Handbrake: Component Locations Saab 9-4X I

Parking Brake System 9 illustrations ~473 words

Special Tools

Illustration Tool Number/Description J 21177-A Drum To Brake Shoe Clearance Gauge J 37043 Parking Brake Cable Release Tool

Scheme 56

Scheme 56: Special Tools
Scheme 56: Special Tools

Location (pos)

  1. 01 - Front
  2. 02 - Rear
  3. 03 - Left
  4. 04 - Right Hand
  5. 05 - All
  6. 06 - Upper
  7. 07 - Center
  8. 08 - Lower
  9. 09 - Service Information

Scheme 57

Scheme 57: Removal Procedure
Scheme 57: Removal Procedure

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60
  1. Block the rear wheels.
  2. Disable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER DISABLING»(ref-652264-S31062533302014082300000) .
  3. Turn the ignition to the OFF position.
  4. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
  5. Disconnect the electronic parking brake control module electrical connector.
  6. Disconnect the parking brake intermediate cable nut (1) from the electronic parking brake control module spindle by rotating the nut counterclockwise.
  7. Disconnect the parking brake intermediate cable and position the cable aside.
  8. Remove the electronic parking brake control module bolts (1).
  9. Remove the electronic parking brake control module assembly.
  10. If removing the electronic parking brake control module bracket, remove the electronic parking bake control module bracket bolts (1).
  11. Remove the electronic parking brake control module bracket (1).

Scheme 61

Scheme 61: Installation Procedure
Scheme 61: Installation Procedure

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64
  1. If removed, install the electronic parking brake control module bracket (1).
  2. Refer to «CAUTION: RETAINER»(ref-652229-S20487768742014082300000) . Install the electronic parking brake control module bracket bolts (1) and tighten to 9 Nm (80 lb in) .
  3. Install the electronic parking brake control module assembly.
  4. Install the electronic parking brake control module bolts (1) and tighten to 25 Nm (18 lb ft) .
  5. Inspect the O-ring seals on the electronic parking brake control module spindle and the parking brake intermediate cable to ensure that they are correctly positioned and are not damaged. Replace them if necessary.
  6. NOTE: Ensure the park brake intermediate cable fitting is engaged in the actuator in the spindle. Install the parking brake intermediate cable fitting to the spindle.
  7. NOTE: When installing the parking brake intermediate cable nut to the electronic park brake module spindle, hold the spindle housing securely to avoid distorting the housing. Install the parking brake intermediate cable nut (1) to the electronic parking brake control module spindle by rotating the nut clockwise and tighten to 6 Nm (53 lb in) .
  8. Connect the electronic parking brake control module electrical connector.
  9. Enable the parking brake cable adjuster. Refer to «PARKING BRAKE CABLE ADJUSTER ENABLING»(ref-652264-S35258670362014082300000) .
  10. Calibrate the electronic parking brake control module. Refer to «ELECTRONIC PARKING BRAKE CONTROL MODULE PROGRAMMING AND SETUP»(ref-652232-S17504339162014082300000) .
