Glass/window/mirrors: Overview Saab 9-2X I

Scheme 1

1. Windshield glass
2. Dam rubber
3. Molding
4. Rearview mirror mount
5. Locating pin
6. Fastener
7. Rear quarter glass
8. Locating pin
9. Glass
10. Spring
11. Seal

Scheme 2

1. Glass
2. Door sash (Front)
3. Door sash (Rear)
4. Weather strip
5. Stabilizer (Outer)
6. Stabilizer (Inner)
7. Regulator ASSY
8. Motor ASSY
9. Mirror gusset
10. Slider
11. Roller

Tightening torque: Nm (kgf-m, ft-lb)

T1: 7.4 (0.75, 5.5)

T2: 13.7 (1.4, 10.1)

Scheme 3

1. Glass
2. Door sash (Front)
3. Door sash (Rear)
4. Weather strip
5. Stabilizer (Outer)
6. Regulator ASSY
7. Stabilizer (Inner)
8. Motor ASSY

Tightening torque: Nm (kgf-m, ft-lb)

T1: 7.4 (0.75, 5.5)

T2: 13.7 (1.4, 10.1)

Scheme 4

1. Outer mirror
2. Inner rearview mirror
3. Mount
4. Spring
5. Mirror
6. Scalp cap
