Automatic Transmission - 5-SPEED & 6-SPEED: Specifications Saab 9-3 II

Automatic Trans 8 illustrations ~271 words

Engine torque

Current air mass/combustion is converted to torque, unit Nm. This information is sent continuously on the bus. TCM uses the information to control the transmission system pressure.

Maximum permissible torque

In order to obtain smoother shifting and minimum transmission wear, TCM continuously sends information on the bus concerning "maximum torque", unit Nm.

As the transmission is designed to withstand a maximum torque of 300 Nm (B207E/L), TCM will normally send bus information "Maximum torque 300 Nm" but for some gear changes, especially during rapid acceleration, TCM will request a lower "Maximum torque" during the brief period that gear changing takes place.

The Trionic system uses the information in its air mass control circuit for torque limitation.

Scheme 1

Scheme 1: 1st gear
Scheme 1: 1st gear
PositionS1S2S3S4S5C1C2C3B1B2B3B4B5F1F2
D1stONOFFONOFFOFFONOFFOFFOFFOFFOFFOFFONOFFON
L1st with engine brakeONOFFONOFFONONOFFOFFOFFOFFONOFFONOFFON

POWER FLOW REFERENCE - 1ST GEAR

Scheme 2

Scheme 2: 2nd gear
Scheme 2: 2nd gear
PositionS1S2S3S4S5C1C2C3B1B2B3B4B5F1F2
D2ndOFFONONOFFOFFONOFFOFFONONOFFOFFONONOFF

POWER FLOW REFERENCE - 2ND GEAR

Scheme 3

Scheme 3: 3rd gear
Scheme 3: 3rd gear
PositionS1S2S3S4S5C1C2C3B1B2B3B4B5F1F2
D3rdOFFONONONOFFONOFFOFFONONOFFONOFFONOFF

POWER FLOW REFERENCE - 3RD GEAR

Scheme 4

Scheme 4: 4th gear
Scheme 4: 4th gear
PositionS1S2S3S4S5C1C2C3B1B2B3B4B5F1F2
D4thOFFONOFFONOFFONOFFONONONOFFOFFOFFONOFF

POWER FLOW REFERENCE - 4TH GEAR

Scheme 5

Scheme 5: 5th gear
Scheme 5: 5th gear
PositionS1S2S3S4S5C1C2C3B1B2B3B4B5F1F2
D5thOFFOFFOFFONOFFONONONOFFONOFFOFFOFFOFFOFF

POWER FLOW REFERENCE - 5TH GEAR

Scheme 6

Scheme 6: Reverse gear
Scheme 6: Reverse gear
PositionS1S2S3S4S5C1C2C3B1B2B3B4B5F1F2
RSpeed < or = 7 km/hOFFOFFONOFFONOFFONOFFOFFOFFONOFFONOFFOFF
RSpeed > 7 km/hONOFFOFFOFFOFFOFFOFFOFFOFFOFFOFFOFFONOFFOFF

POWER FLOW REFERENCE - 4TH GEAR

Weight, fluid capacity and grade of fluid

Transmission, including fluidKg90
Fluid capacity (incl. torque converter and oil cooler)L7.2
Grade of fluidSaab 3309 40 - 93 160 393 Automatic transmission fluid (mineral oil based). Synthetic fluid has a coefficient of friction that differs from mineral oil-based fluid and should therefore not be used. The use of synthetic oil can cause malfunctions through abnormal wear.

WEIGHT, FLUID CAPACITY AND GRADE OF FLUID

Speed at 1000 rpm. Torque converter gear ratio 1:1

B207E/L195/65 R15205/65 R15215/60 R15215/55 R16225/45 R17235/45 R17225/45 R18
1st gearKm/h10.210.410.310.410.210.410.6
2nd gearKm/h15.715.915.815.915.715.916.3
3rd gearKm/h24.024.424.224.324.024.424.9
4th gearKm/h35.536.135.735.935.536.136.9
5th gearKm/h46.847.547.147.446.847.548.6
Reverse gearKm/h9.39.59.49.49.39.59.7

GEAR RATIOS

B207R215/55 R16225/45 R17235/45 R17225/45 R18
1st gearKm/h10.410.210.410.6
2nd gearKm/h15.915.715.916.3
21/2 gearKm/h20.920.721.021.5
3rd gearKm/h24.324.024.424.9
31/2 gearKm/h32.131.632.232.9
4th gearKm/h35.935.536.136.9
5th gearKm/h47.446.847.548.6
Reverse gearKm/h9.49.39.59.7

