Fuses Saab 9-3 II

Glass, Windows and Mirrors 11 illustrations ~186 words

Fuses

The electrical center can contain a greater number of fuses than those listed below. In such cases, these are not connected to a wiring harness. For additional fuse information, see CIRCUIT PROTECTION DEVICES and POWER DISTRIBUTION .

NoAmpTypeFunction
1
2
3
440+30Electrically adjustable seat without memory
540+30Electrically heated rear window (115) STC control module (CV) (565) Antenna amplifier (624)
630+30Control module, rear left door (702RL) Control module, rear left window lift (575RL)
730+30Control module, right rear door (702RR) Control module, rear right window lift (575RR)
820+30Connection, trailer (258)
9
1030High-level brake light Trailer lighting Luggage compartment illumination Left rear lighting brake lights Right rear lighting: Direction indicators taillights Reversing lights
11
12
13
1415+30Rear window wiper motor (63R)
1515+30Heating, left seat (64FL)
1615+30Heating, right seat (64FR)
177.5+15Rain sensor (649) Sunroof (182) Interior rearview mirror (681) with: Remote control garage opening Compass ADM control module
1815+30Sunroof (182)
197.5+30Positioning unit (468)
207.5+30DVD (729)
217.5+30Control module, rear doors (702R) Control module, rear window lifts (575R) Control module, SPA (630) Front lamp unit, interior lighting (185F) on CV
2230+30Rear amplifier (354R)
23
2410+30Siren, anti-theft alarm (275) Anti-theft alarm sensor (690) Rear CD changer (355R)
2530+30Electrically adjustable driver's seat with memory control module (357Dk) Electrically adjustable seat without memory (CV)
2630Rear fog light Number plate lighting Luggage compartment illumination Trailer lighting Left rear lighting Direction indicators taillights Reversing lights Right rear lighting: brake lights
2710Electrically controlled lumbar support
28
29

FUSE LIST

Scheme 397

Scheme 397: Relays
Scheme 397: Relays

The electrical center can contain a greater number of relays than those listed below. In such cases, these are not connected to a wiring harness. For additional relay information, see BUZZERS, RELAYS & TIMERS .

RELAYS LIST Location No. Description Graphic Diagram R1 446 Electrically adjustable seat relay ELECTRICALLY ADJUSTABLE SEAT 4D/5D LH ELECTRICALLY ADJUSTABLE SEAT 4D/5D RH R2 757R Relay, +15, REC - R3 - - - - R4 113 Electrically heated rear window relay - R5 83a Rear window wiper relay - R6 - - - - R7 710 Boot lid opening motor relay - R8 - - - - R9 - - - - R10 - - - - R11

Scheme 398

Scheme 398
Scheme 398

Scheme 399

Scheme 399
Scheme 399

Scheme 400

Scheme 400
Scheme 400

Scheme 401

Scheme 401
Scheme 401

Scheme 402

Scheme 402
Scheme 402

Scheme 403

Scheme 403: Fuse 5, rear electrical center 701, maxi-fuse
Scheme 403: Fuse 5, rear electrical center 701, maxi-fuse
No.Name
113Relay, electrically heated rear window
115Heating element, rear window
565Control module, STC
624Antenna amplifier, radio
701Rear electrical center

COMPONENTS LIST

Scheme 404

Scheme 404: Fuse 6, rear electrical center 701
Scheme 404: Fuse 6, rear electrical center 701
No.Name
575RLControl module, window lift, rear, LH
701Rear electrical center
702RLControl module, door, rear, left-hand

COMPONENTS LIST

Scheme 405

Scheme 405: Fuse 7, rear electrical center 701
Scheme 405: Fuse 7, rear electrical center 701
No.Name
575RRControl module, window lift, rear, RH
701Rear electrical center
702RRControl module, door, rear, right-hand

COMPONENTS LIST

Scheme 406

Scheme 406: Fuse 17, rear electrical center 701
Scheme 406: Fuse 17, rear electrical center 701
No.Name
182Sun Roof Module
649Rain sensor
681Interior rear-view mirror
701Electrical center, luggage compartment
757RRelay, +15, REC

COMPONENTS LIST

Scheme 407

Scheme 407: Fuse 21, rear electrical center 701
Scheme 407: Fuse 21, rear electrical center 701
No.Name
575RControl module, rear window lift
630Control module, SPA
685FUnit, dome light, front
701Electrical distribution unit, boot
702RControl module, rear door

COMPONENTS LIST
