Automatic Transmission (Af 40-6): Component Locations Saab 9-4X I

Special Tools

Illustration Tool Number/Description DT-498-B GE-498-B KM-498-B CH-48027 J-21867-A Pressure Measuring Equipment DT-519 KM-519 Oil Seal/Ring Installer DT-674-A KM-674-A J-29077 Installer DT-6328 KM-6328 Adapter DT-6329 KM-6329 J-21867-50 Adapter DT-41623-B KM-J-41623-B J-41623-B 8792806 Disconnect Tool DT-45096 J-45096 TransFlow Cooler Flush Machine DT-45096-30 J-45096-30 TransFlow Adapter EN-328-B KM-328-B J-6125-1B Pin Remover EN-469-A KM-469-A J-23129 Remover/Installer J-41239-1A Seal Installer J-45000 Seal Remover J-45201 Seal Remover

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

For automatic transmission AF40, the identification plate is on the top of the transmission housing.

1. DT-498-B Pressure Measuring Equipment
2. DT-6329 Adapter

For equivalent regional tools, refer to SPECIAL TOOLS .

1. DT-45096 TransFlow Cooler Flush Machine
2. DT-45096-30 TransFlow Adapter

For equivalent regional tools, refer to SPECIAL TOOLS .

GM studies indicate that plugged or restricted transmission oil coolers and pipes cause insufficient transmission lubrication and elevated operating temperatures which can lead to premature transmission failure. Many repeat repair cases could have been prevented by following published procedures for transmission oil cooler flushing and flow checking. This procedure includes flow checking and flushing the auxiliary transmission oil cooler, if equipped.

Note. Use the DT-45096 TransFlow Cooler Flush Machine or equivalent to flush and flow test the transmission oil cooler and the oil cooler pipes after the transaxle is removed for repairs or replacement. Use only GM Goodwrench DEXRON VI automatic transmission fluid in the DT-45096 TransFlow Cooler Flush Machine. In AF40-6 automatic transmission fluid AW-1 is used. After performing flushing and flow test, remove remaining DEXRON VI in the oil cooler by carefully blowing with compressed air.

Time allowance for performing the cooler flow checking and flushing procedure is included in the appropriate labor time guide operations. The service procedure steps for oil cooler flushing and flow testing are as follows

1. DT-45096 TransFlow Cooler Flush Machine
2. DT-45096-30 TransFlow Adapter
3. Shop air supply with water/oil filters, regulator and pressure gauge - minimum 90 psi
4. Eye protection
5. Rubber gloves

Scheme 15

Scheme 16

Scheme 17

1. Verify that the main power switch (1) is in the OFF position.
2. Place the main function switch (2) in the IDLE position.
3. Connect DT-45096 flush machine to the vehicle 12V DC power source by connecting the red battery clip to the positive, +, battery post on the vehicle and connect the negative lead to a known good chassis ground.
4. Turn the main power switch to the ON position.
5. WARNING: Do not overfill the supply vessel. Damage to the unit may result. To verify the fluid level, view the LCD screen display while filling the unit, to ensure the fluid level does not exceed 30 L (32 qt). Fill the supply tank with Dexron®VI through the fill port.
6. Reinstall and tighten the fill cap.
7. Connect a shop air supply hose to the quick-disconnect on the rear panel marked SUPPLY AIR.

Scheme 18

Scheme 19

1. From the machine display, identify the temperature of the automatic transmission fluid that is stored in the supply vessel of DT-45096 flush machine.
2. Determine whether the transmission oil cooler is steel or aluminum by using a magnet (1) at the cooler flange (2) at the radiator.
3. Refer to the table below. Using the temperature from step 1 , locate on either the Steel MINIMUM Flow Rate table or the Aluminum MINIMUM Flow Rate table the minimum flow rate in gallons per minutes (GPM). Record the minimum flow rate in GPMs and the supply fluid temperature for further reference. Example: Fluid temperature: 75°F Cooler type: Steel The MINIMUM flow rate for this example would be 0.8 GPM.