GEAR RATIOS

KM-574 Handle, torque converter

Group: Automatic transmission

9000900-M93900/9-39-59-3 s M03
X

SPECIAL TOOL COMPATIBILITY - KM-574 HANDLE, TORQUE CONVERTER

Z19DTH195/65 R15205/65 R15215/60 R15215/55 R16225/45 R17235/45 R17225/45 R18
1st gearKm/h10.510.710.610.610.510.710.9
2nd gearKm/h18.418.718.518.618.418.719.1
3rd gearKm/h28.028.528.228.428.028.529.1
4th gearKm/h37.738.338.038.237.738.339.2
5th gearKm/h50.751.551.051.350.751.552.7
6th gearKm/h63.564.563.964.363.564.566.0
Reverse gearKm/h12.813.012.913.012.813.013.3

GEAR RATIO

B284215/55 R16225/45 R17235/45 R17225/45 R18
1st gearKm/h8.98.78.99.1
2nd gearKm/h15.515.315.615.9
3rd gearKm/h23.623.323.724.2
4th gearKm/h31.831.431.932.7
5th gearKm/h42.842.242.943.9
6th gearKm/h53.652.953.855.0
Reverse gearKm/h10.810.710.911.1

GEAR RATIO

Weight, torque, fluid capacity and grade of fluid

Transmission, including fluidKg96
Maximum torque capacityNm450
Oil volume (total incl. torque converter at 75°C) Z19, B207L7.0
Oil volume (total incl. torque converter at 75°C) for B284L6.7
Oil volume (for oil change) Z19, B207L2.85
Oil volume (for oil change) for B284L2.55
Grade of fluid93 165 147 Automatic transmission fluid, mineral oil based. Synthetic oil has a coefficient of friction that differs from mineral oil based oil and should therefore not be used. The use of synthetic oil can cause malfunction through abnormal wear.

WEIGHT, TORQUE, FLUID CAPACITY AND GRADE OF FLUID

NmLbf ftDimension
Bearing cap, bearing bracket intermediate shaft107M6
Driver for torque converter, B207, Z19DTH3022M8
Driver for torque converter, B284, Z19DTR6044M10
Driver plate to crankshaft, B20763 +40°48 + 40°M10
Driver plate to crankshaft, Z19160118M10
Driver plate to crankshaft, B28430 +45°22 + 45°M10
Bearing bracket intermediate shaft4735M10
Gearbox to engine7052M12
Gearbox to engine4030M10
Selector lever107M6
Selector lever housing86M6
Lock nut for selector lever86M6
Oil plug, oil filler4533M10
Oil hoses to transmission64M6
Torque rod LH to gearbox console, -M0470 + 90°52 + 90°M12
Torque rod LH to subframe, -M0470 + 90°52 + 90°M12
Torque rod console LH to gearbox, -M049369M12
Torque rod RH to oil sump, -M043727
Torque rod RH to subframe, -M0470 + 90°52 + 90°
Torque rod to subframe, front M0560 + 90°44 + 90°
Torque rod to subframe, rear M058059
Wheels11081
Subframe to body75 + 90°55 + 90°M12
Subframe to body, rear bolts90 + 45°60 + 45°
Steering swivel member to ball joint5038M12
Anti-roll bar6447M12
Hub center-nut230170M24 x 1.5
Radiator bracket to subframe4735
Steering gear to subframe50 + 60°37 + 60°
Gear selector position sensor2518
Gear selector position sensor lever2015
Gear selector position sensor nut86
Ground cable to gearbox107
Oil cooler2418

AUTOMATIC TRANSMISSION TIGHTENING TORQUES

Scheme 7

Scheme 7: 83 95 170 Adapter
Scheme 7: 83 95 170 Adapter

Group: Miscellaneous

9000900-M93900/9-39-59-3 (9440)
XXX

SPECIAL TOOL COMPATIBILITY - 83 95 170 ADAPTER

Scheme 8

Scheme 8: 32 025 063 Special socket
Scheme 8: 32 025 063 Special socket

EN-47645 Special socket E14 Joint 3/8" 150 mm "MOMENTO"

9000900-M93900/9-39-59-3 (9440)
XX

SPECIAL TOOL COMPATIBILITY - 32 025 063 SPECIAL SOCKET
