To fit

Note. Spray the connector with Kontakt 61, part no. 30 04 520, before plugging in. The bushing must not be lubricated.

  1. Fit the pedal (C). Tightening torque: 24 Nm (17.7 lbf ft).
  2. Fit the accelerator cable (B) to the accelerator pedal.
  3. Lift up the lower panel.
  4. Plug in the connector (A) for the floor lighting.
  5. Fit the lower panel with air duct (C).
  6. Fit the screws (B) for the data link connector.
  7. Raise the cover (A) for the data link connector.

Check and adjust the cable as necessary.

Tightening torque: 24 Nm (17.7 lbf ft).

Scheme 207

Scheme 207: To remove

Scheme 208

Scheme 208

Scheme 209

Scheme 209

Scheme 210

Scheme 210
  1. Open the data link connector cover.
  2. Undo the screws in the data link connector.
  3. Remove the screws and clip securing the lower panel with air duct.
  4. Unplug the connector for the floor lighting.
  5. Lift out the lower panel.
  6. Disconnect the throttle cable from the throttle pedal by sliding back the bush and removing it and the cable.
  7. Remove the engine cover by releasing the holders one at a time starting at the oil filler. Remove the cover above the throttle valve.
  8. Withdraw the cable and its sheathing through the rubber bush in the bulkhead.
  9. Disconnect the throttle cable from the throttle body.
  10. Turn the lock clip for the throttle cable adjuster and then pull out the sheathing.

Scheme 211

Scheme 211: To fit

Note. Spray the connector with Kontakt 61, part no. 30 04 520, before plugging in.

Scheme 212

Scheme 212

Scheme 213

Scheme 213

Scheme 214

Scheme 214
  1. Grease the rubber bush in the bulkhead with acid-free petroleum jelly (vaseline) and push the cable and its sheathing through the hole in the bush from the engine bay side.
  2. Pull the cable through the bulkhead and into the cabin.
  3. Hook the cable onto the throttle body in the engine bay. Fit the clip and secure it.
  4. Attach the wire to the accelerator pedal. NOTE: The bush must not be lubricated.
  5. Loosen the clip for adjusting the cable. Adjust the cable by holding the throttle cam against the stop (closed) with one hand and pulling the cable with the other hand until it is properly tensioned. Then release back to the next groove in the sleeve and fit the clip. Replace the cover above the throttle valve and the engine cover.
  6. Fit the connector to the floor lighting.
  7. Fit the data link connector retaining screws and tighten them.
  8. Fit the lower panel.
  9. Close the data link connector cover.

Scheme 215

Scheme 215: System overview, 4-cyl

List of lubricants

ConnectorsKontakt 61Part. No. 30 04 520