1. Inspect transmission oil cooler lines for damage or kinks that could cause restricted oil flow. Repair as needed and refer to the appropriate GM service manual procedures.

Location (pos)

1. 01 - Front
2. 02 - Rear
3. 03 - Left
4. 04 - Right Hand
5. 05 - All
6. 06 - Upper
7. 07 - Center
8. 08 - Lower
9. 09 - Service Information

1. 01 - Front
2. 02 - Rear
3. 03 - Left
4. 04 - Right Hand
5. 05 - All
6. 06 - Upper
7. 07 - Center
8. 08 - Lower
9. 09 - Service Information

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. NOTE: Adjust the automatic transmission range selector cable while the transmission and the gear selector are in the Park position only. Failure to do so may cause misadjustment. Set the park brake and chock the wheels.
2. Verify the transmission range select lever is in the park position.
3. Verify the transmission manual shift lever is in the park position.
4. If installing a new cable, skip this step and go to the next step. Pull the retaining collar (1) forward, then release the range select cable adjuster clip (2) by pushing up on the adjuster clip from the underside. Depress the adjuster clip (2) locking the adjuster clip completely.
5. Ensure that the cable adjuster is secured.
6. Check the transmission range select lever in all gear selections for proper operation.

Scheme 24

Scheme 25

Scheme 26

1. Set the park brake and chock the wheels.
2. Disconnect the transmission range selector lever cable terminal (1) from the transmission manual shift lever pin (6).
3. Slide the retainer (4) rearward to release the transmission range selector lever cable from the bracket.
4. Remove the front floor console extension. Refer to «FRONT FLOOR CONSOLE EXTENSION REPLACEMENT»(ref-652235-S07389571222014082300000) .
5. Disconnect the transmission range selector lever cable retainers (2) from the support bracket.
6. Remove the grommet (1) and cable assembly from the floor panel.
7. Slide the transmission range selector lever cable retainer forward (1) and remove the transmission range selector cable from the transmission control base.
8. Disconnect the transmission range selector lever cable terminal (2) from the shift lever pin.
9. Remove the transmission range selector lever cable from the vehicle.

Scheme 27

Scheme 28

Scheme 29

1. Install the transmission range selector lever cable in the vehicle.
2. Connect the transmission range selector lever cable terminal (2) to the shift lever pin.
3. Install the transmission range selector cable to the transmission control base, then slide the transmission range selector lever cable retainer rearward (1) to lock the cable in place.
4. NOTE: Ensure the grommet is properly oriented with paint dot facing top. Install the grommet (1) and cable assembly into the floor panel.
5. Connect the transmission range selector lever cable retainers (2) to the support bracket.
6. Install the front floor console extension. Refer to «FRONT FLOOR CONSOLE EXTENSION REPLACEMENT»(ref-652235-S07389571222014082300000) .
7. Connect the transmission range selector lever cable terminal (1) to the transmission manual shift lever pin (6).
8. Install the cable in the bracket, then slide the retainer (4) forward to lock the transmission range selector lever cable in the bracket.
9. Adjust the cable. Refer to «RANGE SELECTOR LEVER CABLE ADJUSTMENT»(ref-652265-S15692028382014082300000) .

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
2. Remove the front transaxle mount through bolt (1).
3. Remove and discard the three transaxle mount-to-transaxle attachment bolts (2).
4. Remove the transaxle mount (1) from the vehicle.

Scheme 34

Scheme 35

1. Install the transaxle mount (1).
2. Refer to «FASTENER CAUTION»(ref-652265-S21063658522014082300000) . Install the transaxle NEW brace bolts (2) and tighten to 62 Nm (46 lb ft) .
3. Install the transaxle bolt (1) and tighten to 105 Nm (77 lb ft) .
4. Lower the vehicle.

