Crimp Connection J1, Front Harness
Location: Approx. 210 mm from branching of grounding point G30 towards the left headlamp
Scheme 33
Crimp J2, Front Harness
Location: Approx. 60 mm from branching point grounding point G30 towards left headlamp
Scheme 34
Crimp Connection J9, Front Harness
Location: Approx. 150 mm from branching of grounding point G31 towards the left headlamp
Scheme 35
Crimp Connection J12, Front Harness
Location: Approx. 130 mm from branching point grounding point G31 towards LH headlamp
Scheme 36
Crimp J130, Roof Harness
Location: Approx. 90 mm from the branching point to the LH make-up light towards the luggage compartment electrical center
Scheme 37
Crimp J146, Rear Harness
Location
4D: Approx. 380 mm from the REC
5D: Approx. 50 mm from branching point grounding point G3 towards REC
Scheme 38
Crimp Connection J222, Rear Harness CV
Location: Approx. 120 mm from branching of light cluster on left rear wing towards the luggage compartment lighting
Scheme 39
Crimp J147, Rear Harness, 5D
Location: Approx. 40 mm from branching point grounding point G29 towards right-hand light cluster
Scheme 40
Checking the Wiring Harness
Move the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.
Scheme 41
Move the wiring harness at several spots and in several directions to reveal intermittent breaks and short-circuits. Check switches, connectors and crimp connections for oxidation, retracted pins and pin clamping force.
