Handbrake: Removal & Installation Saab 9-4X I

Parking Brake System 51 illustrations ~2449 words

Removal Procedure

Refer to BRAKE DUST WARNING .

Scheme 5

Scheme 5: Removal Procedure
Scheme 5: Removal Procedure

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. Disable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER DISABLING»(ref-652264-S31062533302014082300000) .
  2. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
  3. Remove the rear tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
  4. Remove the rear disc brake rotor. Refer to «REAR BRAKE ROTOR REPLACEMENT»(ref-652270-S41803734362014082300000) .
  5. Remove the park brake shoe upper return spring (1).
  6. Compress the park brake shoe hold down springs (1) and rotate the pins 1/4 turn to remove the hold down springs.
  7. Remove the park brake shoes (1) by grasping the shoes near the park brake shoe actuator, spread the park brake shoes apart and lift around the wheel hub and bearing assembly.
  8. Cross the top of one of the park brake shoes over the opposite park brake shoe.
  9. Remove the park brake shoe lower return spring (1).
  10. Remove the park brake shoe adjuster (1).
  11. Disassemble the park brake shoe adjuster.
  12. Clean the park brake shoe adjuster components of any corrosion or debris.
  13. Lubricate the park brake shoe adjuster threads (1) with high temperature brake lubricant.
  14. Lubricate the park brake shoe adjuster clevis (2) with high temperature brake lubricant.
  15. Assemble the park brake shoe adjuster to the fully retracted position.

Scheme 11

Scheme 11: Installation Procedure
Scheme 11: Installation Procedure

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. Install the park brake shoe adjuster (1) to the park brake shoes.
  2. Cross the top of one of the park brake shoes over the opposite park brake shoe.
  3. Install the park brake shoe return spring (1).
  4. Clean the park brake shoe mounting plate.
  5. Apply high temperature brake lubricant to the park brake shoe mounting plate contact points.
  6. Install the park brake shoes (1) by grasping the shoes near the park brake shoe actuator, spread the park brake shoes apart and lift around the wheel hub and bearing assembly.
  7. Install the hold down spring pins through the park brake shoe mounting plate.
  8. Compress the park brake shoe hold down springs (1) and rotate the pins 1/4 turn to install the hold down springs.
  9. Install the park brake shoe upper return spring (1).
  10. Adjust the parking brake. Refer to «PARKING BRAKE ADJUSTMENT»(ref-652264-S04986638942014082300000) .
  11. Install the rear brake rotor. Refer to «REAR BRAKE ROTOR REPLACEMENT»(ref-652270-S41803734362014082300000) .
  12. Install the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
  13. Enable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER ENABLING»(ref-652264-S35258670362014082300000) .

Scheme 16

Scheme 16: Removal Procedure
Scheme 16: Removal Procedure

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. Disable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER DISABLING»(ref-652264-S31062533302014082300000) .
  2. Turn the ignition to the OFF position.
  3. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
  4. If equipped with AWD, lower the rear suspension support approximately 152-254 mm (6-10 in) to access the cable connectors. Refer to «REAR SUSPENSION SUPPORT REPLACEMENT (AWD)»(ref-652247-S35301006722014082300000) «REAR SUSPENSION SUPPORT REPLACEMENT (FWD)»(ref-652247-S27211112922014082300000) .
  5. Disconnect the parking brake intermediate cable (1) from the electronic parking brake control module by rotating the cable nut counterclockwise.
  6. Disconnect the left parking brake rear cable fitting (1) from the park brake cable.
  7. Disconnect the right parking brake rear cable fitting (2) from the park brake cable.
  8. Remove the parking brake intermediate cable clip bolt (1).
  9. Remove the parking brake intermediate cable (1).

