Scheme 509
Scheme 510
| Callout | Component Name |
|---|---|
| 1 | Lower Console |
| 2 | Automatic Transmission Shift Lock Actuator |
Scheme 511
| Connector Part Information OEM: 12064762 Service: 12125665 Description: 6-Way F Metri-Pack 150 Series Unsealed (L-GY) |
|---|
| Terminal Part Information Pins: A-C, E-F Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Automatic Transmission Shift Lock Actuator Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | BK | 150 | Ground |
| B | RD | 275 | A/T Shift Lock Control Switch Supply Voltage |
| C | PU | 961 | Remote Shift Selector Signal |
| D | Not Used | ||
| E | OG | 1135 | A/T Shift Lock Control Solenoid Supply Voltage |
| F | YE | 1020 | Ignition 3 Voltage |
Automatic Transmission Shift Lock Actuator Connector Terminal Identification
Begin the system diagnosis with Diagnostic System Check - Vehicle . The Diagnostic System Check - Vehicle will provide the following information
- The identification of the control modules which command the system
- The ability of the control modules to communicate through the serial data circuit
- The identification of any stored DTCs and their status
The use of the Diagnostic System Check - Vehicle will identify the correct procedure for diagnosing the system and where the procedure is located.
| IMPORTANT | Review the system operation in order to familiarize yourself with the system functions. Refer to Automatic Transmission Shift Lock Control Description and Operation . |
