Charging System - V6: Removal & Installation Saab 9-3 II

To remove

In the method described below, the generator has already been removed.

Scheme 163

1. Remove the belt pulley cover.
2. Remove the belt pulley using special tools «83 95 709»(ref-275860-S30878733912007122900000) and «83 95 832»(ref-275860-S39815629112007122900000) . NOTE: The belt pulley is threaded counter clockwise.

Scheme 164

1. Fit the belt pulley using special tools «83 95 709»(ref-275860-S30878733912007122900000) and «83 95 832»(ref-275860-S39815629112007122900000) . Tightening torque 80 Nm (59 lbf ft)
2. Fit the belt pulley cover.

In the method described below, the generator has already been removed.

Scheme 165

1. Remove the belt pulley cover.
2. Remove the belt pulley. NOTE: The belt pulley is threaded counter clockwise.

Scheme 166

1. Fit the belt pulley. Tightening torque 80 Nm (59 lbf ft)
2. Fit the belt pulley cover.

Scheme 167

In the method described below, the generator has already been removed.

1. Remove the protective housing from the generator.
2. Remove the voltage regulator.

The generator brushes are fixed to the voltage regulator. The whole unit must be replaced with a new one.

Scheme 168

1. Carefully straighten the spring tab so that it lies against the voltage regulator. Clean and apply a thin coating of Vaseline to avoid oxidation.
2. Clean the ground connection on the regulator and apply Vaseline.
3. Refit the voltage regulator.
4. Refit the protective housing on to the generator.

In the method described below, the generator has already been removed.

Scheme 169

Scheme 170

1. Remove the generator, see «GENERATOR, REMOVE AND INSTALL, Z18XE»(ref-275860-S09796562912007122900000) .
2. Remove the guard: Undo the bolts (1, 2) Pull off the guard
3. Remove the regulator: Undo the bolts (arrows)

In the method described below, the generator has already been removed.

Scheme 171

1. Remove the protective housing from the generator.
2. Remove the voltage regulator.

The generator brushes are fixed to the voltage regulator. The whole unit must be replaced with a new one.

Scheme 172

1. Carefully straighten the spring tab so that it lies against the voltage regulator. Clean and apply a thin coating of Vaseline to avoid oxidation.
2. Clean the ground connection on the regulator and apply Vaseline.
3. Refit the voltage regulator.
4. Refit the protective housing on to the generator.

Scheme 173

1. Hook the cover catches into the battery box.
2. Lower the cover.
3. Lock with lock screws.
4. Press the hose into place.
