Climate System: Specifications Saab 9-3 II

Automatic HVAC System 5 illustrations

Tightening torque

Torque (Nm)Torque (lbf ft)
Steering wheel member to body2418
Steering wheel member's lower mounting2418
Steering wheel member's mounting to the bulkhead partition space2418
Climate control unit86
Steering wheel member's lower mounting, center3324
Pedal bracket to the steering wheel member2418
Expansion valve1511
Expansion valve's PAD connection1511
PAD connection, front right structural member1511
Condenser's upper PAD connection1813
Condenser's lower PAD connection1813
A/C compressor2418
A/C compressor's PAD connection1813
Receiver's PAD connection1813
Receiver's high pressure pipe1813
Electromagnetic clutch's universal joint driver

TIGHTENING TORQUE

Scheme 1

Scheme 1: 82 92 948 Plugs, A/C system, kit
Scheme 1: 82 92 948 Plugs, A/C system, kit

Group: Body

9000900-M93900/9-39-59-3 (9440)
XXXXX

SPECIAL TOOL REFERENCE

Scheme 2

Scheme 2: 82 92 955 Spare parts kit, plugs
Scheme 2: 82 92 955 Spare parts kit, plugs

Group: Body

9000900-M93900/9-39-59-3 (9440)
XXXXX

SPECIAL TOOL REFERENCE

Scheme 3

Scheme 3: 82 93 474 Removal tool
Scheme 3: 82 93 474 Removal tool

Group: Body

9000900-M93900/9-39-59-3 (9440)
XXXXX

SPECIAL TOOL REFERENCE

Scheme 4

Scheme 4: 83 96 095 Release tool, belt circuit B207E/L
Scheme 4: 83 96 095 Release tool, belt circuit B207E/L
9000900-M93900/9-39-59-3 (9440)
X

SPECIAL TOOL REFERENCE

Scheme 5

Scheme 5: 85 80 144 Puller windscreen wiper arm
Scheme 5: 85 80 144 Puller windscreen wiper arm
9000900-M93900/9-39-59-3 (9440)
XXX

SPECIAL TOOL REFERENCE

Torque (Nm)Torque (lbf ft)
Steering wheel member to body2418
Steering wheel member's lower mounting2418
Steering wheel member's mounting to the bulkhead partition space2418
Climate control unit86
Steering wheel member's lower mounting, center3324
Pedal bracket to the steering wheel member2418
Expansion valve1511
Expansion valve's PAD connection1511
PAD connection, front right structural member1511
Condenser's upper PAD connection1813
Condenser's lower PAD connection1813
A/C compressor2418
A/C compressor's PAD connection1813
Receiver's PAD connection1813
Receiver's high pressure pipe1813
Electromagnetic clutch's universal joint driver

TIGHTENING TORQUE

Torque (Nm)Torque (lbf ft)
Steering wheel member to body2418
Steering wheel member's lower mounting2418
Steering wheel member's mounting to the bulkhead partition space2418
Climate control unit86
Steering wheel member's lower mounting, center3324
Pedal bracket to the steering wheel member2418
Expansion valve1511
Expansion valve's PAD connection1511
PAD connection, front right structural member1511
Condenser's upper PAD connection1813
Condenser's lower PAD connection1813
A/C compressor2418
A/C compressor's PAD connection1813
Receiver's PAD connection1813
Receiver's high pressure pipe1813
Electromagnetic clutch's universal joint driver

TIGHTENING TORQUE
