Identifying Control Module. Scheme 1
| Location | LHD | Above main relay board |
|---|---|---|
| RHD | Next to main relay board | |
| Number of pins | 70 | |
| Power supply (+B circuit) | Pin no. | 7 |
| Power supply (+15 circuit) | Pin no. | 64 |
| Power supply (+30 circuit) | Pin no. | 26 |
| Power supply (+54 circuit) | Pin no. | 31 |
| Power ground | Pin no. | 57 |
| Instrument bus, I-BUS (+) | Pin no. | 14 |
| Instrument bus, I-BUS (-) | Pin no. | 5 |
CONTROL MODULE SPECIFICATIONS
Measuring The Voltage Levels In The Control Module. Scheme 2
Windscreen And Rear Window Wiper Operation, Intermittent
The interval between strokes of the intermittent windscreen wiper operation can be adjusted between 2 and 15 seconds with a potentiometer located on the wiper stalk switch.
DICE also controls the wipers when the windscreen and rear window washers are operating. During a short wash, the wipers do three strokes and this increases to a maximum of five for longer washing times. The rear window wipers do a few strokes after a certain delay while washing.
The function "Extra strikes" after washing is programmable.
