Automatic Transmission - 9-5: Overview Saab 9-5 I рестайлинг

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

Scheme 281

1. Place drapes over the wings to keep the paintwork clean and protect it from damage.
2. Remove the grille.
3. Remove the cover from the intake manifold.
4. Remove the battery cover, battery and battery tray.
5. Unplug the 16-pin and 10-pin connectors. The connectors are mounted in a holder.
6. Remove the breather hose from the transmission. The hose is positioned differently depending on engine variant.
7. Remove the gear selector arm from the transmission. The selector lever must be in position 1.
8. Remove the clamp and press out the shifting cable, using a suitable screwdriver.
9. V6: Detach the cable channel from the engine and transmission casing.
10. Remove the three upper bolts for the gearbox. Use «87 92 723 ACCESS TOOL, BOLT IN JOINT BETWEEN AUTOMATIC TRANSMISSION AND ENGINE»(ref-212247-S40735966362005122300000) to facilitate removing the rearmost bolt.
11. Clean the area round the dipstick tube where it enters the transmission.
12. Remove the dipstick tube and plug the hole.
13. Unplug the oxygen sensor connectors.
14. Remove the nut for the rear engine mounting.
15. Undo the three bolts securing the rear engine cushion, leaving the bolts in place.
16. V6: Fit lifting lugs, one on the rear cylinder head and one on the front cylinder head (undo the existing bolt first).
17. Put «83 94 850 LIFTING BEAM»(ref-212247-S16617664292005122300000) in position and relieve the weight on the engine and transmission. IMPORTANT: Place suitable protective pads or the like under the feet of the lifting beam to avoid damaging the paintwork.
18. Raise the car.
19. Remove the front wheels.
20. Remove covers.
21. Dismantle the front exhaust system. Be careful with the oxygen sensors.
22. 4 cyl: Dismantle the rear engine mounting and engine pad.
23. Remove the screws securing the steering gear.
24. Remove the two rear clamps securing the power steering delivery pipe to the subframe. Remove the A/C pipes from the plastic clips on the subframe at the same time.
25. Remove the air cleaner casing from the subframe.
26. 4-cyl: Detach the engine oil cooler from the charge air cooler.
27. Fit a Strap part number «83 95 212 STRAP»(ref-212247-S10294142822005122300000) , round the radiator core and radiator crossmember.
28. Remove the bolts securing the outer ball joints to the steering knuckle housing on both sides.
29. Detach the upper anti-roll bar ball joints. Use a 17 mm spanner to prevent the boot from twisting. If the spanner is too wide to fit between the boot and the suspension strut, it must be ground narrower.
30. Remove the torque arm from the subframe and remove the rear support plates.
31. Assemble the holder, using tools 83 95 170, 83 95 196 and «83 95 188 BASIC FIXTURE»(ref-212247-S07420972802005122300000) . «83 95 311 TROLLEY LIFT»(ref-212247-S16202124172005122300000) Lifting trolley.
32. Position the lifting trolley with lifting table and holder under the subframe. Raise the lifting table, being careful to position it correctly.
33. Remove the last 4 bolts securing the subframe.
34. Lower the subframe approx. 5 cm so that the two front clamps holding the power steering delivery pipe in place can be removed. Remove the clamps, lower the subframe and move the lifting trolley out of the way.
35. 4-cyl: Remove the splash plate (secured with two bolts to the transmission casing) to access the torque converter mounting on the drive plate. V6: Remove the plug (under the starter motor) covering the bolts to the torque converter.
36. Undo the 6 bolts securing the torque converter to the drive plate. Rotate the plate together with the pulley. NOTE: The crankshaft must be rotated to make all the bolts accessible.
37. Press the torque converter towards the gearbox and fit «87 92 574 HOLDER»(ref-212247-S03891516862005122300000) Holder to keep it in place while the gearbox is removed.
38. Disconnect the ground leads.
39. Remove the torque arm with bracket.
40. Drain the transmission fluid, fit the drain plug. Tightening torque: 40 Nm (30 lbf ft)
41. Disconnect the oil cooler inlet and outlet hoses. Plug the inlet and outlet passages on the transmission and also plug the hoses. Use plug no. (10) 91 32 929 and seal no. (10) 91 32 937.
42. Loosen the left drive shaft using «87 92 616 REMOVING TOOL, DRIVE SHAFTS»(ref-212247-S41046422222005122300000) .
43. Suspend the shaft by means of a cable tie.
44. Lower the car to the floor.
45. Remove the left-hand engine pad.
46. Lower the unit approx. 100 mm so that the transmission clears the structural member. Remove the transmission bracket from the transmission.
47. Raise the car.
48. Fit lifting tool MKM-886, part no. «87 92 608 HOLDER FOR SINGLE-COLUMN LIFT»(ref-212247-S15173240482005122300000) , onto a pillar-type jack. Adjust the tool so that it centers on the lifting lug on top of the transmission casing and secure it to the lifting lugs as shown in the illustration. Use bolts that are approx. 20 mm longer than the removed ones.
49. Remove the remaining bolts securing the transmission to the engine.
50. Pull out and lower the transmission casing. IMPORTANT: The pillar-type jack may tip over. Exercise care.
51. Lift down the gearbox from the pillar jack using an engine hoist and «87 92 442 LIFTING CABLE»(ref-212247-S08596964052005122300000) while removing the lifting tool from the gearbox.

