Draining ATF
| CAUTION | Transmission cannot be filled, or only insufficiently with ATF. |
> Do not start engine
> Do not tow vehicle
Scheme 2
| WARNING | Danger of scalding and chemical burns from hot ATF |
> Allow ATF to cool down
> Wear personal protective gear (goggles, gloves)
1. Unscrew ATF drain plug -1- and drain ATF. see scheme 3
2. Replace sealing ring for drain plug and tighten screw. --> Tightening torque: 30 ftlb. .
| CAUTION | Transmission cannot be filled, or only insufficiently with ATF. |
> Do not start engine
> Do not tow vehicle
| WARNING | Danger of scalding and chemical burns from hot ATF |
> Allow ATF to cool down
> Wear personal protective gear (goggles, gloves)
1. Unscrew ATF drain plug -1- and drain ATF. see scheme 240
2. Replace sealing ring for drain plug and tighten screw. --> Tightening torque: 30 ftlb. .
Scheme 3
1. Remove screws -1-. see scheme 241
2. Remove ATF- pan -2- with seal -3-. Pay attention to the magnet -4-. see scheme 241
| CAUTION | Transmission cannot be filled, or only insufficiently with ATF. |
> Do not start engine
> Do not tow vehicle
| WARNING | Danger of scalding and chemical burns from hot ATF |
> Allow ATF to cool down
> Wear personal protective gear (goggles, gloves)
1. Unscrew ATF drain plug -1- and drain ATF. see scheme 245
2. Replace sealing ring for drain plug and tighten screw. --> Tightening torque: 30 ftlb. .