Scheme 20

Scheme 20: Installation Procedure
Scheme 20: Installation Procedure

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23
  1. Install the parking brake intermediate cable (1).
  2. Refer to «CAUTION: RETAINER»(ref-652229-S20487768742014082300000) Install the parking brake intermediate cable clip bolt (1) and tighten to 17 Nm (13 lb ft) .
  3. Connect the left parking brake rear cable fitting (1) to the parking brake intermediate cable.
  4. Connect the right parking brake rear cable fitting (2) to the parking brake intermediate cable.
  5. NOTE: Ensure the park brake cable fitting is engaged in the actuator in the spindle. Install the parking brake intermediate cable fitting to the spindle.
  6. NOTE: When installing the parking brake intermediate cable nut to the electronic park brake module spindle, hold the spindle housing securely to avoid distorting the housing. Install the parking brake intermediate cable nut (1) to the electronic parking brake control module spindle by rotating the nut clockwise and tighten to 6 Nm (53 lb in) .
  7. If equipped with AWD, install the rear suspension support. Refer to «REAR SUSPENSION SUPPORT REPLACEMENT (AWD)»(ref-652247-S35301006722014082300000) or «REAR SUSPENSION SUPPORT REPLACEMENT (FWD)»(ref-652247-S27211112922014082300000) .
  8. Enable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER ENABLING»(ref-652264-S35258670362014082300000) .

Refer to BRAKE DUST WARNING .

Scheme 24

Scheme 24: Removal Procedure
Scheme 24: Removal Procedure

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27
  1. Disable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER DISABLING»(ref-652264-S31062533302014082300000) .
  2. Turn the ignition to the OFF position.
  3. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
  4. Remove the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
  5. Remove the parking brake shoes. Refer to «PARKING BRAKE SHOE REPLACEMENT»(ref-652264-S40174047412014082300000) .
  6. Disconnect the left parking brake cable fitting (1) from the parking brake intermediate cable connector.
  7. Using the CH-37043 Parking Brake Cable Release Tool, compress the locking tabs on the left parking brake cable conduit (1) and remove the cable from the rear frame bracket.
  8. Remove the left parking brake actuator assembly spring clip (1).
  9. Press the parking brake actuator arm inward and release the parking brake rear cable fitting from the actuator.
  10. NOTE: The parking brake rear cable is secured to the rear suspension knuckle with an integral spring clip interference fit. Grasp the parking brake rear cable (1) and pull the cable assembly inward to release the cable conduit from the rear suspension knuckle.
  11. Remove the parking brake rear cable.

Scheme 28

Scheme 28: Installation Procedure
Scheme 28: Installation Procedure

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31
  1. NOTE: The parking brake rear cable is secured to the rear suspension knuckle with an integral spring clip interference fit. Insert the parking brake rear cable (1) into the rear suspension knuckle.
  2. Ensure the parking brake rear cable is inserted fully into the rear suspension knuckle.
  3. Press the parking brake actuator arm inward and install the parking brake rear cable to the actuator.
  4. Install the left parking brake actuator assembly spring clip (1).
  5. Install the parking brake rear cable and conduit (1) to the rear frame bracket.
  6. Ensure the parking brake rear cable conduit locking tabs are fully engaged to the rear frame bracket.
  7. Connect the left parking brake cable fitting (1) to the parking brake intermediate cable connector.
  8. Install the parking brake shoes. Refer to «PARKING BRAKE SHOE REPLACEMENT»(ref-652264-S40174047412014082300000) .
  9. Install the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
  10. Enable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER DISABLING»(ref-652264-S31062533302014082300000) .

Refer to BRAKE DUST WARNING .

Scheme 32

Scheme 32: Removal Procedure
Scheme 32: Removal Procedure

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35
  1. Disable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER DISABLING»(ref-652264-S31062533302014082300000) .
  2. Turn the ignition to the OFF position.
  3. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
  4. Remove the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
  5. Remove the parking brake shoes. Refer to «PARKING BRAKE SHOE REPLACEMENT»(ref-652264-S40174047412014082300000) .
  6. Lower the rear suspension support approximately 152-254 mm (6-10 in). Refer to «REAR SUSPENSION SUPPORT REPLACEMENT (AWD)»(ref-652247-S35301006722014082300000) «REAR SUSPENSION SUPPORT REPLACEMENT (FWD)»(ref-652247-S27211112922014082300000) .
  7. Disconnect the left parking brake cable fitting (1) from the parking brake intermediate cable connector.
  8. Using the CH-37043 Parking Brake Cable Release Tool, compress the locking tabs on the left parking brake cable conduit (1) and remove the cable from the rear frame bracket.
  9. Remove the left parking brake actuator assembly spring clip (1).
  10. Press the parking brake actuator arm inward and release the parking brake rear cable fitting from the actuator.
  11. NOTE: The parking brake rear cable is secured to the rear suspension knuckle with an integral spring clip interference fit. Grasp the parking brake rear cable (1) and pull the cable assembly inward to release the cable conduit from the rear suspension knuckle.
  12. Remove the parking brake rear cable.