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. Remove the battery box. Refer to «BATTERY TRAY REPLACEMENT»(ref-652241-S39377734662014082300000) .
2. Install the engine support fixture. Refer to «ENGINE SUPPORT FIXTURE (ENGINE BRIDGE, RETAINER FRAME)»(ref-652231-S17556864582014082300000) «ENGINE SUPPORT FIXTURE (CENTERING ADAPTER)»(ref-652231-S04641133612014082300000) .
3. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
4. Remove the front transmission mount through bolt (1).
5. Remove the rear transmission mount through bolt (1).
6. Remove the transmission mount to transmission bolts (1).
7. Using the engine support, lower the transmission enough to provide clearance for the left transmission mount.
8. Remove the transmission mount to frame rail bolts (1).
9. Remove the left transmission mount (2).

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. Install the left transmission mount (2).
2. Refer to «FASTENER CAUTION»(ref-652265-S21063658522014082300000) . Install the transmission mount bracket to transmission bolt (1) and tighten to 22 Nm (16 lb ft) .
3. Using the engine support, raise the transmission until the transmission contacts the left transmission mount.
4. NOTE: DO NOT reuse the old bolts. Always use NEW bolts when reinstalling the mount. Install the transmission mount bracket to transmission bolts (1) and tighten to 50 Nm (37 lb ft) plus 60-75 degrees .
5. Install the wheel and tire assembly. Refer to «TIRE AND WHEEL REMOVAL AND INSTALLATION»(ref-652234-S18162824462014082300000) .
6. Raise the vehicle.
7. Install the rear transmission mount through bolt (1) and tighten to 105 Nm (77 lb ft) .
8. Install the front transmission mount through bolt (1) and tighten to 100 Nm (74 lb ft) .
9. Lower the vehicle.
10. Remove the engine support fixture.
11. Install the battery box. Refer to «BATTERY TRAY REPLACEMENT»(ref-652241-S39377734662014082300000) .

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

1. Remove control valve body cover. Refer to «CONTROL VALVE BODY COVER REPLACEMENT»(ref-652265-S27932581382014082300000) .
2. Detach the wiring harness for the solenoid valves. (The illustration shows how to use a screwdriver for detaching the different connectors.) 2.1. Detach 8 connectors from the solenoid valves (1). 2.2. Unplug the 2 connectors from the engine speed sensors (2). 2.3. Remove the wiring harness from the 2 retaining clips (3).
3. Unplug the engine speed sensor connectors. Detach the connectors from the two mountings (4).
4. Remove the temperature sensor. 4.1. Remove the screw (1). 4.2. Lift away the attaching plate (2). 4.3. Remove the temperature sensor (3).
5. Move the wiring harness for the solenoid valves and the wiring harness for the engine speed sensors aside.
6. Remove the cover (1). 6.1. Remove the screws (2). 6.2. Remove the gasket (3).
7. Remove the valve housing. 7.1. Undo the fasteners in the specified order. 7.2. Remove the fasteners.
8. Lower the car to the floor.
9. Unhook the clutch rod (1).
10. NOTE: The ducts are filled with oil. Carefully lift the valve housing upwards.

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. Clean the sealing surfaces.
2. Clean the threads (arrows).
3. Install the valve housing. 3.1. Hook in the clutch rod (1). 3.2. Install 6 fasteners.
4. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
5. Install the cover. 5.1. Install a new gasket (3). 5.2. Install the cover (1). 5.3. Install two screws (2).
6. Finish fitting the valve housing.
7. Refer to «FASTENER CAUTION»(ref-652265-S21063658522014082300000) . Tighten the 8 fasteners (arrows) in the specified order. Tighten 10 Nm (88 lb in)
8. Install the temperature sensor (3). 8.1. Moisten the temperature sensor O-ring with gearbox oil. 8.2. Install the attaching plate (2). 8.3. Tighten the fastener (1). Tighten 10 Nm (88 lb in)
9. Plug in the engine speed sensor connectors. Attach the connectors to the two mountings (4).
10. Plug in the connector for the solenoid valves. 10.1. Secure the wiring harness in the 2 retaining clips (3). 10.2. Plug in the 2 connectors for the engine speed sensors (2). 10.3. Plug in the 8 connectors for the solenoid valves (1).
11. Install control valve body. Refer to «CONTROL VALVE BODY COVER REPLACEMENT»(ref-652265-S27932581382014082300000) .
12. Lower the vehicle.