Scheme 282

When fitting a new transmission, transfer the holder for the torque converter from the new transmission to the old one.

Scheme 283

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

Scheme 294

Scheme 295

Scheme 296

1. Turn the torque converter so that the bolt holes line up with the holes in the drive plate. Fit «87 92 574 HOLDER»(ref-212247-S03891516862005122300000) to keep the torque converter in place while fitting.
2. Make sure the two guide sleeves are on the engine and apply anti-corrosion agent to the sleeves. Fit the new drive shaft seals, lubricate them before fitting.
3. Lift up the gearbox using an engine hoist and «87 92 442 LIFTING CABLE»(ref-212247-S08596964052005122300000) .
4. Fit Lifting tool MKM-88687 92 608 onto a pillar-type jack.
5. Adjust the tool so that it centers on the lifting lug on top of the transmission casing and secure it to the transmission. IMPORTANT: The pillar-type jack may tip over. Exercise care.
6. Fit Protective collar «83 95 162 PROTECTIVE COLLAR, DRIVE SHAFTS»(ref-212247-S01603638032005122300000) in the right-hand shaft seal in the transmission to protect the seal when the transmission is being fitted. Lubricate the seal.
7. Place the transmission in position. IMPORTANT: Push the transmission into place until approx. 20 mm remains and then remove tool «83 95 162 PROTECTIVE COLLAR, DRIVE SHAFTS»(ref-212247-S01603638032005122300000) .
8. Tighten the bottom bolts between the engine and the transmission. Tightening torque: 75 Nm (55 lbf ft) V6: Tighten the bolts between the oil pan and the transmission. Tightening torque: 47 Nm (34 lbf ft)
9. Remove the lifting beam from the transmission and move the jack out of the way. Refit the bolts in the gearbox. Tightening torque 24 Nm (18 lbf ft)
10. Lower the car and fit the engine pad mounting on the gearbox. Tightening torque: 84 Nm (62 lbf ft) Lift the unit. Do not lift higher than necessary, it will only make fitting the subframe more difficult. Fit the bolts that secure the engine pad to the body. Start with the small bolt. Tightening torque, bolts: 63 Nm (46 lbf ft) Tightening torque, nut: 84 Nm (62 lbf ft)
11. Fit protective collar «83 95 162 PROTECTIVE COLLAR, DRIVE SHAFTS»(ref-212247-S01603638032005122300000) in the sealing ring. Lubricate the sealing ring.
12. Make sure that the drive shaft is clean and then align it with the tool. IMPORTANT: Insert all but 20 mm of the drive shaft in the transmission and then withdraw the tool before the shaft's sealing surface reaches the shaft seal.
13. Push in the rest of the shaft until the circlip clicks in.
14. Raise the car.
15. Remove tool «87 92 574 HOLDER»(ref-212247-S03891516862005122300000) , which is keeping the torque converter in place, and press it against the drive plate. Fit the plug.
16. Apply threadlock, LOCTITE 242 part no 74 96 268 to the bolts that secure the torque converter to the drive plate. NOTE: Use the original bolts and their washers. If excessively long bolts are fitted, the torque converter will be damaged. The length of the bolts should be 10 mm, measured from the washer.
17. Fit the 6 bolts without tightening them. Rotate the engine with the pulley
18. Tighten them when they are all fitted in place. Tightening torque: 30 Nm (22 lbf ft)
19. 4-cyl: Fit the splash plate. V6: Fit the plug.
20. Fit the oil cooler hoses. The hoses should be horizontal so that they do not chafe against the subframe. Use new seals greased with petroleum jelly. Tightening torque: 27 Nm (20 lbf ft)
21. Fit the bracket for the torque arm on the transmission.
22. Connect the ground cable to the bracket and to the transmission.
23. Place the subframe on the lifting trolley and raise it slightly.
24. Fit the power steering delivery pipe's clamps.
25. Raise the subframe and guide it into position by means of the holder's studs. At the same time, guide the following into place: The radiator core's studs The AC pipes Outer ball joints
26. Fit the bolts to the subframe and fit the rear support plates. Adjust the subframe so that the guide pins on the holder are aligned with the holes in the body before tightening the bolts. Tightening torques: Subframe bolts 100 Nm (74 lbf ft) + 45 ° Support plate bolts: 60 Nm (44 lbf ft) NOTE: Make sure that the transmission's oil cooler hoses do not rest against the subframe.
27. Remove the lifting trolley.
28. Fit the bolts securing the outer ball joint to the steering knuckle housing.
29. Tighten the bolts. Tightening torque 60 Nm + 90 ° (44 lbf ft + 90°)
30. Tighten the anti-roll bar link. If the wrench used to hold it is too wide to fit between the boot and the suspension strut, it must be ground narrower. Alternatively, hold the hexagonal pin with a socket. Tightening torque 84 Nm (62 lbf ft) Tightening torque, nut with steel lock: 95 Nm (66 lbf ft)
31. Fit the steering gear bolts and tighten them. Tightening torque 90 Nm (66 lbf ft)
32. Remove the strap round the radiator core.
33. 4-cyl: Fit the engine oil cooler. Tighten the air filter housing.
34. Fit the rear engine cushion in place. Screw in the front bolts but do not tighten them.
35. Bolt the rear engine mounting in place. Tightening torque: 70 Nm (52 lbf ft)
36. Tighten the torque arm on the subframe Tightening torque 26 Nm (19 lbf ft)
37. Fit the front exhaust system. Tightening torque 4-cyl: 25 Nm (18.4 lbf ft) Tightening torque V6: to the turbo 24 Nm (18 lbf ft) to the exhaust manifold 40 Nm (30 lbf ft)
38. Run the wiring for the oxygen sensor into the engine bay.
39. Fit the covers.
40. Lower the car to the floor.
41. Remove the lifting beam. V6: Remove the lifting tool and its mountings from the engine.
42. Connect the oxygen sensors
43. Shake the unit to ensure there is no tension in the engine pads. Tighten the rear engine pad retaining nut and 3 bolts. Tightening torque: bolts 24 Nm (18 lbf ft) Tightening torque: nut 45 Nm (33 lbf ft)
44. Fit the bolts securing the transmission to the engine and tighten them. Tightening torque: 70 Nm (52 lbf ft) V6: Screw on the cable duct to the engine and transmission.
45. Clean and fit the dipstick tube.
46. Fit the transmission's breather hose.
47. Fit the shifting cable to the bracket on the transmission. Fit the clamp.
48. Fit the shifting cable to the selector lever in position P.
49. Check the position of the selector lever and adjust if necessary, see «SELECTOR LEVER»(ref-212247-S22726463052005122300000) .
50. Raise the car. Undo the bolt for the front torque rod and center the rubber pad in the rod. Tighten the bolt. Tightening torque: 47 Nm (34 lbf ft) Lower the car to the floor.
51. Plug in the transmission's connectors.
52. Fit the battery tray, battery and battery cover.
53. Fit the cover over the intake manifold.
54. Fit the grille.
55. Fit the front wheels. Tighten the bolts using a torque wrench. NOTE! the wheels must hang freely Tightening torque: 110 Nm (81 lbf ft)
56. Fill with transmission fluid, Texaco Texamatic DEXRON III (7045 EU, TL1863 US), to the correct level.
57. If the gearbox has been changed and dirt is found in the oil, flushing equipment «87 91 824 FLUSHING EQUIPMENT»(ref-212247-S26279213072005122300000) must be connected before the car is started.
58. Test drive the car with varying engine loads and RPM and read any trouble codes that are generated. Also check the position of the steering wheel when driving straight ahead on a level road. Adjust if needed.
59. Set the right time on the clock.

