Intake System 4-CYL: Overview Saab 9-3 II

Mechanical 10 illustrations ~293 words

Scheme 449

Scheme 449: To remove

Scheme 450

Scheme 450
  1. Release the connector from the mass air flow sensor.
  2. Release the hose from the air filter housing cover.
  3. Remove the air filter housing cover.
  4. Remove the air filter.
  5. Cover the turbo inlet hose and blow the air filter housing clean.

Scheme 451

Scheme 451: To fit

Scheme 452

Scheme 452
  1. Fit a new air filter.
  2. Fit the air filter housing cover.
  3. Connect the hose to the air filter housing cover.
  4. Connect the mass air flow sensor connector.

Scheme 453

Scheme 453: To remove

Scheme 454

Scheme 454

Scheme 455

Scheme 455

Scheme 456

Scheme 456

Scheme 457

Scheme 457

Scheme 458

Scheme 458
  1. Remove Throttle body actuator unit (604). See «THROTTLE BODY ACTUATOR (604) (2006)»(ref-275835-S17178834512007122900000) or «THROTTLE BODY ACTUATOR (604) (2007).»(ref-279917-S30521273282008021800000)
  2. Remove Control module, Trionic T8 (589). See «TRIONIC T8 CONTROL MODULE (589) (2006)»(ref-275835-S15998373582007122900000) or «TRIONIC T8 CONTROL MODULE (589) (2007).»(ref-279917-S04257352552008021800000)
  3. Remove the solenoid valve's hose (A) from the intake manifold.
  4. Remove the atmospheric pressure sensor (539) (B) from the intake manifold. Allow the sensor to hang in the connector.
  5. Undo the nut for the cable duct (C).
  6. Undo the fuel pressure regulator's hose (D) from the intake manifold.
  7. Undo the EVAP canister purge valve's hose (A) from the intake manifold and fold aside.
  8. Undo the brake servo's plastic hose (B) from the intake manifold.
  9. Unplug the wiring harness' connector (A) for the injectors.
  10. Undo the wiring harness' connector from the clip (A) under the intake manifold.
  11. Unplug the injector connectors (B).
  12. Lift up the wiring harness to the injectors.
  13. Remove the upper bracket to the dipstick (A) and undo it from the sump and fold aside.
  14. Remove the intake manifold's stay (B)
  15. Remove the intake manifold (A).

Description

The induction system comprises air cleaner, mass air flow sensor, connecting pipes/hoses, turbo unit and charge air cooler. The system is connected to the throttle body.