Scheme 60

Scheme 61

1. NOTE: Perform the following procedure when removing the retaining rings and cooler lines from the quick connect fittings located on the radiator and/or the transmission. Pull the plastic cap back from the quick connect fitting and down along the cooler line about 5 cm (2 in).
2. Using a bent-tip screwdriver, pull on one of the open ends of the retaining ring in order to rotate the retaining ring around the quick connect fitting until the retaining ring is out of position and can be completely removed.
3. Remove the retaining ring from the quick connect fitting.
4. Discard the retaining ring.
5. Pull the cooler line straight out from the quick connect fitting.

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

1. NOTE: Do not reuse any of the existing oil lines or oil line fittings if there is excessive corrosion. Do not reuse any of the existing retaining rings that were removed from the existing quick connect fittings. Install new retaining rings. Ensure the following procedures are performed when installing the new retaining rings onto the fittings. Install a new retaining ring into the quick connect fitting using the following procedure
2. Hook one of the open ends of the retaining ring in one of the slots in the quick connect fitting.
3. Rotate the retaining ring around the fitting until the retaining ring is positioned with all three ears through the three slots on the fitting.
4. Do not install the new retaining ring onto the fitting by pushing the retaining ring.
5. Ensure that the three retaining ring ears are seen from inside the fitting and that the retaining ring moves freely in the fitting slots.
6. Install the cooler line into the quick connect fitting.
7. Insert the cooler line end into the quick connect fitting until a click is either heard or felt.
8. Do not use the plastic cap on the cooler line in order to install the cooler line into the fitting.
9. Pull back sharply on the cooler line in order to ensure that the cooler line is fastened into the quick connect fitting.
10. IMPORTANT: Do not manually depress the retaining clip when installing the plastic cap. Position (snap) the plastic cap onto the fitting. Do not manually depress the retaining ring when installing the plastic cap onto the quick connect fitting.
11. Ensure that the plastic cap is fully seated against the fitting.
12. Ensure that no gap is present between the cap and the fitting.
13. Ensure that the yellow identification band on the tube is hidden within the quick connect fitting.
14. A hidden yellow identification band indicates proper joint seating.
15. Fill the transmission to the proper level. Refer to «ADHESIVES, FLUIDS, LUBRICANTS, AND SEALERS»(ref-652265-S25988896342014082300000) and «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-652265-S16994866682014082300000) .

Scheme 72

1. Drain the cooling system. Refer to «DRAINING AND FILLING (GE 47716)»(ref-652237-S23590170992014082300000) , «DRAINING AND FILLING (STATIC FILL LAU)»(ref-652237-S36839240752014082300000) or «DRAINING AND FILLING (STATIC FILL LF1)»(ref-652237-S01219592032014082300000) .
2. Remove the transaxle oil cooler hoses from the oil cooler fittings on the radiator. Refer to «TRANSMISSION FLUID COOLER HOSE/PIPE QUICK-CONNECT FITTING DISCONNECTION AND CONNECTION»(ref-652265-S09980399162014082300000) .
3. NOTE: Do not remove the upper and lower transaxle oil cooler fittings from the radiator at the same time other wise the transaxle oil cooler will fall inside the radiator end tank. Remove the oil cooler fitting from the radiator.

