Differentials: Overview Saab 9-2X I

Scheme 3

1. pinion hypoid driven gear and drive pinion set
2. Pinion height adjusting washer
3. Rear bearing
4. Bearing preload adjusting spacer
5. Bearing preload adjusting washer
6. Differential carrier
7. Front bearing
8. Spacer
9. Pilot bearing
10. Front oil seal
11. Companion flange
12. Self-locking nut
13. Side bearing
14. O-ring
15. Side bearing retainer shim
16. Side bearing retainer
17. Side oil seal
18. Side gear thrust washer
19. Side gear
20. Pinion mate gear
21. Pinion mate gear washer
22. Pinion shaft lock pin
23. Circlip
24. Pinion mate shaft
25. Air breather cap
26. Stud bolt
27. Oil filler plug
28. Oil drain plug
29. Rear cover
30. Differential case
31. Gasket

Tightening torque: Nm (kgfm, ft-lb)

T1: 10.3 (1.05, 7.6)

T2: 29 (3.0, 21.7)

T3: 49 (5.0, 36.2)

T4: 105 (10.7, 77.4)

T5: 181 (18.5, 134)

Scheme 4

1. Pinion hypoid driven gear and drive pinion set
2. Pinion height adjusting washer
3. Rear bearing
4. Bearing preload adjusting spacer
5. Bearing preload adjusting washer
6. Differential carrier
7. Front bearing
8. Collar
9. Pilot bearing
10. Front oil seal
11. Companion flange
12. Self-locking nut
13. Side bearing
14. O-ring
15. Side bearing retainer shim
16. Side bearing retainer
17. Side oil seal
18. Gasket
19. Differential case (Viscous coupling type)
20. Rear cover
21. Air breather cap
22. Stud bolt
23. Oil filler plug
24. Oil drain plug

Tightening torque: Nm (kgfm, ft-lb)

T1: 10.3 (1.05, 7.6)

T2: 29 (3.0, 21.7)

T3: 49 (5.0, 36.2)

T4: 105 (10.7, 77.4)

T5: 181 (18.5, 134)

Scheme 5

1. Differential front member
2. Plate
3. Crossmember
4. Differential rear member
5. Differential mount lower bracket
6. Stopper
7. Differential mount bracket
8. Differential mount front cover

Tightening torque: Nm (kgfm, ft-lb)

T1: 33 (3.4, 24.3)

T2: 60 (6.1, 44.3)

T3: 70 (7.1, 51.6)

T4: 90 (9.2, 66.4)

T5: 100 (10.2, 73.8)