Scheme 36

Scheme 36: Installation Procedure
Scheme 36: Installation Procedure

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
  1. NOTE: The parking brake rear cable is secured to the rear suspension knuckle with an integral spring clip interference fit. Insert the parking brake rear cable (1) into the rear suspension knuckle.
  2. Ensure the parking brake rear cable is inserted fully into the rear suspension knuckle.
  3. Press the parking brake actuator arm inward and install the parking brake rear cable to from the actuator.
  4. Install the left parking brake actuator assembly spring clip (1).
  5. Install the parking brake rear cable and conduit (1) to the rear frame bracket.
  6. Ensure the parking brake rear cable conduit locking tabs are fully engaged to the rear frame bracket.
  7. Connect the left parking brake cable fitting (1) to the parking brake intermediate cable connector.
  8. Install the rear suspension support. Refer to «REAR SUSPENSION SUPPORT REPLACEMENT (AWD)»(ref-652247-S35301006722014082300000) or «REAR SUSPENSION SUPPORT REPLACEMENT (FWD)»(ref-652247-S27211112922014082300000) .
  9. Install the parking brake shoes. Refer to «PARKING BRAKE SHOE REPLACEMENT»(ref-652264-S40174047412014082300000) .
  10. Install the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
  11. Enable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER DISABLING»(ref-652264-S31062533302014082300000) .

Refer to BRAKE DUST WARNING .

Scheme 40

Scheme 40: Removal Procedure
Scheme 40: Removal Procedure

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42
  1. Disable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER DISABLING»(ref-652264-S31062533302014082300000) .
  2. Turn the ignition to the OFF position.
  3. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
  4. Remove the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
  5. Remove the parking brake shoes. Refer to «PARKING BRAKE SHOE REPLACEMENT»(ref-652264-S40174047412014082300000) .
  6. Disconnect the right parking brake cable fitting from the parking brake intermediate cable connector.
  7. Using the CH-37043 Parking Brake Cable Release Tool, compress the locking tabs on the right parking brake cable conduit (1) and remove the cable from the rear frame bracket.
  8. Remove the left parking brake actuator assembly spring clip (1).
  9. Press the parking brake actuator arm inward and release the parking brake rear cable fitting from the actuator.
  10. NOTE: The parking brake rear cable is secured to the rear suspension knuckle with an integral spring clip interference fit. Grasp the parking brake rear cable (1) and pull the cable assembly inward to release the cable conduit from the rear suspension knuckle.
  11. Remove the parking brake rear cable.

Scheme 43

Scheme 43: Installation Procedure
Scheme 43: Installation Procedure

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45
  1. NOTE: The parking brake rear cable is secured to the rear suspension knuckle with an integral spring clip interference fit. Insert the parking brake rear cable (1) into the rear suspension knuckle.
  2. Ensure the parking brake rear cable is inserted fully into the rear suspension knuckle.
  3. Press the parking brake actuator arm inward and install the parking brake rear cable to from the actuator.
  4. Install the left parking brake actuator assembly spring clip (1).
  5. Install the parking brake rear cable and conduit (1) to the rear frame bracket.
  6. Ensure the parking brake rear cable conduit locking tabs are fully engaged to the rear frame bracket.
  7. Connect the right parking brake cable fitting to the parking brake intermediate cable connector.
  8. Install the parking brake shoes. Refer to «PARKING BRAKE SHOE REPLACEMENT»(ref-652264-S40174047412014082300000) .
  9. Install the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
  10. Enable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER DISABLING»(ref-652264-S31062533302014082300000) .

Refer to BRAKE DUST WARNING .