Scheme 73

1. Inspect the new O-ring seals for cracks, cuts or damage. Replace if necessary.
2. Refer to «FASTENER CAUTION»(ref-652265-S21063658522014082300000) . NOTE: The correct thread engagement is critical. Cross-threaded fittings can achieve proper tightness and still leak. Install the oil cooler fitting to the radiator and tighten to 38 Nm (28 lb ft) .
3. Install the transaxle oil cooler hoses to the oil cooler fittings on the radiator. Refer to «TRANSMISSION FLUID COOLER HOSE/PIPE QUICK-CONNECT FITTING DISCONNECTION AND CONNECTION»(ref-652265-S09980399162014082300000) .
4. Fill the cooling system. Refer to «DRAINING AND FILLING (GE 47716)»(ref-652237-S23590170992014082300000) , «DRAINING AND FILLING (STATIC FILL LAU)»(ref-652237-S36839240752014082300000) , or «DRAINING AND FILLING (STATIC FILL LF1)»(ref-652237-S01219592032014082300000) .
5. Adjust the transmission fluid level.
6. Inspect for fluid leaks.

1. DT-41239-1A Cooler Line Seal Installer
2. DT-45201 Cooler Line Seal Remover

For equivalent regional tools, refer to SPECIAL TOOLS .

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. Raise the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-652230-S26645367622014082300000) .
2. WARNING: Ensure that the vehicle is properly supported and squarely positioned. To help avoid personal injury when a vehicle is on a hoist, provide additional support for the vehicle on the opposite end from which the components are being removed. Place a drain pan or suitable container under the vehicle.
3. Remove the transaxle oil cooler line assembly nut from the transaxle.
4. Disconnect the transaxle oil cooler lines from the vehicle.
5. NOTE: Ensure that the J 45201 is fully seated into the transaxle seal bore. Insert the collet piece (2) of the DT-45201 Cooler Line Seal Remover into the cooler line seal.
6. Insert the forcing screw piece (1) of the DT-45201 Cooler Line Seal Remover into the collet (2).
7. Tighten the forcing screw (1) until snug.
8. Thread the collar piece (1) of the DT-45201 Cooler Line Seal Remover onto the collet (3) until snug.
9. Turn the collar clockwise in order to remove the cooler line seal (87).
10. Discard the seal (87).
11. Clean the case bores for the cooler line seals.

Scheme 78

Scheme 79

Scheme 80

1. Insert a new transaxle cooler line seal into the case bore.
2. Remove the nub from the DT-41239-1A Cooler Line Seal Installer.
3. Install the nub of the DT-41239-1A Cooler Line Seal Installer on the transaxle cooler line seal.
4. Tap the new transaxle cooler line seal into the case bore.
5. Install the transaxle oil cooler line assembly to the transaxle.
6. Refer to «FASTENER CAUTION»(ref-652265-S21063658522014082300000) . Install the transaxle oil cooler line assembly nut and tighten to 9 Nm (80 lb in) .
7. Lower the vehicle.
8. NOTE: DEXRON® VI automatic transmission fluid is not compatible with this transaxle. If DEXRON® VI ATF is used, transaxle failure will result. This transaxle uses GM AW-1 fluid P/N 19256039. Add fluid to the transaxle. Refer to «ADHESIVES, FLUIDS, LUBRICANTS, AND SEALERS»(ref-652265-S25988896342014082300000)
9. Start the engine and check for leaks.

Scheme 81

Scheme 82

Scheme 83

Scheme 84

1. CH-49290 Engine fixture
2. CH-49289 Support frame fixture
3. CH-904 Basic tool
4. DT-47648 Transmission fixture
5. EN-47649 Engine Bridge
6. EN-47650 Retainer Frame

For equivalent regional tools, refer to SPECIAL TOOLS .

