Airbag System: Overview Saab 9-2X I

Scheme 1

1. Combination switch ASSY with roll connector
2. TORX(R) bolt T30
3. Airbag module ASSY (Driver's side)
4. Airbag module ASSY (Passenger's side)
5. Airbag control module
6. Hexagon head bolt (exclusive use)
7. Side airbag sensor
8. Side airbag harness
9. Side airbag module
10. Airbag main harness
11. Front sub sensor harness
12. Front sub sensor
13. TORX(R) bolt T30

Tightening torque: Nm (kgf-m, ft-lb)

T1: 5.9 (0.59, 4.4)

T2: 7.4 (0.75, 5.4)

T3: 10 (1.0, 7.2)

T4: 20 (2.0, 14.5)

T5: 25 (2.5, 18.1)
