Assembling control mechanism for transmission
| No. | Designation | Qty. | Installation |
|---|---|---|---|
| 1- see scheme 24 | Control mechanism for transmission | 1 | See > 387719 Control mechanism for transmission |
| 2 | Wire harness | 1 | Engage wire harness in brackets and connect plug connections to solenoid valves and transmission input speed sender. |
| 3 | O-ring | 2 | Always replace and coat with Vaseline |
| 4 | Screw | 1 | Tightening torque : 6 Nm (4.5 ftlb.) |
| 5 | Transmission input speed sender | 1 | |
| 6 | Spacer sleeve (20 mm) | 1 | |
| 7 | Screw | 1 | Tightening torque : 6 Nm (4.5 ftlb.) |
| 8 | Holder | 1 | |
| 9 | Pressure regulator 1 and O-ring | 1 | |
| 10 | Screw | 4 | Tightening torque : 6 Nm (4.5 ftlb.) |
| 11 | Holder | 2 | |
| 12 | Solenoid valve 1 | 1 | Do not tighten screws for guide plate in selector lever position "P". Tightening torque : 6 Nm (4.5 ftlb.) |
| 13 | Pressure regulator 2 and O-ring | 1 | Thinly coat O-ring with Vaseline |
| 14 | Pressure regulator 4 and O-ring | 1 | Thinly coat O-ring with Vaseline |
| 15 | Pressure regulator 3 and O-ring | 1 | Thinly coat O-ring with Vaseline |
| 16 | Solenoid valve 1 | 1 | |
| 17 | Solenoid valve 1 | 1 | |
| 18 | Screw | 1 | Tightening torque : 6 Nm (4.5 ftlb.) |
| 19 | Transmission speed sender | 1 | |
| 20 | Spacer sleeve (8 mm) | 1 | |
| 21 | Oil pipe | 1 | |
| 22 | O-ring | 2 | Always replace and coat with Vaseline |
Instructions for assembling control mechanism
Note. The ATF temperature sender is integrated in the wire harness. Therefore, in the case of damage, the entire wire harness must be replaced. In the event of mechanical stress (e. g. if it falls) the transmission input speed sender or the transmission speed sender must not be reinstalled as the permanent magnet will have been destroyed. Always replace an oil pipe that has been removed. Always insert an oil pipe using an insertion aid 3381 as otherwise the oil pipe can be bent.
1. Coat new oil pipe -21- and new O-rings -22- lightly with Vaseline. see scheme 25
Scheme 88
2. Insert oil pipe into insertion aid 3381 and drive evenly into transmission housing as far as the stop on the tool. The open side of the tool should face the outer wall of the transmission.
Scheme 89
3. Screw in transmission speed sender -19- and spacer (8 mm) -20- and tighten screw -18-. see scheme 25
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|---|---|---|---|---|
| Fastening screw for transmission input speed sender | Tightening torque | 6 (4.5 ftlb.) Nm |
Scheme 90
4. Screw in transmission input speed sender -5- and spacers (20 mm) -6- and tighten screws -4-. see scheme 25
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|---|---|---|---|---|
| Fastening screw for transmission input speed sender | Tightening torque | 6 (4.5 ftlb.) Nm |
Scheme 91
5. Insert wiring harness -2- with the flat point facing the ATF pan. see scheme 25
