Shift Interlock System: Removal & Installation Pontiac Vibe I

Automatic Trans 4 illustrations ~202 words

Removal Procedure

CAUTIONRefer to BATTERY DISCONNECT CAUTION in Cautions and Notices.

Scheme 127

Scheme 127
  1. Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE in Engine Electrical.
  2. Remove the front floor console. Refer to CONSOLE REPLACEMENT - FRONT FLOOR in Instrument Panel, Gages and Console.
  3. Disconnect the electrical connector (1).
  4. Remove the retaining screw, then the Shift Lock Control Module/Shift Lock Solenoid assembly.

Scheme 128

Scheme 128: Installation Procedure
  1. Install the Shift Lock Control Module/Shift Lock Solenoid assembly, then the retaining screw (2).
  2. Connect the electrical connector (1).
  3. Install the front floor console. Refer to CONSOLE REPLACEMENT - FRONT FLOOR in Instrument Panel, Gages and Console.
  4. Connect the negative battery cable.
CAUTIONRefer to BATTERY DISCONNECT CAUTION in Cautions and Notices.

Scheme 129

Scheme 129
  1. Disconnect the negative battery cable. Refer to BATTERY NEGATIVE CABLE DISCONNECT/CONNECT PROCEDURE in Engine Electrical.
  2. Remove the front floor console. Refer to CONSOLE REPLACEMENT - FRONT FLOOR in Instrument Panel, Gages and Console.
  3. Disconnect the electrical connector (1).
  4. Remove the retaining screw, then the Shift Lock Control Module/Shift Lock Solenoid assembly.

Scheme 130

Scheme 130: Installation Procedure
  1. Install the Shift Lock Control Module/Shift Lock Solenoid assembly, then the retaining screw (2).
  2. Connect the electrical connector (1).
  3. Install the front floor console. Refer to CONSOLE REPLACEMENT - FRONT FLOOR in Instrument Panel, Gages and Console.
  4. Connect the negative battery cable.
