Traffic Safety System: Component Locations Saab 9-4X I

Collision/avoidance 19 illustrations ~526 words

Location (pos)

  1. 01 - Front
  2. 02 - Rear
  3. 03 - Left
  4. 04 - Right Hand
  5. 05 - All
  6. 06 - Upper
  7. 07 - Center
  8. 08 - Lower
  9. 09 - Service Information

Scheme 1

Scheme 1: Front and Rear Object Alarm Module Replacement
Scheme 1: Front and Rear Object Alarm Module Replacement
CalloutComponent Name
Preliminary Procedures Remove the left body side trim panel. Refer to BODY SIDE TRIM PANEL REPLACEMENT .
1Front And Rear Object Alarm Module Nuts (Qty: 3) Refer to CAUTION: RETAINER . Tighten 6 N m (53 lb in)
2Front And Rear Object Alarm Module Procedure Disconnect the electrical connectors. For programming and set up, refer to CONTROL MODULE REFERENCES

Scheme 2

Scheme 2: Removal Procedure
Scheme 2: Removal Procedure
  1. Remove front bumper fascia. Refer to «FRONT BUMPER FASCIA REPLACEMENT»(ref-652246-S16212509752014082300000) .
  2. Disconnect electrical connector from the front object alarm sensor.
  3. Lift the locking tabs on the housing and remove the front object alarm sensor.

Scheme 3

Scheme 3: Installation Procedure
Scheme 3: Installation Procedure
  1. NOTE: Do not refinish previously painted sensors. Excess paint build up will cause the sensor to be inoperative. Paint the front object alarm sensor. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(ref-652267-S18850513642014082300000) .
  2. Ensure the paint does not exceed 6 mils. Use a paint thickness gauge suitable for non-ferrous metals. Refer to «PAINT GAUGES»(ref-652267-S20575355142014082300000) .
  3. Insert the sensor into the housing.
  4. Connect the electrical connector to the front object alarm sensor.
  5. Install the front bumper fascia. Refer to «FRONT BUMPER FASCIA REPLACEMENT»(ref-652246-S16212509752014082300000) .

Scheme 4

Scheme 4: Front Object Alarm Sensor Housing Replacement
Scheme 4: Front Object Alarm Sensor Housing Replacement

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Remove the front fascia. Refer to «FRONT BUMPER FASCIA REPLACEMENT»(ref-652246-S16212509752014082300000) .
  2. Disconnect the sensor harness.
  3. Remove the sensor from the sensor housing. The sensor housing must be painted if replaced. If reinstalled, painting will not be necessary.
  4. NOTE: Do Not grind off alignment tabs. Sand/grind sonic weld plastic residue from the fascia.
  5. Apply structural adhesive epoxy, Lord Fusor™ 127EZ or equivalent, to fascia at mating surface.
  6. Using the alignment tabs, install the sensor housing to the fascia.
  7. Allow adhesive to cure according to manufacturer's directions.
  8. Install the sensor to the sensor housing.
  9. Connect the electrical harness.
  10. Install the front fascia. Refer to «FRONT BUMPER FASCIA REPLACEMENT»(ref-652246-S16212509752014082300000) .

Scheme 9

Scheme 9: Removal Procedure
Scheme 9: Removal Procedure
  1. Remove rear bumper fascia. Refer to «REAR BUMPER FASCIA REPLACEMENT»(ref-652246-S20532272552014082300000) .
  2. Disconnect electrical from the rear object sensor.
  3. Lift the locking tabs on the housing and remove the rear object sensor.

Scheme 10

Scheme 10: Installation Procedure
Scheme 10: Installation Procedure
  1. NOTE: Do not refinish previously painted sensors. Excess paint build up will cause the sensor to be inoperative. Paint the rear object sensor. Refer to «BASECOAT/CLEARCOAT PAINT SYSTEMS»(ref-652267-S18850513642014082300000) .
  2. Ensure the paint does not exceed 6 mils. Use a paint thickness gauge suitable for non-ferrous metals. Refer to «PAINT GAUGES»(ref-652267-S20575355142014082300000) .
  3. NOTE: Ensure the silicone decoupling ring is installed on the sensor to avoid sensor failure. Insert the sensor into the housing.
  4. Connect the electrical connector to the rear object sensor.
  5. Install the rear bumper fascia. Refer to «REAR BUMPER FASCIA REPLACEMENT»(ref-652246-S20532272552014082300000) .

Scheme 11

Scheme 11: Rear Object Sensor Housing Replacement
Scheme 11: Rear Object Sensor Housing Replacement

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. Remove the rear fascia. Refer to «REAR BUMPER FASCIA REPLACEMENT»(ref-652246-S20532272552014082300000) .
  2. Disconnect the sensor harness.
  3. Remove the sensor from the sensor housing. The sensor housing must be painted if replaced. If reinstalled, painting will not be necessary.
  4. NOTE: Do Not grind off alignment tabs. Sand/grind sonic weld plastic residue from the fascia.
  5. Apply structural adhesive epoxy, Lord Fusor™ 127EZ or equivalent, to fascia at mating surface.
  6. Using the alignment tabs, install the sensor housing to the fascia.
  7. Allow adhesive to cure according to manufacturer's directions.
  8. Install the sensor to the sensor housing.
  9. Connect the electrical harness.
  10. Install the rear fascia. Refer to «REAR BUMPER FASCIA REPLACEMENT»(ref-652246-S20532272552014082300000) .

Scheme 16

Scheme 16: Rearview Camera Replacement
Scheme 16: Rearview Camera Replacement
CalloutComponent Name
Preliminary Procedures Remove the liftgate center applique. Refer to LIFTGATE CENTER APPLIQUE REPLACEMENT
1Rearview Camera Procedure Disconnect the electrical connector. Depress the clip fingers and push outward to remove the rearview camera from the applique.

Scheme 17

Scheme 17: Parking Assist Module Power, Ground, Serial Data, and Rear Sensors (UD5)
Scheme 17: Parking Assist Module Power, Ground, Serial Data, and Rear Sensors (UD5)

Scheme 18

Scheme 18: Parking Assist Front Sensors (UD5)
Scheme 18: Parking Assist Front Sensors (UD5)

Scheme 19

Scheme 19: Rearview Camera (UVC)
Scheme 19: Rearview Camera (UVC)
