Camshaft Core Hole Plug: Overview RAM Cab & Chassis 3500 HD

Mechanical 7 illustrations ~677 words
  1. Clean the core hole in the cylinder block. NOTE: Do not apply adhesive to the new camshaft core hole plug. A new plug has adhesive pre-applied.
  2. Install a new camshaft core hole plug (1) located at the rear of cylinder block, using a suitable flat faced tool. The plug must be fully seated on the cylinder block shoulder.
  3. Install the flexplate. Refer to «FLEXPLATE, INSTALLATION, 5.7L»(ref-476518-S24511482552012060400000) .
  4. Install the engine. Refer to «INSTALLATION, 5.7L»(ref-476518-S29366604722012060400000) .

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87

Scheme 88

Scheme 88
Scheme 88

Scheme 89

Scheme 89
Scheme 89
  1. Lubricate the camshaft lobes and camshaft bearing journals and insert the camshaft (1). NOTE: Ensure that the plate is installed on the correct side. The fasteners are flat head fasteners so the top of the head of the fastener should not stick above the front face of the plate after they are torqued. The plate has chamfered fastener holes and the chamfered side should be facing forward to ensure the fasteners are flush or below the front surface.
  2. Install the camshaft thrust plate (1).
  3. Using the sequence shown in illustration, tighten the bolts to 12 N.m (9 ft. lbs.). NOTE: The camshaft phaser must be installed before the camshaft end play can be measured.
  4. Measure camshaft end play. Refer to «Engine - Specifications»(ref-476518-S29189367412012060400000) .
  5. If not within limits, disassemble, clean, and inspect for burrs or debris. Reassemble and measure end play again. If the end play is still out, then install a new thrust plate.
  6. Install the timing chain (5) and sprockets (1, 3). Refer to «CHAIN AND SPROCKETS, TIMING, INSTALLATION, 5.7L»(ref-476518-S39750828302012060400000) .
  7. Install the timing chain tensioner arm (4) and guide (2).
  8. Remove the tensioner pin (special tool #8514, Pins, Tensioner) (1).
  9. Install the oil pump (1) and tighten bolts to 28 N.m (21 ft. lbs.). Refer to «PUMP, ENGINE OIL, INSTALLATION, 5.7L»(ref-476518-S39247865552012060400000) .
  10. Inspect the oil pick up tube O-rings and replace as necessary.
  11. Install the oil pick up tube (1) and tighten fasteners (2) to 28 N.m (21 ft. lbs.).
  12. Install the timing chain cover. Refer to «COVER(S), ENGINE TIMING, INSTALLATION, 5.7L»(ref-476518-S35543616332012060400000) .
  13. Install the oil pan. Refer to «PAN, OIL, INSTALLATION, 5.7L»(ref-476518-S08996329102012060400000) . CAUTION: Engines equipped with MDS use both standard roller lifters (2) and deactivating roller lifters (1). The deactivating roller lifters must be used in cylinders 1, 4, 6, 7. The deactivating lifters can be identified by the two holes in the side of the lifter body (3), for the latching pins. NOTE: Each tappet reused must be installed in the same position from which it was removed. When camshaft is replaced, all of the tappets must be replaced.
  14. Install the rear MDS lifter assembly (2) and tighten bolt (1) to 12 N.m (106 in. lbs.)
  15. Install the front MDS lifter assembly (2) and tighten bolt (1) to 12 N.m (106 in. lbs.).
  16. Install both the left and right cylinder heads (4). Refer to «CYLINDER HEAD, INSTALLATION, 5.7L»(ref-476518-S06920310142012060400000) .
  17. Install pushrods.
  18. Install rocker arms. Refer to «ROCKER ARM, VALVE, INSTALLATION, 5.7L»(ref-476518-S00844730812012060400000) .
  19. Install cylinder head covers. Refer to «COVER(S), CYLINDER HEAD, INSTALLATION, 5.7L»(ref-476518-S24184402652012060400000) .
  20. Install the intake manifold. Refer to «MANIFOLD, INTAKE, INSTALLATION, 5.7L»(ref-476518-S24872514842012060400000) .
  21. Install the generator (2).
  22. Install the power steering pump (3).
  23. Install the accessory drive belt (1). Refer to «BELT, SERPENTINE, INSTALLATION»(ref-476513-S03685655272012060400000) .
  24. Install the radiator. Refer to «RADIATOR, ENGINE COOLING, INSTALLATION»(ref-476513-S11026862522012060400000) .
  25. Install the air cleaner assembly. Refer to «BODY, AIR CLEANER, INSTALLATION, 5.7L»(ref-476518-S17318564912012060400000) .
  26. Install the negative battery cable.
  27. Fill the radiator with coolant. Refer to «STANDARD PROCEDURE»(ref-476513-S07101829012012060400000) .
  28. Fill the engine with oil. Refer to «FILTER, ENGINE OIL, INSTALLATION, 5.7L»(ref-476518-S10211005842012060400000) .
  29. Start the engine and check for leaks.

Scheme 90

Scheme 90: REMOVAL
Scheme 90: REMOVAL

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92
  1. Raise and support the vehicle.
  2. Remove the steering rack to frame mounting bolts (1) and lower the steering rack enough to gain clearance for the structural dust cover removal.
  3. Remove the transmission mount to crossmember retaining nuts (1).
  4. Using a suitable jack, lift the transmission enough to gain clearance for the structural dust cover removal.
  5. Remove the structural dust cover retaining bolts (1, 3 & 4).
  6. Remove the structural dust cover (2).
