Seat Belts: Overview Saab 9-7X I

Restraints Control Systems 4 illustrations ~762 words

Seat Belt Schematic Icons

Seat Belt Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to Sir Disabling And Enabling . Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs

Scheme 1

Scheme 1: Seat Belt Schematics
Scheme 1: Seat Belt Schematics

Scheme 2

Scheme 2: Seat Belt Component Views
Scheme 2: Seat Belt Component Views
CalloutComponent Name
1Seat Belt Buckle - Driver

Scheme 3

Scheme 3
Scheme 3
CalloutComponent Name
1Seat Belt Buckle - Passenger

Scheme 4

Scheme 4: Seat Belt Buckle - Driver
Scheme 4: Seat Belt Buckle - Driver
Connector Part Information OEM: 12048457 Service: 12058709 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12059894/5 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Seat Belt Buckle - Driver Connector Parts Information

PinWire ColorCircuit No.Function
ABK2644Seat Position Sensor Return
BBK/WH238Driver Seat Belt Switch Signal

Seat Belt Buckle - Driver Connector Terminal Identification

Operational and Functional Checks

IMPORTANTIf the vehicle has been in a collision, refer to Repairs and Inspections Required After a Collision for additional information.

Perform the following inspection from the driver seat

  1. Turn the ignition switch to the ON position. Verify proper operation of the seat belt reminder lamp with the belt buckled and with the belt unbuckled.
  2. Inspect the shoulder belt guide in order to ensure that the following conditions are met: The shoulder belt guide swivels freely. The seat belt webbing is seated flatly in the guide slot. The seat belt webbing does not bind.
  3. Verify that the seat belt buckle faces inboard and is accessible.
  4. Verify that the seat belt retractor units are securely attached.
  5. Verify that the seat belt anchor bolts are secure.
  6. Fully extend the seat belt webbing. Verify that the seat belt webbing does not have any twists or tears.
  7. Allow the seat belt webbing to retract. Verify that the seat belt webbing returns freely and completely back into the retractor.
  8. Snap the seat belt latch plate into the buckle.
  9. Sharply tug on the seat belt latch plate and the buckle. Verify that the seat belt latch plate and the buckle remain locked when tugged.
  10. Push the button on the buckle. Verify that the seat belt latch plate releases easily from the buckle. Verify that the button returns to its original position.

Repeat the inspection procedure, steps 2-10, from the front passenger seat.

Test the function of the automatic locking child restraint feature, if equipped

  1. To engage the automatic locking feature, pull the belt to the fully extended position. Allow the belt to retract to the proper position for the child seat and fasten the latch plate to the buckle. As the belt retracts, a ratcheting sound should be heard.
  2. To disengage the automatic locking feature, allow the belt to retract to the fully stowed position. Before the belt is completely stowed, the cinch feature will reset, the ratcheting sound will stop and the belt will extract freely.

Perform the following steps in order to inspect the center seat belts

  1. Verify that the center seat belts are accessible.
  2. Verify that the center seat belts have no twists or tears in the webbing.
  3. Snap the center seat belt latch plate into the buckle.
  4. Sharply tug on the seat belt latch plate and the buckle. Verify that the seat belt latch plate and the buckle remain locked when tugged.
  5. Push the button on the buckle. Verify that the seat belt latch plate releases easily from the buckle. Verify that the button returns to its original position.

Repeat the inspection procedure, steps 2-10, from the rear seats.

Repeat the center seat belt inspection procedure, steps 1-5, from the rear seat.

Circuit/System Description

The inflatable restraint sensing and diagnostic module (SDM) sends the status of the driver and passenger seat belt switch to the instrument panel cluster (IPC) via a serial data communication message. If the seat belt is unfastened, the SDM will send a message to the IPC to illuminate the fasten safety belt indicator for 72 seconds or until the seat belt is fastened.

Front Seat Belt System Operation

CAUTIONTo help avoid personal injury from unrepaired crash damage to a restraint system, perform the seat belt check for each seat belt system. Replace the seat belt system if there is any doubt about the condition of system components.
  1. The front Seat Belt System includes a driver and\or passenger seat belt retractor and buckle.
  2. The front Seat Belt System, includes a seat belt switch in the LF and RF seat buckle which controls the fasten safety belt indicators and a tone alarm. When the LF/RF seat belt is buckled, the LF/RF door is closed, and the ignition switch is in the ON position, the following events will not occur: The tone alarm will not operate. The fasten safety belts indicator will not operate.
  3. When the LF/RF seat belt is not buckled, the LF/RF door closed, and the ignition switch is in the RUN position, the following events will occur: The tone alarm will operate for 4 to 8 seconds and then turn OFF. The fasten safety belts indicator will operate for 20 seconds, until the LF/RF seat belt is buckled. Then the fasten safety belts indicator will flash for an additional 55 seconds before turning OFF. To diagnose a failure of the fasten safety belts indicator refer to «Symptoms - Seat Belts»(ref-268085-S10469232222007101800000) .
