Tools
Designation Type Number Explanation hose clamp VW-tool 3094
Preliminary work
1. Raise the vehicle at the prescribed jacking points. Refer to 40 Tightening torques for front axle - as of MY 2005 (All Models) .
2. Remove rear underside panel. Refer to 51 94 19 Removing and installing cover for rear underbody - as of MY 2005 (All Models) .
Scheme 92
1. Clamp shut coolant hoses (flow and return sides) with Hose clamp 3094 ( Tools ).
2. Place collection pan for coolant under the transmission.
Scheme 93
Note. If necessary, use a mirror when screwing in and unscrewing the top screws.
3. Unscrew fastening screws between ATF cooler and port plate and remove ATF cooler.
Scheme 94
1. Insert new sealing rings in port plate.
Scheme 95
2. Insert new sealing rings for ATF cooler.
Note. If necessary, use a mirror when screwing in and unscrewing the top screws.
3. Position ATF cooler on port plate and screw in screws.
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|---|---|---|---|---|
| ATF cooler to port plate | Fastening screws between ATF-cooler and port plate | Tightening torque | 10 (7.5 ftlb.) Nm |
4. Remove Hose clamp 3094 ( Tools ) from coolant pipes (flow and return sides).
Subsequent work
1. Fill in coolant and bleed cooling system. Refer to 19 38 17 Draining and filling in coolant - as of MY 2005 (All Models) .
2. Check and if necessary, top up the ATF. Refer to 37 02 35 Checking and topping up ATF - as of MY 2005 (All Models) .
3. Install rear underside panel. Refer to 51 94 19 Removing and installing cover for rear underbody - as of MY 2005 (All Models) .
Designation Type Number Explanation hose clamp VW-tool 3094
1. Raise the vehicle at the prescribed jacking points. Refer to 40 Tightening torques for front axle - as of MY 2005 (All Models) .
2. Remove rear underside panel. Refer to 51 94 19 Removing and installing cover for rear underbody - as of MY 2005 (All Models) .
3. Remove rear silencer. Refer to 26 33 19 Removing and installing rear silencer - as of MY 2005 (Boxster, Boxster RHD, Boxster S, Boxster S RHD) . Refer to 26 33 19 Removing and installing rear silencer - as of MY 2005 (Cayman S, Cayman S RHD) .
Removing port plate for ATF cooler
1. Clamp shut coolant hoses (flow and return sides) with hose clamp 3094 .
Scheme 96
2. Unscrew fastening screws between transmission and mount for exhaust system and remove mount for exhaust system.
3. Place collection pan for coolant under the transmission.
Scheme 97
4. Unscrew fastening screw between ATF cooler and coolant line and pull coolant line out of ATF cooler.
Scheme 98
5. Unscrew fastening screw between ATF cooler and coolant line and pull coolant line out of ATF cooler.
Note. If necessary, use a mirror when screwing in and unscrewing the top screws.
6. Unscrew fastening screws between ATF cooler and port plate and remove ATF cooler.
Scheme 99
7. Unscrew fastening screws between port plate and transmission housing and remove port plate.
Installing port plate for ATF cooler
1. Position port plate with new sealing rings on transmission housing and screw in fastening screws.
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|---|---|---|---|---|
| Port plate to transmission housing | Fastening screws between port plate and transmission housing | Tightening torque | 10 (7.5 ftlb.) Nm |
Note. If necessary, use a mirror when screwing in and unscrewing the top screws.
2. Position ATF cooler on port plate and screw in screws.
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|---|---|---|---|---|
| ATF cooler to port plate | Fastening screws between ATF-cooler and port plate | Tightening torque | 10 (7.5 ftlb.) Nm |
3. Insert coolant pipe with new O-ring in ATF cooler and screw in fastening screw.
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|---|---|---|---|---|
| Fastening screw | Fastening screws between coolant pipes and ATF cooler | Tightening torque | 23 (17 ftlb.) Nm |
4. Insert coolant pipe with new O-ring in ATF cooler and screw in fastening screw.
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|---|---|---|---|---|
| Fastening screw | Fastening screws between coolant pipes and ATF cooler | Tightening torque | 23 (17 ftlb.) Nm |
5. Install engine mount for exhaust system and tighten fastening screws between transmission and engine mount for exhaust system.
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|---|---|---|---|---|
| Exhaust system mount | Fastening screws between transmission housing mount | Tightening torque | 45 (33 ftlb.) Nm |
6. Remove hose clamp 3094 from coolant pipes (flow and return sides).
1. Install rear mufflers. Refer to 26 33 19 Removing and installing rear silencer - as of MY 2005 (Boxster, Boxster RHD, Boxster S, Boxster S RHD) . Refer to 26 33 19 Removing and installing rear silencer - as of MY 2005 (Cayman S, Cayman S RHD) .
2. Fill in coolant and bleed cooling system. Refer to 19 38 17 Draining and filling in coolant - as of MY 2005 (All Models) .
3. Check and if necessary, top up the ATF. Refer to 37 02 35 Checking and topping up ATF - as of MY 2005 (All Models) .
4. Install rear underside panel. Refer to 51 94 19 Removing and installing cover for rear underbody - as of MY 2005 (All Models) .