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

1. Remove the intake manifold cover. Refer to «INTAKE MANIFOLD COVER REPLACEMENT»(ref-652231-S15941694392014082300000) .
2. Remove the battery tray. Refer to «BATTERY TRAY REPLACEMENT»(ref-652241-S39377734662014082300000) .
3. Disconnect the connector (1) from the transmission control module.
4. Remove the shift lever cable from the selector on the transmission. Refer to «RANGE SELECTOR LEVER CABLE REPLACEMENT»(ref-652265-S30276357842014082300000) .
5. Remove upper transmission fasteners (1).
6. Install the engine support fixture. Refer to «ENGINE SUPPORT FIXTURE (ENGINE BRIDGE, RETAINER FRAME)»(ref-652231-S17556864582014082300000) and «ENGINE SUPPORT FIXTURE (CENTERING ADAPTER)»(ref-652231-S04641133612014082300000) .
7. Raise the vehicle.
8. Drain the transmission fluid.
9. Remove the exhaust front pipe. Refer to «EXHAUST FLEXIBLE PIPE REPLACEMENT (LAU)»(ref-652240-S22994477482014082300000) or «EXHAUST FLEXIBLE PIPE REPLACEMENT (LF1-SERVICE)»(ref-652240-S39572498132014082300000) .
10. Install CH-49290 Engine fixture and CH-49289 Support frame fixture.
11. Remove the frame. Refer to «DRIVETRAIN AND FRONT SUSPENSION FRAME INSULATOR REPLACEMENT»(ref-652247-S00711622472014082300000) .
12. Remove the transmission front mount. Refer to «TRANSMISSION FRONT MOUNT REPLACEMENT»(ref-652265-S39316327472014082300000) .
13. Remove the transmission rear mount bracket. Refer to «TRANSMISSION REAR MOUNT REPLACEMENT»(ref-652265-S41712967522014082300000) .
14. Remove the right wheel driveshaft. Refer to «FRONT WHEEL DRIVE SHAFT REPLACEMENT»(ref-652249-S17747125552014082300000) .
15. Remove the left wheel drive shaft. Refer to «FRONT WHEEL DRIVE SHAFT REPLACEMENT»(ref-652249-S17747125552014082300000) .
16. Remove the transfer case from the transmission. Refer to «TRANSFER CASE REPLACEMENT»(ref-652248-S04533415112014082300000)
17. Remove the starter. Refer to «STARTER REPLACEMENT (LAU)»(ref-652241-S14690624992014082300000) or «STARTER REPLACEMENT (LF1)»(ref-652241-S08189275452014082300000) .
18. Remove the six fasteners (1) from the flywheel to the torque converter.
19. Remove the oil cooler hose connection (1) from the transmission.
20. Remove the fasteners to the transmission mount bracket left side. Refer to «FRONT AXLE SHAFT SEAL REPLACEMENT - LEFT SIDE»(ref-652265-S27598727142014082300000) .
21. Lower the vehicle.
22. Adjust the settings of the CH-904 Basic tool and lower the engine enough to access the transmission.
23. Raise the vehicle.
24. Support the transmission with DT-47648 Transmission fixture and a transmission jack. graphic here
25. Remove the lower transmission fasteners.
26. Separate the transmission from the engine.
27. Secure the torque converter in the transmission to prevent it from falling.
28. Lower the transmission.

