Fuses Saab 9-3 II

Doors & Locks 9 illustrations ~160 words

Fuses

The electrical center can contain a greater number of fuses than those listed below. In such cases, these are not connected to a wiring harness. For additional fuse information, see CIRCUIT PROTECTION DEVICES and appropriate POWER DISTRIBUTION article.

No.AmpTypeFunction
1
2
3
440+30Electrically adjustable seat without memory
540+30Electrically heated rear window (115) STC control module (CV) (565) Antenna amplifier (624)
630+30Control module, rear left door (702RL) Control module, rear left window lift (575RL)
730+30Control module, right rear door (702RR) Control module, rear right window lift (575RR)
820+30Connection, trailer (258)
9
1030High-level brake light Trailer lighting Luggage compartment illumination Left rear lighting brake lights Right rear lighting: Direction indicators taillights Reversing lights
11
12
13
1415+30Rear window wiper motor (63R)
1515+30Heating, left seat (64FL)
1615+30Heating, right seat (64FR)
177.5+15Rain sensor (649) Sunroof (182) Interior rearview mirror (681) with: Remote control garage opening Compass ADM control module
1815+30Sunroof (182)
197.5+30Positioning unit (468)
207.5+30DVD (729)
217.5+30Control module, rear doors (702R) Control module, rear window lifts (575R) Control module, SPA (630) Front lamp unit, interior lighting (185F) on CV
2230+30Rear amplifier (354R)
23
2410+30Siren, anti-theft alarm (275) Anti-theft alarm sensor (690) Rear CD changer (355R)
2530+30Electrically adjustable driver's seat with memory control module (357Dk) Electrically adjustable seat without memory (CV)
2630Rear fog light Number plate lighting Luggage compartment illumination Trailer lighting Left rear lighting Direction indicators taillights Reversing lights Right rear lighting: brake lights
2710Electrically controlled lumbar support
28
29

FUSES DESCRIPTION

Scheme 820

Scheme 820: Relays
Scheme 820: Relays

The electrical center can contain a greater number of relays than those listed below. In such cases, these are not connected to a wiring harness. For additional relay information, see BUZZERS, RELAYS & TIMERS .

RELAYS DESCRIPTION TABLE Location No. Description Graphic R1 446 Electrically adjustable seat relay R2 757R Relay, +15, REC R3 - - - R4 113 Electrically heated rear window relay R5 83a Rear window wiper relay R6 - - - R7 710 Boot lid opening motor relay R8 - - - R9 - - - R10 - - - R11

Scheme 821

Scheme 821
Scheme 821

Scheme 822

Scheme 822
Scheme 822

Scheme 823

Scheme 823
Scheme 823

Scheme 824

Scheme 824
Scheme 824

Scheme 825

Scheme 825
Scheme 825

Scheme 826

Scheme 826: Fuse 6, rear electrical center 701
Scheme 826: Fuse 6, rear electrical center 701
No.Name
575RLControl module, window lift, rear, LH
701Rear electrical center
702RLControl module, door, rear, left-hand

COMPONENTS LIST

Scheme 827

Scheme 827: Fuse 7, rear electrical center 701
Scheme 827: Fuse 7, rear electrical center 701
No.Name
575RRControl module, window lift, rear, RH
701Rear electrical center
702RRControl module, door, rear, right-hand

COMPONENTS LIST

Scheme 828

Scheme 828: Fuse 21, rear electrical center 701
Scheme 828: Fuse 21, rear electrical center 701
No.Name
575RControl module, rear window lift
630Control module, SPA
685FUnit, dome light, front
701Electrical distribution unit, boot
702RControl module, rear door

COMPONENTS LIST
