Engine Mechanical - 5.3L: Overhaul Saab 9-7X I

Oil Pump Assemble

1. Install the driven gear (412) into the pump housing (413). Install the driven gear with the orientation mark facing the pump cover. IMPORTANT: Prior to assembling the oil pump, coat all wear or internal surfaces with clean engine oil.
2. Install the drive gear (410) into the pump housing.
3. Install the oil pump cover (409).
4. Install the oil pump cover bolts (408). Tighten: Tighten the oil pump cover bolts to 12 N.m (106 lb in). NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
5. Install the relief valve (414).
6. Install the relief valve spring (415).
7. Install the relief valve plug (416). Tighten: Tighten the relief valve plug to 12 N.m (106 lb in).
8. Inspect the oil pump for smooth operation by rotating the drive gear.

Service Prior to Assembly

1. Dirt or debris will cause premature wear of the rebuilt engine. Clean all components. Refer to «Cleanliness and Care»(ref-268156-S06496902282007101800000) .
2. Use the proper tools to measure components when inspecting for excessive wear. Components that are not within the manufacturers specifications must be repaired or replaced.
3. When the components are installed into an engine, return the components to their original location, position and direction. Refer to «Separating Parts»(ref-268156-S42784542542007101800000) .
4. During assembly, lubricate all moving parts with clean engine oil. This provides initial lubrication when the engine is first started.

Scheme 561

Scheme 562

1. Apply a 3.175 mm (0.125 in) bead of sealant GM P/N 12346004 (Canadian P/N 10953480) to the engine block coolant heater sealing washer (115), if applicable. Refer to «Sealers, Adhesives, and Lubricants»(ref-268156-S21759060742007101800000) . IMPORTANT: Engine block plug, oil gallery, and coolant sealing washers may be used again if not bent, scored or otherwise damaged.
2. Install the engine block coolant heater (114) to the engine block. Tighten: Tighten the block coolant heater to 50 N.m (37 lb ft). NOTE: Refer to «Fastener Notice»(ref-268087-S07010920292007101800000) .
3. Apply a 3.175 mm (0.125 in) bead of sealant GM P/N 12346004 (Canadian P/N 10953480) to the engine block right rear coolant drain hole plug sealing washer.
4. Install the engine block right rear coolant drain hole plug. Tighten: Tighten the block right rear coolant drain hole plug to 60 N.m (44 lb ft).
5. Apply a 3.175 mm (0.125 in) bead of sealant GM P/N 12346004 (Canadian P/N 10953480) to the engine block left front oil gallery plug sealing washer (117).
6. Install the engine block left front oil gallery plug (116). Tighten: Tighten the block left front oil gallery plug to 60 N.m (44 lb ft).
7. Apply a 3.175 mm (0.125 in) bead of sealant GM P/N 12346004 (Canadian P/N 10953480) to the engine block left rear oil gallery plug sealing washer (113).
8. Install the engine block left rear oil gallery plug (112). Tighten: Tighten the block left rear oil gallery plug to 60 N.m (44 lb ft).
9. Inspect the engine block rear oil gallery plug and O-ring seal. If the O-ring seal on the plug is not cut or damaged, the rear oil gallery plug may be used again.
10. Lubricate the O-ring seal with clean engine oil.
11. Install the O-ring seal onto the plug.
12. Install the engine block rear oil gallery plug into the oil gallery bore. A properly installed block plug will protrude 0.8-1.4 mm (0.0315-0.055 in) beyond the rear face of the block.
13. Apply threadlock GM P/N 12345382 (Canadian P/N 10953489) to the sides of the NEW front oil gallery plug (101).
14. Install a NEW engine block front oil gallery plug. Install the plug into the oil gallery bore 2.2-2.8 mm (0.0086-0.011 in) below flush.
15. Install the left side knock sensor (718) and bolt (739). Tighten: Tighten the bolt to 20 N.m (15 lb ft).
16. Install the right side knock sensor (718) and bolt (739). Tighten: Tighten the bolt to 20 N.m (15 lb ft).

Piston and Connecting Rod Assembly

The pistons are cast aluminum. The pistons use 2 compression rings and 1 oil control ring assembly. The piston is a low friction, lightweight design with a flat or recessed top and barrel shaped skirt. The piston pins are chromium steel and are a full-floating design. The connecting rods are powdered metal. The connecting rods are fractured at the connecting rod journal and then machined for the proper clearance. All applications use a piston with a graphite coated skirt. The piston and pin are to be serviced as an assembly.

Valve Rocker Arm Cover Assemblies

The valve rocker arm covers are cast aluminum and use a pre-molded silicon gasket for sealing. Mounted to each rocker cover are the coil and bracket assemblies. Incorporated into the left cover is the positive crankcase ventilation (PCV) system dirty air passage. Incorporated into the right cover are the oil fill tube and the PCV fresh air passage.

Disassembly and Assembly Procedure Revisions

The timing chain and sprocket installation procedure has been revised. Refer to Timing Chain and Sprockets Installation .

Assembling Components

1. When assembling components, use only the sealant specified or equivalent in the service procedure. NOTE: Refer to «Sealant Notice»(ref-268087-S13037664082007101800000) .
2. Sealing surfaces should be clean and free of debris or oil.
3. Specific components such as crankshaft oil seals or valve stem oil seals may require lubrication during assembly.
4. Components requiring lubrication will be identified in the service procedure.
5. When applying sealant to a component, apply the amount specified in the service procedure.
6. Tighten bolts to specifications. Do not overtighten.