Brief description of AF30

The AF30 is an electronically-controlled 4-speed automatic transmission with a Lock-up function.

AF30 consists mainly of a 4-speed planetary gear unit, a torque converter with Lock-up clutch, a hydraulic control system and an electronic control system.

The gearbox is controlled by a control module (TCM), which continuously processes information from its own sensors as well as from other control modules. On the basis of this processed information, it controls the transmission hydraulic system.

Compared with conventional hydraulically-controlled transmissions, the AF30 has the following advantages

1. Improved shifting performance and smoother shifting as torque is reduced when shifting takes place.
2. Reduced mechanical stresses on the entire drive train due to torque limitation.
3. Improved fuel economy through a consumption optimizing driving program and Lock Up in 3rd and 4th gear. Under extreme driving conditions when adaptive shifting programs are active, it is possible to drive with Lock Up in 2nd gear instead of 3rd gear without Lock Up. Improved shifting functions that are selected automatically if the temperature of the transmission fluid rises have been introduced. See «ADAPTIVE SHIFTING PROGRAMS»(ref-212247-S38541021672005122300000) .
4. The possibility of selecting different driving programs: NORMAL, SPORT and WINTER.
5. Self-diagnosis and storage of diagnostic trouble codes.

Compared with the earlier AF20/AF22 automatic transmissions, the AF30 incorporates the following modifications

Scheme 297

1. The transmission casing, inner drive units and inboard drive-shaft universal joints are reinforced to withstand the higher torque developed (310 Nm).
2. The TCM sends and receives information from the other control modules in the car through a bus communication system, see «BUS COMMUNICATION»(ref-212247-S25541200692005122300000) .