Notes
Note. Fill only with ATF approved by Porsche. See Spare Parts Catalogue. Hot vehicles should cool down before beginning the activity. Vehicle must be horizontal in order to be filled and checked.
1. Raise the vehicle at the prescribed jacking points. Refer to 40 Tightening torques for front axle - as of MY 2005 (All Models) .
2. Remove support plate. Refer to 42 14 19 Removing and installing support plate - as of MY 2005 (All Models) .
3. Drain ATF. Refer to 37 02 55 Changing ATF - as of MY 2005 (All Models) .
4. Remove ATF pan. Refer to 37 55 19 Removing and installing ATF pan - as of MY 2005 (All Models) .
5. Remove ATF filter. Refer to 37 58 55 Replacing ATF filter - as of MY 2005 (All Models) .
Scheme 100
1. Pull off securing clasp for wiring harness plug.
Scheme 101
2. Pull off transmission speed connector.
Scheme 102
3. Unscrew designated fastening screws for hydraulic control unit.
Note. Do not set down removed control mechanism for transmission on transmission input speed sender (rear of control mechanism). This can damage the sender.
4. Removed control mechanism from transmission and follow up wiring harness plug.
Installing control mechanism for transmission
1. Thinly coat Toroidal sealing ring for wiring harness plug with Vaseline and insert plug into transmission housing.
Scheme 103
2. Carefully position control mechanism and insert pin -1- of detent disc into groove of selector valve -2- .
3. Screw in fastening screws for control mechanism until hand-tight.
4. Tighten fastening screws from inside outwards.
| Location | Explanation | Type | Basic value | Tolerance 1 | Tolerance 2 |
|---|---|---|---|---|---|
| Control mechanism for transmission | Fastening screws for control mechanism to transmission | Tightening torque | 8 (6 ftlb.) Nm |
5. Attach securing clasp for wiring harness plug and engage holding tongue.
1. Install ATF filter. Refer to 37 58 55 Replacing ATF filter - as of MY 2005 (All Models) .
2. Install ATF pan. Refer to 37 55 19 Removing and installing ATF pan - as of MY 2005 (All Models) .
3. Fill in ATF. Refer to 37 02 55 Changing ATF - as of MY 2005 (All Models) .
4. Install support plate. Refer to 42 14 19 Removing and installing support plate - as of MY 2005 (All Models) .
5. Lower the vehicle.
Designation Type Number Explanation an insertion aid VW-tool 3381
Scheme 104
1. Raise the vehicle at the prescribed jacking points. Refer to 40 Tightening torques for front axle - as of MY 2005 (All Models) .
2. Remove support plate. Refer to 42 14 19 Removing and installing support plate - as of MY 2005 (All Models) .
3. Drain ATF. Refer to 37 02 55 Changing ATF - as of MY 2005 (All Models) .
4. Remove ATF pan. Refer to 37 55 19 Removing and installing ATF pan - as of MY 2005 (All Models) .
5. Remove ATF filter. Refer to 37 58 55 Replacing ATF filter - as of MY 2005 (All Models) .
6. Remove control mechanism for transmission. > 387719 Control mechanism for transmission .
Scheme 105
| No. | Designation | Qty. | Removal |
|---|---|---|---|
| 1- (Scheme 104) | Control mechanism for transmission | 1 | See > 387719 Control mechanism for transmission |
| 2 | Wire harness | 1 | Remove plug connections from solenoid valves and from transmission input speed sender and disengage wire harness on brackets. |
| 3 | O-ring | 2 | |
| 4 | Screw | 1 | |
| 5 | Transmission input speed sender | 1 | Unscrew fastening screw and remove sender and sleeve. |
| 6 | Spacer sleeve (20 mm) | 1 | |
| 7 | Screw | 1 | |
| 8 | Holder | 1 | |
| 9 | Pressure regulator and O-ring | 1 | |
| 10 | Screw | 4 | |
| 11 | Holder | 2 | |
| 12 | Solenoid valve 1 | 1 | Unscrew guide plate for parking-lock mechanism |
| 13 | Pressure regulator 2 and O-ring | 1 | |
| 14 | Pressure regulator 4 and O-ring | 1 | |
| 15 | Pressure regulator 3 and O-ring | 1 | |
| 16 | Solenoid valve 1 | 1 | |
| 17 | Solenoid valve 1 | 1 | |
| 18 | Screw | 1 | |
| 19 | Transmission speed sender | 1 | Unscrew fastening screw and remove sender and sleeve. |
| 20 | Spacer sleeve (8 mm) | 1 | |
| 21 | Oil pipe | 1 | Lever out oil pipe with a screwdriver. |
| 22 | O-ring | 2 |
1. Install control mechanism for transmission. > 387719 Control mechanism for transmission
2. Install ATF filter. Refer to 37 58 55 Replacing ATF filter - as of MY 2005 (All Models) .
3. Install ATF pan. Refer to 37 55 19 Removing and installing ATF pan - as of MY 2005 (All Models) .
4. Fill in ATF. Refer to 37 02 55 Changing ATF - as of MY 2005 (All Models) .
5. Install support plate. Refer to 42 14 19 Removing and installing support plate - as of MY 2005 (All Models) .
6. Lower the vehicle.
