General Information: Other Saab 9-5 I рестайлинг 2

Warning messages

Warning, Important and Note

The headings "Warning", "Important" and "Note" occur from time to time in the service information. The importance of the information is indicated by the three different headings and the difference between them is explained below.

Note. Hints and tips on how the work can be carried out in a way that saves both time and effort.

This information is provided as means of improving efficiency, not for reasons of safety.

Market codes

The codes refer to market specifications.

MARKET CODES REFERENCE

Identifying Vehicle Data Specifications. Scheme 1

VEHICLE DATA REFERENCE

B235R

250 hp

Torque And Power Graphs - B235R. Scheme 2

B205E

150 hp

Torque And Power Graphs - B205E. Scheme 3

B235E

185 hp

Torque And Power Graphs - B235E. Scheme 4

B235L

220 hp

Torque And Power Graphs - B235L. Scheme 5

B205E BioPower

The values apply when only E85 is used.

180 hp/280 Nm

B235E BioPower

The values apply when only E85 is used.

210 hp/310Nm

Vehicle Identification Number. Scheme 6

When contacting a Saab dealer it may sometimes be necessary to quote the car's vehicle identification, engine and gearbox numbers.

1. VIN inside windscreen
2. Gearbox number
3. Engine no.
4. Label for colour codes (body and trim) and tyre pressure
5. VIN plate
6. VIN (stamped on body)

Fitting a modification identity plate

As of MY04, the modification identification plate is not factory fitted but is provided in the vehicles Warranty and Service Book. On markets that require the vehicle to be marked, the plate must be fitted as follows

Scheme 7

1. Open the bonnet.
2. Using Teroson FL875, clean the area of the body to which the plate is to be adhered. Remove the protective backing from the plate.
3. Press the plate into place as illustrated. (Scheme 7): Identifying Number Plate
4. Mark the specified box on the plate and close the bonnet.

Warning labels, Japan

Affix the labels with Japanese text on the following places. Clean the surface thoroughly before affixing the label.

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. Refrigerant, part no. 53 26 228: On the opposite side of the circular hole at the original label. (Scheme 8): Identifying Warning Labels On Refrigerant
2. Radiator fan, part no. 53 26 210: Next to the original label. (Scheme 9): Identifying Warning Labels On Radiator Fan
3. Battery, part no. 53 26 327: Vertically at the negative terminal. (Scheme 10): Identifying Warning Labels On Battery
4. LHD: Brake fluid, part no. 53 26 244: Remove the old label, part no. 53 27 606, from the electrical distribution unit and fit the new label in the recess. (Scheme 11): Identifying Warning Labels On Electrical Distribution Unit RHD: Brake fluid, part no. 53 26 343: On the top of the brake fluid reservoir. (Scheme 12): Identifying Warning Labels On Brake Fluid Reservoir
5. Coolant, part no. 53 26 236: On top of the expansion tank's centre section. (Scheme 13): Identifying Warning Labels On Expansion Tank
6. Airbag, part no. 53 26 269: On the dashboard end cover on the passenger side. LHD (Scheme 14): Identifying Warning Labels On Dashboard LHD RHD (Scheme 15): Identifying Warning Labels On Dashboard RHD
7. Jack, part no. 53 26 194: On the jack, over the original marking. (Scheme 16): Identifying Warning Labels On Jack

Identifying Vehicle Identification Number. Scheme 17

VIN NUMBER REFERENCE

Replacing the VIN plate

If the VIN label is damaged in a collision or while repairing damage, the garage can order a replacement label from the spare parts department in Nykoping.

Address

Saab Automobile AB

Arno stores

Logistic / Customer Care - ULU

SE-611 81 Nykoping

SWEDEN

Only authorised Saab garages can obtain replacement labels. This is so that Saab Automobile AB does not participate in providing a stolen car with a new identity.

Identifying Springs And Dampers Label. Scheme 18

EXPLANATION

These designations refer to EPC.

If the entire code or part of the code is missing, contact your importer. The importer should in turn contact Product Improvement Process (PIP) or the Parts Assistance Centre (PAC), who will be able to produce the appropriate details.

Stamp these new details into the VIN plate.

Lubricant

LUBRICATION POINT

Trim and warranty

Saab dealers offer a wide selection of Saab original trim and styling products for your vehicle within the scope of the Saab spare part and accessories programme. All Saab spare parts and accessories are covered by the Saab spare part warranty.

The use of trim and styling products which are not approved and sold by Saab Automobile AB will invalidate the Saab warranty with respect to all affected technical systems and in other respects as defined in the warranty for your particular market. Saab Automobile AB will not accept any liability, as a manufacturer or as a warranty agent, for faults which are caused by trim and styling products which are not approved and sold by Saab Automobile AB.

Identifying 30 12 598 Circlip Pliers. Scheme 19

For dismantling outboard drive shaft CV joint

AUXILIARY TOOL

Identifying 30 31 614 Pop-Rivet Tool. Scheme 20

Powerful tool with step-up gearing. Can also be used for steel rivets.

AUXILIARY TOOL

Identifying 82 93 086 Circlip Pliers ø120-200Mm. Scheme 21

For oil pump circlips, 4 cyl M94-. FACOM 479 A.S.

AUXILIARY TOOL

Identifying 82 93 110 Tool Bag Hook (X6). Scheme 22

AUXILIARY TOOL

Identifying 82 93 706 Wing Guard. Scheme 23

AUXILIARY TOOL

Identifying 82 93 755 Front Guard. Scheme 24

AUXILIARY TOOL

Identifying 85 80 219 Expander Pliers. Scheme 25

For expanding rubber unions and cable entry grommets

AUXILIARY TOOL

Identifying 86 11 790 Toolbox. Scheme 26

TOOLS REFERENCE

Identifying 86 11 808 Longitudinal Wall. Scheme 27

Used together with 86 11 790 TOOLBOX

TOOLS REFERENCE

Identifying 86 11 816 Transverse Wall. Scheme 28

Used together with 86 11 790 TOOLBOX

TOOLS REFERENCE
