Seat Belt Buckle - Passenger
| Connector Part Information OEM: 12048457 Service: 12058709 Description: 2-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12059894/5 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Seat Belt Buckle - Passenger Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | BK | 2644 | Seat Position Sensor Return |
| B | BK | 2484 | Passenger Seat Belt Switch Signal |
Seat Belt Buckle - Passenger Connector Terminal Identification
Begin the system diagnosis by reviewing the Seat Belt System Description and Operation . Reviewing the Description and Operation will help identify the correct symptom diagnostic procedure when a malfunction exists. The Description and Operation will also assist in determining if the condition described by the customer is normal system operation. Refer to Symptoms - Seat Belts in order to identify the correct procedure for diagnosing the system and where the procedure is located.
Emergency Locking Retractors
| CAUTION | Perform this test in an area clear of other vehicles or obstructions. Do not conduct this test on the open road. A large, empty parking lot is suitable. Failure to observe this precaution may result in damage to the vehicle and possible personal injury. |
Scheme 24
- Fasten the seat belts, an assistant is needed when the retractor under test is not part of the driver seat belt.
- Accelerate the vehicle slowly to 16 km/h (10 mph) and apply the brakes firmly.
- Verify that the seat belt locks when braking firmly.
- If the belt does not lock, proceed with the following steps. Remove the seat belt retractor assembly. Tilt the seat belt retractor slowly. Ensure that the seat belt webbing can be pulled from the retractor at an inclination of 15 degrees or less and cannot be pulled from the retractor at an inclination of 60 degrees or more. If the seat belt retractor does not operate as described, replace the retractor assembly. Refer to the following procedures: «Front Seat Belt Replacement»(ref-268085-S34485328942007101800000) «Rear Seat Belt Replacement»(ref-268085-S41344090412007101800000) «Seat Belt Retractor Replacement - No. 1 Center Rear»(ref-268085-S36652696602007101800000)
| IMPORTANT | Review the Seat Belt System Description and Operation in order to familiarize yourself with the system functions. Refer to Seat Belt System Description and Operation . |
Intermittent
Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .
Reference Information
Schematic Reference
Seat Belt Schematics
Connector End View Reference
Seat Belt Connector End Views
Electrical Information Reference
- «Circuit Testing»(ref-268113-S34300255622007101800000)
- «Connector Repairs»(ref-268113-S12163038632007101800000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-268113-S21569870072007101800000)
- «Wiring Repairs»(ref-268113-S39498775722007101800000)
Repair Procedures
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «Front Seat Belt Buckle Replacement»(ref-268085-S02847573722007101800000)
- «Control Module References»(ref-268114-S32850434302007101800000) for SDM and IPC replacement, setup, and programming
Seat Belt Service Precautions
- Do not bleach or dye the seat belt webbing. Use only the following items in order to clean the seat belt webbing: A mild soap and water solution A soft brush or cloth
- Keep sharp edges and damaging objects away from the seat belts. Do not bend or damage any part of the seat belt buckle or latch plate. Replace any seat belts that are cut or otherwise damaged in any manner.
- Use only the correct seat belt anchor fasteners. Begin tightening the seat belt anchor fasteners by hand in order to ensure that the bolt is threaded straight. Tighten the correct seat belt anchor nut to the correct torque value. Refer to «Fastener Tightening Specifications»(ref-268085-S31611115872007101800000) .
- Some seat belts and retractors require service as a set with service replacement components only. Do not repair individual components that require service as a set.
- Verify that the replacement part number is correct for the vehicle at that seating position. Do not substitute a seat belt from a different seating position.
- Replace any seat belts that have a visible Caution label instructing replacement.
- Some seat belts have an Energy Management Loop. An Energy Management Loop is an overlap of the seat belt webbing that is stitched together. If any separated stitching exists, replace the seat belt.
Child Seat Restraint System
| CAUTION | A child in a rear-facing child restraint can be seriously injured if the right-front passengers air bag inflates. This is because the back of a rear-facing child restraint would be very close to the inflating air bag. NEVER use a rear-facing child restraint in this vehicle. If a forward-facing child restraint is suitable for your child, ALWAYS move the front passenger seat as far back as it will go and then install the child restraint. Be sure the child restraint position does not conflict with any additional requirements provided by the manufacturer. For more information, refer to the vehicle owners manual and the instruction that came with the child restraint. |
The child seat may only be used in a forward facing seating location. The child seat should be installed and secured according to the manufacturers directions. If the child seat has a top strap it will need to be anchored. Refer to Child Restraint Tether Anchor Replacement - Rear No. 1 .
All vehicles are equipped with a dual-mode type retractor with emergency and automatic locking features. The automatic locking feature is for restraint of a child seat. The child seat can be secured by pulling the seat belt all the way out to lock it. Then, tighten the seat belt around the child seat.
