Connected components
| Via crimp J43 | |
|---|---|
| 25 | Switch, hazard warning flashers |
| 61 | Switch, windshield wipers |
| 61a | Switch, rear window wiper |
| 91 | Lamp, lighting, selector lever position indicator |
| 252R | Switch, electrically heated rear seat |
| 375 | Connection, mobile phone |
| 439 | Solenoid, selector lever, SHIFT LOCK |
| 445 | Data link connector, 16-pin, CARB |
| 615LH | Switch, seat ventilation, left-hand seat |
| 615RH | Switch, seat ventilation, right-hand seat |
| Via crimp J45 | |
| 48F | Cigarette lighter, front |
| 48R | Cigarette lighter, rear (LHD) |
| 148F | Lamp, lighting, ashtray/cigarette lighter, front |
| 148R | Lamp, lighting, cigarette lighter, rear (LHD) |
| 216 | Control module, ACC |
| 220 | Fan control module |
| 504 | Control panel, heating and ventilation |
TOOLS COMPATIBILITY-GROUNDING POINT G41P
Scheme 144
Scheme 145
Location: On the left-hand ground screw in the middle of the knee member (in the interior).
| 540 | Main instrument display panel |
|---|---|
| Via crimp J41 | |
| 445 | Data link connector, 16-pin, CARB |
| 449 | Switch, TCS |
| 506 | Switch, WINTER |
| 535 | Transmission fluid temperature sensor |
| 537 | Switch, SPORT |
| 541 | SID |
TOOLS COMPATIBILITY-GROUNDING POINT G41S
Scheme 146
Scheme 147
Location: On right-hand side of knee member
A. Connected components in LHD car
| Via crimp J46 | |
|---|---|
| 19 | Lamp, glove box lighting |
| 353 | Main unit, audio system |
| 354 | Amplifier, audio system |
| 359RH | Lamp, RH vanity mirror lighting |
| 613FL | Lamp, LH front floor lighting |
| 613FR | Lamp, RH front floor lighting |
| 650 | Rain sensor |
| 637 | Control module, ADM |
TOOLS COMPATIBILITY-GROUNDING POINT G42
B. Connected components in RHD car
| G30 | Grounding point in engine bay on side panel in front of LH wheel housing |
|---|---|
| Via crimp J42 | |
| 10 | Switch, lights |
| 21 | Relay, ignition switch |
| 42 | Level switch, brake fluid |
| 242 | Level switch, coolant |
| 628 | Control module, DICE |
| Via crimp J48 | |
| 62F | Motor, windshield wipers |
| 88 | Switch, fog lights |
| 276 | Bonnet switch, anti-theft alarm |
| 282 | Switch, headlamp beam length adjustment |
| 405 | Relay, reversing lights, automatic |
| 453 | Motor, coolant circulation pump |
| 461 | Connection, electronic road toll |
TOOLS COMPATIBILITY-GROUNDING POINT G42
Scheme 148
Scheme 149
Location: On the right-hand ground screw in the middle of the knee member (in the interior).
| 502 | Control module, TCM |
TOOLS COMPATIBILITY-GROUNDING POINT G43