Scheme 46

Scheme 46: Removal Procedure
Scheme 46: Removal Procedure

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48
  1. Disable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER DISABLING»(ref-652264-S31062533302014082300000) .
  2. Turn the ignition to the OFF position.
  3. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
  4. Remove the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
  5. Remove the parking brake shoes. Refer to «PARKING BRAKE SHOE REPLACEMENT»(ref-652264-S40174047412014082300000) .
  6. Lower the rear suspension support approximately 152-254 mm (6-10 in). Refer to «REAR SUSPENSION SUPPORT REPLACEMENT (AWD)»(ref-652247-S35301006722014082300000) or «REAR SUSPENSION SUPPORT REPLACEMENT (FWD)»(ref-652247-S27211112922014082300000) .
  7. Disconnect the right parking brake cable fitting from the parking brake intermediate cable connector.
  8. Using the CH-37043 Parking Brake Cable Release Tool, compress the locking tabs on the right parking brake cable conduit (1) and remove the cable from the rear frame bracket.
  9. Remove the left parking brake actuator assembly spring clip (1).
  10. Press the parking brake actuator arm inward and release the parking brake rear cable fitting from the actuator.
  11. NOTE: The parking brake rear cable is secured to the rear suspension knuckle with an integral spring clip interference fit. Grasp the parking brake rear cable (1) and pull the cable assembly inward to release the cable conduit from the rear suspension knuckle.
  12. Remove the parking brake rear cable.

Scheme 49

Scheme 49: Installation Procedure
Scheme 49: Installation Procedure

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51
  1. NOTE: The parking brake rear cable is secured to the rear suspension knuckle with an integral spring clip interference fit. Insert the parking brake rear cable (1) into the rear suspension knuckle.
  2. Ensure the parking brake rear cable is inserted fully into the rear suspension knuckle.
  3. Press the parking brake actuator arm inward and install the parking brake rear cable to from the actuator.
  4. Install the left parking brake actuator assembly spring clip (1).
  5. Install the parking brake rear cable and conduit (1) to the rear frame bracket.
  6. Ensure the parking brake rear cable conduit locking tabs are fully engaged to the rear frame bracket.
  7. Connect the right parking brake cable fitting to the parking brake intermediate cable connector.
  8. Install the rear suspension support. Refer to «REAR SUSPENSION SUPPORT REPLACEMENT (AWD)»(ref-652247-S35301006722014082300000) or «REAR SUSPENSION SUPPORT REPLACEMENT (FWD)»(ref-652247-S27211112922014082300000) .
  9. Install the parking brake shoes. Refer to «PARKING BRAKE SHOE REPLACEMENT»(ref-652264-S40174047412014082300000) .
  10. Install the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
  11. Enable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER DISABLING»(ref-652264-S31062533302014082300000) .

Refer to BRAKE DUST WARNING .

Scheme 52

Scheme 52: Removal Procedure
Scheme 52: Removal Procedure

Scheme 53

Scheme 53
Scheme 53
  1. Disable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER DISABLING»(ref-652264-S31062533302014082300000) .
  2. Turn the ignition to the OFF position.
  3. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
  4. Remove the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
  5. Remove the park brake shoes. Refer to «PARKING BRAKE SHOE REPLACEMENT»(ref-652264-S40174047412014082300000) .
  6. Remove the parking brake actuator spring clip (1).
  7. Press the parking brake actuator lever inward and release the parking brake rear cable fitting.
  8. Remove the parking brake actuator (1).

Scheme 54

Scheme 54: Installation Procedure
Scheme 54: Installation Procedure

Scheme 55

Scheme 55
Scheme 55
  1. Install the parking brake actuator (1).
  2. Press the parking brake actuator lever inward and install the parking brake rear cable fitting.
  3. Install the parking brake actuator spring clip (1).
  4. Install the park brake shoes. Refer to «PARKING BRAKE SHOE REPLACEMENT»(ref-652264-S40174047412014082300000) .
  5. Install the tire and wheel assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
  6. Enable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER ENABLING»(ref-652264-S35258670362014082300000) .

More articles — Handbrake
