Transmission Fluid Checking

1. Start the engine and operate the vehicle for 15 minutes or until the transmission fluid reaches an operating temperature of 82-93°C (180-200°F).
2. Park the vehicle on a level surface.
3. With your foot on the brake, move the shift lever through each gear range. Pause for about 3 seconds in each range, ending in PARK.
4. Apply the parking brake and let the engine idle for 3 minutes.
5. Remove the transmission fluid level indicator. Wipe the indicator clean. Insert the indicator. Give the indicator a full twist in order to close.
6. Wait 3 seconds and remove the indicator.
7. Read both sides of the indicator. The fluid must be within the hot cross-hatched area using the lowest level reading.

Transmission Fluid Checking

Scheme 492

Possible Points of Fluid Leaks

Transmission Oil Pan

1. Incorrectly tightened oil pan bolts
2. Improperly installed or damaged oil pan gasket
3. Damaged oil pan or mounting face
4. Incorrect oil pan gasket

Case Leak

1. Damaged or missing fill tube seal
2. Mislocated fill tube bracket
3. Damaged vehicle speed sensor seal
4. Damaged manual shaft seal
5. Loose or damaged oil cooler connector fittings
6. Worn or damaged propeller shaft oil seal
7. Loose line pressure pipe plug
8. Warped
9. Distorted torque converter housing
10. Porous casting

Leak at the Torque Converter End

1. Converter leak in the weld area
2. Converter seal lip cut. Check the converter hub for damage
3. Converter seal bushing moved forward and damaged
4. Converter seal garter spring missing from the seal
5. Porous casting of the transmission case or the oil pump

Leak at the Vent Pipe or the Fluid Fill Tube

1. Overfilled system
2. Water or coolant in the fluid-the fluid will appear milky.
3. Transmission case porous
4. Incorrect fluid level indicator
5. Plugged vent
6. Drain-back holes plugged
7. Mispositioned oil pump to case gasket, if equipped

Scheme 493

Cooler Flow Check and Flushing Steps

1. Machine Set-up
2. Determine Minimum Flow Rate
3. Back Flush
4. Forward Flush
5. Flow Test
6. Code Recording Procedure
7. Clean-up

Tools Required

1. J 35944-200 Cooler Flushing Adapter. See «Special Tools»(ref-268097-S09155325162007101800000) .
2. J 45096 Transmission Oil Cooling System Flush and Flow Test Tool. See «Special Tools»(ref-268097-S09155325162007101800000) .
3. Shop air supply with water/oil filters, regulator and pressure gage-minimum 90 psi
4. Eye protection
5. Rubber gloves

Scheme 494

Scheme 495

Scheme 496

Scheme 497

1. Verify that the main power switch (1) is in the OFF position.
2. Place the main function switch (2) in the IDLE position.
3. Connect J 45096 to the vehicle 12-volt DC power source by connecting the red battery clip to the positive (+) battery post on the vehicle and connect the negative (-) lead to a known good chassis ground. See «Special Tools»(ref-268097-S09155325162007101800000) .
4. Turn the main power switch to the ON position.
5. Fill the supply tank with Dexron®VI, or equivalent, through the fill port. NOTE: Do not overfill the supply vessel. Damage to the unit may result. To verify the fluid level, view the LCD screen display while filling the unit, to ensure the fluid level does not exceed 30 L (32 qt).
6. Install and tighten the fill cap.
7. Connect a shop air supply hose to the quick-disconnect on the rear panel marked SUPPLY AIR.

Scheme 498

Scheme 499

1. From the machine display, identify the temperature of the automatic transmission fluid that is stored in the supply vessel of J 45096 . See «Special Tools»(ref-268097-S09155325162007101800000) .
2. Determine whether the transmission oil cooler is steel or aluminum by using a magnet (1) at the cooler flange (2) at the radiator.
3. Refer to the table below. Using the temperature from step 1, locate on either the Steel MINIMUM Flow Rate table or the Aluminum MINIMUM Flow Rate table the minimum flow rate in gallons per minutes (GPM). Record the minimum flow rate in GPMs and the supply fluid temperature for further reference. Example:: Fluid temperature: 24°C (75°F) Cooler type: Steel The MINIMUM flow rate for this example would be 0.8 GPM.
4. Inspect transmission oil cooler lines for damage or kinks that could cause restricted oil flow. Repair as needed and refer to the appropriate GM service manual procedures.

Minimum Flow Rate in Gallons Per Minute (GPM)

Scheme 500

Scheme 501

Scheme 502

Scheme 503

1. Connect the J 45096 adapters (1) to the vehicle transmission oil cooler supply and return lines at the transmission, may require J 35944-200 . See «Special Tools»(ref-268097-S09155325162007101800000) .
2. Connect the black supply hose (1) to the return line, top connector of the transmission, and the clear waste hose (2) to the feed line, bottom connector of the transmission, to the vehicle cooler lines. This is the reverse flow backflush direction.
3. Turn the main function switch to the FLUSH position. Allow the machine to operate for 30 seconds.
4. Turn the main function switch to the IDLE position and allow the supply vessel pressure to dissipate.

