications

Scheme 71

Scheme 71: Driver Seat Schematics
Scheme 71: Driver Seat Schematics

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75: Passenger Seat Schematics
Scheme 75: Passenger Seat Schematics

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77: Power Seat Component Views
Scheme 77: Power Seat Component Views
CalloutComponent Name
1Window Lockout Switch
2Passenger Window Switch
3Right Rear Window Switch
4Door Lock Switch - Driver
5Memory Seat Switch - Driver
6Heated Seat Switch - Driver
7Left Rear Window Switch
8Driver Window Switch

Scheme 78

Scheme 78
Scheme 78
CalloutComponent Name
1Lumbar Adjuster Switch - Driver
2Seat Adjuster Switch - Driver
3Seat Recliner Switch - Driver

Scheme 79

Scheme 79
Scheme 79
CalloutComponent Name
1Seat Recline Motor - Driver
2Seat Position Sensor - Recline
3Inflatable Restraint Seat Position Sensor (SPS) - Left
4Seat Position Sensor - Horizontal
5Seat Horizontal Motor - Driver
6Seat Position Sensor - Front
7Seat Front Vertical Motor - Driver
8Seat Rear Vertical Motor - Driver
9Seat Position Sensor - Rear

Scheme 80

Scheme 80
Scheme 80
CalloutComponent Name
1Memory Seat Module - Driver
2Heated Seat Element Connector - Driver Cushion
3Seat Belt Switch Connector - Driver

Scheme 81

Scheme 81
Scheme 81
CalloutComponent Name
1Lumbar Horizontal Motor - Driver
2Heated Seat Element Connector - Driver Back
3Lumbar Horizontal Position Sensor - Driver
4Seat Belt Pretensioner - Left

Scheme 82

Scheme 82
Scheme 82
CalloutComponent Name
1Seat Recliner Switch - Passenger
2Seat Adjuster Switch - Passenger
3Lumbar Adjuster Switch - Passenger

Scheme 83

Scheme 83
Scheme 83
CalloutComponent Name
1Inflatable Restraint Seat Position Sensor (SPS) - Right
2Seat Recline Motor - Passenger
3Seat Rear Vertical Motor - Passenger
4Seat Front Vertical Motor - Passenger
5Seat Horizontal Motor - Passenger

Scheme 84

Scheme 84
Scheme 84
CalloutComponent Name
1Lumbar Horizontal Motor - Passenger
2Seat Belt Pretensioner - Right
3Heated Seat Element Connector - Passenger Back

Scheme 85

Scheme 85: Lumbar Adjuster Switch - Driver
Scheme 85: Lumbar Adjuster Switch - Driver
Connector Part Information OEM: 12089287 Service: 15306189 Description: 8-Way F Metri-Pack 280 Series (NA)
Terminal Part Information Pins: A, D-E, H Terminal/Tray: 12034046/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094430/J-35616-4A (PU)

Lumbar Adjuster Switch - Driver Connector Parts Information

PinWire ColorCircuit No.Function
APK2407Driver Seat Lumbar Forward Switch Signal
B-CNot Used
DRD2408Driver Seat Lumbar Rearward Switch Signal
EGY961Battery Positive Voltage
F-GNot Used
HBK1350Ground

Lumbar Adjuster Switch - Driver Connector Terminal Identification
