Engine: Maintenance Porsche Boxster 986 рестайлинг

DRAINING COOLANT

Scheme 262

Scheme 263

Scheme 264

Scheme 265

Scheme 266

Scheme 267

Scheme 268

1. Position the vehicle at the take-up points provided on a lifting platform.
2. Open rear luggage compartment. Protect the trunk floor panel against soiling with a suitable cover.
3. Open tank cap on the expansion tank and remove.
4. Remove the entire underbody cover.
5. Drain cooling system. Remove the drain plug from the engine, drain the coolant into a container and dispose of coolant according to the country-specific legal requirements if no longer required.
6. Pull the radiator supply and return lines off the engine. To do so, undo the hose clamps, carefully pull off the hoses and allow the remaining coolant to run out. Then clean the inside and outside of the hoses, connect the hoses again and tighten the hose clamps. Check whether the hoses are securely seated.
7. Open the heating lines on the vehicle floor. To do so, open the hose clamp, pull off the lines and drain. Then clean the inside and outside of the hoses, connect the hoses again and tighten the hose clamps. Install the hose clamps and check that the lines are seated correctly.
8. Install drain plug on the engine with a new sealing ring and tighten. Tightening torque: 10 to 15 Nm (7.5 to 11 ft.lb).

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

1. Screw lid adapter for coolant expansion tank (K 22) onto the expansion tank.
2. Connect the flexible extension (Fz 100) to the lid.
3. Connect the vacuum pressure gauge of the bleeder tool to the flexible extension. When doing so, ensure that both shutoff valves are closed (positioned 90° to flow direction)
4. Connect the Venturi nozzle onto the vacuum pressure gauge. NOTE: The radiator cleaning amount which is prepared must be approx. 2 liters more than the amount which has to be filled. An anti-freeze content of - 35° C corresponds to a mixture of 50:50 (anti-freeze protection: Water).
5. Place a canister with a sufficient amount of coolant and with an anti-freeze content of - 35°C at rear of vehicle near to the expansion tank.
6. Push the filler hose (5) of the vacuum pressure gauge into the canister until the canister floor; guide the return line (6) of the Venturi nozzle into the open. (Scheme 280) NOTE: A hissing sound after connecting the compressed air supply is usual.
7. Connect compressed air supply.
8. Open both shutoff valves on the vacuum pressure gauge until the transparent filler hose has completely filled with coolant.
9. Close the left shutoff valve (V1) on the vacuum pressure gauge and build up vacuum in the coolant circuit. NOTE: If a vacuum does not build up, there is a leaking valve in the coolant circuit. Deformation of the rubber hose of the cooling system is normal. If the indicator of the pressure gauge is in the green area of the display scale, enough vacuum has been built up. After both shutoff valves on the vacuum pressure gauge have been closed and the compressed air supply has been unplugged, the vacuum must not drop. If the vacuum drops within approx. 30 seconds, there is a leaking point in the coolant circuit.
10. When there is enough vacuum in the cooling system, close the right shutoff valve (V2) and subsequently unplug the compressed air supply.
11. Reopen the left shutoff valve (V1) on the compressed air pressure gauge. The cooling system will now be filled. This procedure will take approx. 5 minutes.
12. When there is no trace of vacuum present or the coolant is no longer suctioned from the canister, open the right shutoff valve (V2).
13. Subsequently remove the complete filling tool (including the lid K 22).
14. If necessary, fill the coolant expansion tank with coolant up to the maximum marking and screw on the cap of the expansion tank.
15. Completely reinstall the underside panel.
16. Conduct a test drive with the vehicle and check the fluid level in the expansion tank after the coolant circuit has cooled again and if necessary fill up to the maximum marking with coolant.

Scheme 279

SPECIAL TOOLS - COOLING SYSTEM LEAK TEST

Note. Perform the leak test only on a cold engine.

Scheme 280

Scheme 281

1. Remove cap and attach tester.
2. Pump the cooling system up to an excess pressure of 1.3 bar. If the pressure decreases, locate the leak and remedy the fault. Check pressure relief valve(s) in the cap. Screw the tester, adapter and cap together.
