REPLACEMENT
Note. If a component is replaced, add an appropriate amount of compressor oil. When replacing the compressor, the new compressor will already have the specified amount of oil in it. Install the new compressor after removing the same amount of oil that is remaining in the compressor removed.
| Replacement parts | Amount of oil replenishment |
|---|---|
| Evaporator | 114 milliliters (3.9 US fl oz, 4.0 Imp fl oz) |
| Condenser | 7 milliliters (0.24 US fl oz, 0.25 Imp fl oz) |
| Hose | 1 milliliters (0.03 US fl oz, 0.04 Imp fl oz) |
REPLACEMENT PARTS AND AMOUNT OF OIL REPLENISHMENT REFERENCE
REMOVAL
Disconnect the ground cable from battery.
Remove the glove box.
Loosen the nut to remove the support beam stay.
Scheme 10
Disconnect the blower motor connector.
Scheme 11
Disconnect the power transistor or blower resistor connector.
Scheme 12
Loosen the bolt and nut to remove the blower motor unit assembly.
Scheme 13
INSTALLATION
Install in the reverse order of removal.
Tightening torque
Refer to COMPONENT in General Description.
Remove the glove box.
Disconnect the power transistor connector.
Loosen the two screws to remove the power transistor.
Scheme 14
Install in the reverse order of removal.
Remove the glove box.
Disconnect the blower resistor connector.
Loosen the two screws to remove the blower resistor.
Scheme 15
Install in the reverse order of removal.
Scheme 16
Measure the blower resistor resistance.
| Terminal No. | Standard |
|---|---|
| 3 and 1 | Approx. 0.51 O |
| 3 and 2 | Approx. 2.70 O |
| 3 and 4 | Approx. 1.43 O |
BLOWER RESISTOR RESISTANCE SPECIFICATIONS
If NG, replace the blower resistor.
Remove the heater and cooling unit.
Loosen the screws to remove the heater core cover.
Scheme 17
Remove the heater core.
Scheme 18
Install in the reverse order of removal.
Disconnect the ground terminal from battery.
Remove the glove box.
Remove the lower panel.
Remove the control wires.
Scheme 19
Remove the console front panel.
Remove the center console panel.
Scheme 20
- Clip
- Screw
Remove four screws.
Scheme 21
Pull out the control unit and disconnect connectors.
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the console front panel.
Remove the center console panel.
Disconnect the connector and aspirator hose (A).
Scheme 22
Install in the reverse order of removal.
Perform the compressor oil return operation.
Turn the A/C switch OFF and stop the engine.
Using the refrigerant recovery system, discharge refrigerant.
Disconnect the ground cable from battery.
Remove the V-belt. or
Remove the generator.
Remove the low-pressure hose and high-pressure hose.
Scheme 23
Disconnect the compressor harness from body harness.
Loosen the bolts to remove the compressor bracket.
Scheme 24
Remove the bolts, and then separate the compressor and bracket.
Scheme 25
Install in the reverse order of removal.
Replace the O-rings on low/high pressure hoses with new ones, then apply compressor oil.
When replacing compressor, adjust amount of compressor oil.
Charge refrigerant.
Tightening torque
Refer to COMPONENT in General Description.
Using the refrigerant recovery system, discharge refrigerant.
Disconnect the ground cable from battery.
Remove the front bumper.
Disconnect the pressure hose and pipe from condenser.
Scheme 26
Remove the radiator bracket (A).
Scheme 27
Remove the two bolts. While lifting the condenser, pull it out through the space between radiator and radiator panel.
Scheme 28
| IMPORTANT | Be careful not to damage the condenser fins. If a damaged fin is found, repair it using a thin screwdriver. If the condenser is replaced, add appropriate amount of compressor oil to the compressor. |
Install in the reverse order of removal.
| IMPORTANT | Replace the O-rings on hoses or pipes with new ones, and then apply compressor oil. Confirm that lower guide of condenser (A) has been fitted into holes on radiator panel. |
Scheme 29
Charge refrigerant.
Tightening torque
Refer to COMPONENT in General Description.
Disconnect the ground cable from battery.
Using the refrigerant recovery system, discharge refrigerant.
Drain LLC from the radiator.
Remove the bolt securing expansion valve and pipe in engine compartment. Release the heater hose clamps in engine compartment to remove the hoses.
Scheme 30
Remove the instrument panel.
Remove the support beam.
Remove the blower motor unit assembly.
Disconnect the servo motor connectors.
Loosen the bolt and nuts to remove the heater and cooling unit.
Scheme 31
Install in the reverse order of removal.
Charge refrigerant.
Tightening torque
Refer to COMPONENT in General Description.
Remove the heater and cooling unit.
Loosen the screws and clip to remove the evaporator cover.
Scheme 32
Remove the evaporator.
Scheme 33
Loosen the two bolts to remove the expansion valve.
Scheme 34
| IMPORTANT | If the evaporator is replaced, add appropriate amount of compressor oil to evaporator. |
Install in the reverse order of removal.
| IMPORTANT | When disconnecting/connecting hoses, do not apply excessive force to them. Confirm that no torsion and excessive tension exists after installing. Seal the disconnected hose with a plug or vinyl tape to prevent contamination from entering. |
Disconnect the ground cable from battery.
Using the refrigerant recovery system, discharge refrigerant.
Remove the evaporator unit mounting bolt (A).
Remove the low-pressure hose attaching bolts (B).
Disconnect the low-pressure hose from evaporator unit.
Disconnect the low-pressure hose from compressor.
Remove the low-pressure hose from vehicle.
Remove the high-pressure hose attaching bolts (C).
Disconnect the high-pressure hose from compressor.
Disconnect the high-pressure hose from condenser.
Remove the high-pressure hose from vehicle.
Remove the high-pressure tube attaching bolt (D).
Remove the high-pressure tube from vehicle.
Scheme 35
| IMPORTANT | When disconnecting/connecting hoses, do not apply an excessive force to them. Confirm that no torsion and excessive tension exists after installing. Seal the disconnected hose with a plug or vinyl tape to prevent contamination from entering. |
Install in the reverse order of removal.
Charge refrigerant.
Tightening torque
Refer to COMPONENT in General Description.
Open the hood.
Disconnect the ground cable from battery.
Disconnect the ambient sensor connector.
Remove the ambient sensor from radiator lower panel.
Scheme 36
Install in the reverse order of removal.
Disconnect the ground cable from battery.
Remove the front defroster grille.
Disconnect the sunload sensor connector (A).
Scheme 37
| IMPORTANT | Be careful not to damage the sensors and interior trims when removing them. |
Install in the reverse order of removal.
Install in the reverse order of removal.
Remove the front seats.
Remove the console box.
Remove the side sill front cover, side sill rear cover and center pillar lower trim.
Remove the foot rest.
Remove the clips from floor mat.
Remove the mat hook.
Remove the mat from toe board area.
Remove the rear heater duct cover (A). Draw out the rear heater duct from the unit assembly and slide it forward to remove.
Scheme 38
Install in the reverse order of removal.
Note. Secure the mat firmly with hook and Velcro tape. Insert the mat edge firmly into the groove of side sill cover.
Remove the instrument panel.
Remove the screws.
Remove the heater vent duct.
Scheme 39
Install in the reverse order of removal.