Scheme 90

Scheme 91

Scheme 92

Scheme 93

1. Lubricate the centering pin on the converter and the two guiding sleeves.
2. Check torque converter for correct transmission positioning.
3. Position the transmission to the engine.
4. Refer to «FASTENER CAUTION»(ref-652265-S21063658522014082300000) . Install the one lower transmission fastener (1) and tighten to 60 Nm (44 lb ft) .
5. Install the four lower transmission fasteners (2) and tighten to 40 Nm (30 lb ft) .
6. Install the transfer case to the transmission. Refer to «TRANSFER CASE REPLACEMENT»(ref-652248-S04533415112014082300000)
7. Remove the DT-47648 Transmission fixture and the transmission jack.
8. Lower the vehicle.
9. Raise the engine to the correct level with the engine support fixture.
10. Install the fasteners to the transmission mount bracket left side. Refer to «TRANSMISSION MOUNT REPLACEMENT - LEFT SIDE»(ref-652265-S23166069232014082300000)
11. Install the upper transmission fasteners (1) and tighten to 60 Nm (44 lb ft) .
12. Connect the shift lever cable to the selector lever on the transmission. Refer to «RANGE SELECTOR LEVER CABLE REPLACEMENT»(ref-652265-S30276357842014082300000) .
13. Connect the electrical connector to the transmission control module.
14. Raise the vehicle.
15. Install the fasteners to the converter. Apply locking agent on the bolts and tighten to 60 Nm (44 lb ft) .
16. Install the starter. Refer to «STARTER REPLACEMENT (LAU)»(ref-652241-S14690624992014082300000) or «STARTER REPLACEMENT (LF1)»(ref-652241-S08189275452014082300000) .
17. Install the oil cooler hose connection (1) to the transmission and tighten to 10 Nm (89 lb in) .
18. Install the transmission rear mount bracket. Refer to «TRANSMISSION REAR MOUNT REPLACEMENT»(ref-652265-S41712967522014082300000) .
19. Install the transmission front mount. Refer to «TRANSMISSION FRONT MOUNT REPLACEMENT»(ref-652265-S39316327472014082300000) .
20. Install the right driveshaft. Refer to «FRONT WHEEL DRIVE SHAFT REPLACEMENT»(ref-652249-S17747125552014082300000) .
21. Install the left driveshaft to the transmission. Refer to «FRONT WHEEL DRIVE SHAFT REPLACEMENT»(ref-652249-S17747125552014082300000) .
22. Install the CH-49290 Engine fixture with the engine guiding pins.
23. Install the frame. Refer to «DRIVETRAIN AND FRONT SUSPENSION FRAME INSULATOR REPLACEMENT»(ref-652247-S00711622472014082300000) .
24. Remove the CH-49290 Engine fixture and the CH-49289 Support frame fixture
25. Install the exhaust front pipe. Refer to «EXHAUST FLEXIBLE PIPE REPLACEMENT (LAU)»(ref-652240-S22994477482014082300000) or «EXHAUST FLEXIBLE PIPE REPLACEMENT (LF1-SERVICE)»(ref-652240-S39572498132014082300000) .
26. Lower the vehicle.
27. Remove the engine support fixture.
28. Install the battery tray and battery. Refer to «BATTERY TRAY REPLACEMENT»(ref-652241-S39377734662014082300000) .
29. Check the transmission fluid. Refer to «TRANSMISSION FLUID LEVEL AND CONDITION CHECK»(ref-652265-S16994866682014082300000) .
30. Install the intake manifold cover. Refer to «INTAKE MANIFOLD COVER REPLACEMENT»(ref-652231-S15941694392014082300000) .

Scheme 94

1. Remove control valve body cover. Refer to «CONTROL VALVE BODY COVER REPLACEMENT»(ref-652265-S27932581382014082300000) .
2. Remove control valve body. Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-652265-S16463239452014082300000) .
3. Remove the transmission control module, see «TRANSMISSION CONTROL MODULE, REPLACEMENT»(ref-652265-S07524743032014082300000) .
4. Remove the wiring harness. Remove the clip (1). Lift out the wiring harness (2).

Scheme 95

Scheme 96

1. Fit the wiring harness. Fit a new seal (2) in the gearcase and an O-ring (1) on the connection.
2. Fit in the wiring harness (2). Make sure that the connector's guide pin locates in the groove and fit the clip (1).
3. Fit the transmission control module. Refer to «TRANSMISSION CONTROL MODULE REPLACEMENT»(ref-652265-S07524743032014082300000) .
4. Fit the control valve body. Refer to «CONTROL VALVE BODY REPLACEMENT»(ref-652265-S16463239452014082300000) .
5. Fit the control valve body cover. Refer to «CONTROL VALVE BODY COVER REPLACEMENT»(ref-652265-S27932581382014082300000) .

Scheme 97

Scheme 98
