SPECIAL TOOL
Note. For special tool identification (Scheme 95)- (Scheme 123).
| TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|
| ST-398477701 | HANDLE | Used for installing front and rear bearing cone. |
| ST-398477702 | DRIFT | Used press-fitting the bearing cone of differential carrier (rear). |
| ST-398217700 | ATTACHMENT SET | Stand for rear differential carrier disassembly and assembly. |
| ST-498447120 | INSTALLER | Used for installing front oil seal. |
| ST-498427200 | FLANGE WRENCH | Used for stopping rotation of companion flange when loosening and tightening self-locking nut. |
| ST-398467700 | DRIFT | Used for removing pinion, pilot bearing and front bearing cone. |
| ST-399780104 | WEIGHT | Used for installing front bearing cone, pilot bearing companion flange. |
| ST-899580100 | INSTALLER | Used for press-fitting the front bearing cone, pilot bearing. |
| ST-899904100 | STRAIGHT PIN REMOVER | Used for driving out differential pinion shaft lock pin. |
| ST-498247001 | MAGNET BASE | Used for measuring backlash between side gear and pinion, and hypoid gear. Used with DIAL GAUGE (32005095). |
| ST-498247100 | DIAL GAUGE | Used measuring backlash between side gear and pinion, hypoid gear. Used with MAGNET BASE (32005094). |
| ST-398507704 | BLOCK | Used for adjusting pinion height and preload. |
| ST-398177700 | INSTALLER | Used for installing rear bearing cone. |
| ST-398457700 | ATTACHMENT | Used for removing side bearing retainer. |
| ST-398477703 | DRIFT2 | Used for press-fitting the bearing race (rear) of differential carrier. |
| ST-398437700 | DRIFT | Used for installing side oil seal. |
| ST-398507702 | DUMMY SHAFT | Used for adjusting pinion height and preload. |
| ST-398507703 | DUMMY COLLAR | Used for adjusting pinion height and preload. |
| ST-398517700 | REPLACER | Used for removing rear bearing cone. |
| ST-398487700 | DRIFT | Used for press-fitting the side bearing cone. |
| ST-398507701 | DIFFERENTIAL CARRIER GAUGE | Used for adjusting pinion height. |
| ST-398527700 | PULLER ASSY | Used for removing front oil seal. Used for removing side bearing cup. |
| ST-398227700 | WEIGHT | Used for installing side bearing. |
| ST28099PA090 | OIL SEAL PROTECTOR | Used for installing rear drive shaft into rear differential. For protecting oil seal. |
| ST-398237700 | GAUGE | Used for installing side bearing. |
| ST28099PA100 | DRIVE SHAFT REMOVER | Used for removing rear drive shaft from rear differential. |
| ST-399703600 | PULLER ASSY | Used for removing companion flange. |
| ST-899874100 | INSTALLER | Used for installing companion flange. |
| ST18759AA000 | PULLER ASSY | Used for removing side bearing cone of differential. |
