BW44-46 Transfer Case - Service Information: Specifications RAM Cab & Chassis 3500 HD

TORQUE SPECIFICATIONS

Scheme 135

1. Raise vehicle.
2. Drain transfer case lubricant.
3. Mark front and rear propeller shafts for alignment reference.
4. Support transmission with jack stand.
5. Remove the transfer case skid plate, if equipped.
6. Disconnect front and rear propeller shafts at transfer case.
7. Disconnect transfer case shift motor and mode sensor wire connectors (3).
8. Disconnect transfer case vent hose.
9. Support transfer case with transmission jack.
10. Secure transfer case to jack with chains.
11. Remove nuts attaching transfer case (2) to transmission (1).
12. Pull transfer case and jack rearward to disengage transfer case.
13. Remove transfer case from under vehicle.

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

1. Place the transfer case so that it can be drained of any remaining fluid and remove the fill (4) and drain plugs (1).
2. Remove the four shift motor mounting bolt (2) and remove the shift motor (3).
3. Remove the rear output shaft flange nut (1), if equipped.
4. Remove the flange spacer (1), if equipped.
5. Remove the flange dust seal, if equipped.
6. Using a suitable puller, remove the output flange, if equipped.
7. Remove all of the case half bolts (1).
8. Carefully using a prybar at pry points (2), separate and remove the rear case half.
9. Remove the retaining ring (1).
10. Remove the locking collar (1).
11. Remove the mode shift fork, spring and sleeve (1) from the main shaft (2).
12. Remove the chain (2), the front out put gear (1) and main shaft gear (3) as an assembly. NOTE: There are three alignment tabs and an oil pump hose pass through incorporated into the support that prevent the structure from rotating once installed.
13. Remove the center bearing support assembly (2) from the mainshaft (1).
14. Remove the oil pump (1).
15. Remove the magnet (1).
16. Remove the shift assembly (1).
17. Remove the mainshaft.
18. Remove the shift rail (1), lower shift fork (3), and the reduction hub as an assembly.
19. Separate the lower shift fork (3) from the reduction hub (2).
20. Separate the lower shift fork (3) from the shift rail (1).
21. Lift the planetary carrier (1) straight up and out of the annulus gear (2). NOTE: Bearing tabs face upward.
22. Remove the carrier thrust bearing (1) from the center of the planetary (2).
23. Remove the annulus gear retainer (1).
24. Remove the annulus gear (1).
25. Remove the front output shaft retaining ring (1) from the front output shaft (2).
26. Remove the front output shaft (1) from the front case half (2).
27. Remove front output shaft seal.
28. Using (special tool #9622, Installer, Countershaft Plug) (1) and (special tool #C-4171, Driver Handle, Universal) (2), remove the front output shaft bearing from the case half (3).
29. Remove input shaft seal.
30. Using (special tool #9622, Installer, Countershaft Plug) (1) and (special tool #C-4171, Driver Handle, Universal) (2), remove the input shaft bearing from the case half (3).
31. Remove rear output shaft seal.
32. Using (special tool #5066, Installer, Bushing) and (special tool #C-4171, Driver Handle, Universal) (1), remove the input shaft bearing from the case half (2).
33. Secure the rear case half.
