Power Seats: Adjustments Saab 9-7X I

Memory Seat Calibration

The memory seat module uses position sensor inputs to establish soft stop locations for the adjuster motors several millimeters ahead of the physical limits of the adjuster assembly. After replacing a memory seat module or adjuster components, it may be necessary to reset the adjuster motor soft stop locations. When the repair procedure has been completed, operate the seat adjuster switch in every direction until the seat adjuster reaches its mechanical hard stop by repeatedly pressing and releasing the switch as necessary.

Scheme 86

Scheme 87

1. Remove the front bucket seat assembly from the vehicle. Refer to «Front Seat Replacement - Bucket»(ref-268080-S25296243202007101800000) .
2. Remove the seat cushion trim panel. Refer to «Seat Cushion Outer Trim Panel Replacement»(ref-268080-S29487672612007101800000) .
3. Remove the seat belt buckle nut.
4. Disconnect the black electrical connector (6) from the seat back harness.
5. Disconnect the black electrical connector (3) from the seat belt buckle.
6. Disconnect the gray lumbar electrical connector (5), if equipped.
7. Remove the SIR harness (2) from the harness clips (1,4), and remove the SIR harness from the seat.
8. Remove the 4 nuts that secure the seat pan to the power seat adjuster frame.
9. Remove the seat back. Refer to «Seat Back Replacement - Front»(ref-268080-S27725635032007101800000) .
