NV273 Transfer Case - Service Information: Specifications RAM Cab & Chassis 3500 HD

Transfer Case 1 illustration ~110 words

SPECIFICATIONS

DESCRIPTIONN-mFt. Lbs.In. Lbs.
Plug, Detent16-2412-18
Plug, Drain/Fill20-3415-25
Bolt, Extension Housing27-3420-25
Bolt, Case Half27-3420-25
Support, Sector27-3420-25
Nuts, Mounting30-4120-30
Bolts, Shift Motor and Mode Sensor Assembly16-2512-18
Nut, Companion Flange176-271130-200
Bolts, Transfer Case to Transmission16-2412-18

Scheme 68

Scheme 68: REMOVAL
1 - TRANSMISSION
2 - TRANSFER CASE
3 - MODE SENSOR CONNECTOR
  1. Shift transfer case into 2WD.
  2. Raise vehicle.
  3. Drain transfer case lubricant.
  4. Remove the transfer case skid plate, if equipped.
  5. Support transmission with jack stand.
  6. Remove crossmember and transmission mount.
  7. Mark front and rear propeller shafts for alignment reference.
  8. Remove front and rear propeller shafts.
  9. Disconnect transfer case shift motor and mode sensor wire connectors (3). (Scheme 68)
  10. Disconnect transfer case vent hose.
  11. Support transfer case with transmission jack.
  12. Secure transfer case to jack with chains.
  13. Remove nuts attaching transfer case (2) to transmission (1).
  14. Pull transfer case and jack rearward to disengage transfer case.
  15. Remove transfer case from under vehicle.