Scheme 504

Scheme 505

1. Disconnect the supply and waste hoses from the vehicle cooler lines. Reverse the supply and waste hoses to provide a normal flow direction.
2. Turn the main function switch to the FLUSH position and allow the machine to operate for 30 seconds.

Scheme 506

1. Turn the main function switch to the FLOW position and allow the oil to flow for 15 seconds. Observe and note the flow rate. This is the TESTED flow rate. IMPORTANT: If the flow rate is less than 0.5 gpm, the LCD displays an error message. Refer to the Troubleshooting section of the operation manual.
2. Compare the TESTED flow rate to the MINIMUM flow rate information previously recorded. If the TESTED flow rate is equal to or greater than the MINIMUM flow rate recorded, the oil cooling system is functioning properly. Perform Code Recording Procedure. If the TESTED flow rate is less than the MINIMUM flow rate previously recorded, repeat the back flush and forward flush procedures.
3. If the TESTED flow rate is less than the MINIMUM flow rate after the second test, perform the Code Recording Procedure. Replace the transmission oil cooler. Connect the supply and waste hoses to the cooler lines in the normal flow direction. Perform the Flow Test. Perform the Code Recording Procedure.

Scheme 507

1. Turn the main function switch to the CODE position. IMPORTANT: If power is interrupted prior to the recording of the 7-character code, the code will be lost and the flow rate test will need to be repeated. The flow test must run for a minimum of 8-10 seconds and be above 0.5 gpm for a code to be generated.
2. Record TESTED flow rate, temperature, cycle and seven-character flow code information on the repair order.

Clean-Up

1. Turn the main function switch to the IDLE position and allow the supply vessel pressure to dissipate.
2. Turn the main power switch to the OFF position.
3. Disconnect the supply and waste hoses and the 12-volt power source from the vehicle. IMPORTANT: A small amount of water may drain from the bottom of the unit when the air supply is disconnected. This is a normal operation of the built-in water separator.
4. Disconnect the air supply hose from J 45096 . See «Special Tools»(ref-268097-S09155325162007101800000) .
5. Dispose of the waste oil in accordance with all applicable federal, state, and local requirements.

Forward Flush

1. Disconnect both hoses (1 and 2) from the oil cooler pipes and connect them to the opposite oil cooler pipe. This will allow the oil cooler and pipes to be flushed in the normal flow direction.
2. Repeat Step 6 and 7 of the Back Flush.
3. Release the trigger (1) of the J 35944-A and allow water only to rinse the oil cooler and pipes for 1 minute. See «Special Tools»(ref-268097-S09155325162007101800000) .
4. Turn the J 35944-A water supply valve (3) to the OFF position and turn OFF the water supply at the faucet. See «Special Tools»(ref-268097-S09155325162007101800000) .
5. Attach the shop air supply to the flushing system feed air valve (2) on the J 35944-A and blow out the water from the oil cooler and pipes. See «Special Tools»(ref-268097-S09155325162007101800000) . Continue, until no water comes out of the discharge hose.

Scheme 508

1. Disconnect the hose from the oil cooler pipe. Connect the oil cooler feed pipe, bottom connector, to the transmission for normal flow. IMPORTANT: The Flow Test must be performed after the flush to ensure that all flushing solution and water is removed from the oil cooling system.
2. Clip the discharge hose (1) to an empty oil container.
3. Confirm the transmission is filled with automatic transmission fluid. Refer to «Fluid Capacity Specifications»(ref-268097-S40852942872007101800000) for the correct automatic transmission fluid capacity.
4. Start the engine with the transmission in PARK range and run for 30 seconds after fluid begins to flow from the discharge hose (1). A minimum of 1.9 L (2 qt) must be discharged during this 30 second run time.
5. If the fluid flow meets or exceeds 1.9 L (2 quarts) in 30 seconds, connect the oil cooler feed pipe to the bottom connector on the transmission.
6. If fluid flow is less than 1.9 L (2 qt) in 30 seconds, perform the following diagnosis: Disconnect the J 35944-A discharge hose (1) from the oil cooler return pipe. See «Special Tools»(ref-268097-S09155325162007101800000) . Disconnect the oil cooler feed pipe at the radiator. Connect the J 35944-A discharge hose (1) to the oil cooler feed pipe, radiator end. See «Special Tools»(ref-268097-S09155325162007101800000) . Clip the discharge hose (1) onto the oil drain container. Start the engine with the transmission in PARK range and run for 30 seconds after fluid begins to flow from the discharge hose (1). A minimum of 1.9 L (2 qt) must be discharged during this 30 second run time.
7. If the amount of transmission fluid flow remains less than 1.9 L (2 qt) in 30 seconds, inspect the oil cooler feed pipe, bottom connector, for restrictions or damage. If no condition is found with the feed pipe, bottom connector, inspect the transmission.
