Chemical Test Method: Overview RAM Cab & Chassis 3500 HD

Combustion leaks into the cooling system can also be checked by using the Bloc-Chek Kit (special tool #C-3685-A, Bloc-Chek Kit) or equivalent. Perform the test following the procedures supplied with the tool kit.

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

1. Remove the cowl grille (4).
2. Remove the engine cover (1). Refer to «COVER, ENGINE, INSTALLATION, 5.7L»(ref-476518-S33162728662012060400000) .
3. Perform the Fuel System Pressure Release procedure. Refer to «FUEL SYSTEM PRESSURE RELEASE»(ref-476558-S31136018322012060400000) .
4. Disconnect the fuel supply line. Refer to «STANDARD PROCEDURE - QUICK-CONNECT FITTINGS»(ref-476558-S38056121542012060400000) .
5. Disconnect and isolate the negative battery cable (2).
6. Drain the cooling system. Refer to «STANDARD PROCEDURE»(ref-476513-S07101829012012060400000) .
7. Remove the air cleaner assembly. Refer to «BODY, AIR CLEANER, REMOVAL, 5.7L»(ref-476518-S29574068052012060400000) .
8. Remove closed crankcase ventilation system. CAUTION: When servicing or replacing exhaust system components, disconnect the oxygen sensor connector(s). Allowing the exhaust to hang by the oxygen sensor wires will damage the harness and/or sensor.
9. Disconnect the oxygen sensor connectors (2).
10. Saturate all exhaust bolts and nuts with Mopar® Rust Penetrant. Allow 5 minutes for penetration. NOTE: If separating the exhaust pipe/catalytic converter at the exhaust manifold flange. New bolts will be required.
11. Remove the exhaust pipe to manifold bolts (3) (left side shown in illustration, right side similar) and disconnect the front exhaust pipe/catalytic converter assembly (4). Discard the nuts and bolts.
12. Disconnect the evaporation control system.
13. Disconnect the heater hoses (2). CAUTION: Do not let the tensioner arm snap back to the free arm position, sever damage may occur to the tensioner.
14. Insert a suitable square drive ratchet into the square hole on belt tensioner arm (7).
15. Release the belt tension by rotating the tensioner arm (7) clockwise . Rotate the belt tensioner arm (7) until the belt can be removed from the pulleys.
16. Remove the accessory drive belt.
17. Gently release the tensioner arm (7). NOTE: It is not necessary to disconnect the hoses from the power steering pump, for power steering pump removal.
18. Remove the three power steering pump (1) mounting bolts (2) through the access holes in the pulley and secure out of the way.
19. Remove the cylinder head covers and gaskets. Refer to «COVER(S), CYLINDER HEAD, REMOVAL, 5.7L»(ref-476518-S01379202482012060400000) .
20. Remove the intake manifold and throttle body as an assembly. Refer to «MANIFOLD, INTAKE, REMOVAL, 5.7L»(ref-476518-S17277474012012060400000) . CAUTION: Rocker arm assemblies and pushrods must be installed in their original locations or engine damage could result.
21. Identify the original locations for assembly, remove rocker arm assemblies and pushrods. Refer to «ROCKER ARM, VALVE, REMOVAL, 5.7L»(ref-476518-S07692378672012060400000) .
22. Using the sequence shown in illustration, remove the head bolts from each cylinder head. Remove the cylinder head and discard the cylinder head gasket.
