SPECIAL TOOL
TEST HARNESS M
| TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|
| ST-98299FE020. (Scheme 70) | TEST HARNESS M | Used when measuring voltage, resistance of airbag system. Used with test harness T (32005234) |
SPECIAL TOOLS DESCRIPTION
Scheme 70
Scheme 71
TEST HARNESS F
| TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|
| ST-98299FC010. (Scheme 72) | TEST HARNESS F | Used when measuring voltage, resistance of airbag module harness. |
SPECIAL TOOLS DESCRIPTION
Scheme 72
Scheme 73
TEST HARNESS V
| TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|
| ST-98299AG010. (Scheme 74) | TEST HARNESS V | Used when measuring voltage and resistance of side airbag sensor and curtain airbag sensor. |
SPECIAL TOOLS DESCRIPTION
Scheme 74
Scheme 75
| TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|
| ST-98299FA030. (Scheme 76) | TEST HARNESS H | Used when measuring voltage, resistance of front sub sensor. |
SPECIAL TOOLS DESCRIPTION
Scheme 76
Scheme 77
TEST HARNESS L
| TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|
| ST-98299FE000. (Scheme 78) | TEST HARNESS L | Used when measuring voltage, resistance of seat belt pretensioner. |
SPECIAL TOOLS DESCRIPTION
Scheme 78
Scheme 79
TEST HARNESS R
| TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|
| ST-98299FE030. (Scheme 80) | TEST HARNESS R | Used when measuring voltage, resistance of airbag control module. |
SPECIAL TOOLS DESCRIPTION
Scheme 80
TEST HARNESS N
| TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|
| ST-98299SA000. (Scheme 81) | TEST HARNESS N | Used when measuring voltage, resistance of driver's airbag module and seat belt pretensioner. |
SPECIAL TOOLS DESCRIPTION
Scheme 81
Scheme 82
TEST HARNESS T
| TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|
| ST-98299SA060. (Scheme 83) | TEST HARNESS T | Used when measuring voltage, resistance of airbag system. Used with test harness M (32005229). |
SPECIAL TOOLS DESCRIPTION
Scheme 83
Scheme 84
AIRBAG RESISTOR
| TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|
| ST-98299PA040. (Scheme 85) | AIRBAG RESISTOR | Used in replacement of airbag module which resistance value is same as airbag module. |
SPECIAL TOOLS DESCRIPTION
Scheme 85
Scheme 86
Scheme 87
Scheme 88
Scheme 89
Scheme 90
Scheme 91
Scheme 92
Scheme 93
Scheme 94
Scheme 95
Scheme 96
Scheme 97
Scheme 98
Scheme 99
Scheme 100
- When servicing a vehicle, be sure to turn the ignition switch to OFF, disconnect the ground cable from battery, and wait for more than 20 seconds before starting work.
- The airbag system is fitted with a backup power source. If the airbag system is serviced within 20 seconds after the ground cable is disconnected, it may inflate.
- If sensors, airbag module, airbag control module, pretensioner, and harness are deformed or damaged, replace them with new genuine parts.
- Do not use the airbag system and pretensioners on other vehicles. When replacing parts, be sure to replace them with new parts.
- When checking the airbag system, be sure to use a digital circuit tester. Use of an analog circuit tester may cause the airbag to activate erroneously.
- When checking, use a test harness. Do not directly apply the tester probe to any connector terminal of the airbag. Test harness
- Do not drop the airbag modulator parts, subject them to high temperature over 93°C (199°F), or let water, oil, or grease get on them; otherwise, the internal parts may be damaged and may be reliability greatly lowered.
- If any damage, opening, or rust is found on the airbag system wire harness, do not attempt to repair using soldering equipment. Be sure to replace the faulty harness with a new genuine part.
- Install the wire harness securely with the specified clips to avoid interference or tangled up with other parts.
- Do not allow water or oil to come in contact with the connector terminals. Do not touch the connector terminals.
- Either of the airbag modules for driver, passenger or side, or pretensioner must not be disassembled.
- The airbag module cannot be used again if once inflated.
- After removal, keep the airbag module with the pad facing upward on a dry, clean, and flat surface away from heat and light sources, and moisture and dust.
- Do not check continuity of either of the airbag modules for driver, passenger or side, or pretensioner.
- The removed front seat with the airbag module must be kept at least 200 mm (8 in) away from walls and other objects. More than 200 mm (8 in)
- When painting or performing sheet metal work on the front part of the vehicle, including the front wheel apron, front fender, and front side frame, remove the front sub sensors and wire harness of the airbag system.
- When painting or performing sheet metal work on the side of the vehicle, including the side sill, center pillar, and front and rear doors, remove the side airbag sensors and wire harness of the airbag system.
- Do not discard undeployed airbag modules. They could easily cause a serious accident if accidentally deployed.
- When storing a removed airbag module, do not place any objects on it or pile airbag modules on top of each other. If the airbag inflates for some reason when it is placed with its pad side facing downward or under any object, a serious accident may result. Driver side airbag module Passenger side airbag module
Scheme 101
- Front sub sensor (LH)
- Front sub sensor (RH)
- Front sub sensor harness (LH)
- Front sub sensor harness (RH)
- Airbag control module with built-in safety and electric sensor
- Passenger's airbag inflator
- Roll connector
- Airbag main harness
- Driver's airbag inflator
- Side airbag harness (LH)
- Side airbag harness (RH)
- Side airbag sensor (LH)
- Side airbag sensor (RH)
- Side airbag inflator (LH)
- Side airbag inflator (RH) To body harness To seat belt pretensioner (LH) To seat belt pretensioner (RH)
| Connector No. | (AB1) | (AB2) | (AB3) | (AB4) | (AB7) | (AB8) | (AB9) | (AB10) | (AB11) | (AB12) | (AB13) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Pole | 6 | 2 | 28 | 4 | 12 | 12 | 2 | 4 | 2 | 4 | 2 |
| Color | Yellow | Black | Yellow | Yellow | Yellow | Yellow | Yellow | Yellow | Yellow | Yellow | Yellow |
| Male/Female | Male | Female | Female | Female | Female | Female | Female | Female | Female | Female | Female |
| Connector No. | (AB15) | (AB18) | (AB19) | (AB20) | (AB21) | (AB26) | (AB27) | (AB28) | (AB29) | ||
| Pole | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | ||
| Color | Yellow | Yellow | Black | Black | Yellow | Yellow | Yellow | Yellow | Yellow | ||
| Male/Female | Female | Female | Female | Female | Female | Male | Male | Male | Male |
CONNECTOR REFERENCE
