Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Steering Column Trim Cover Screws | 2 N.m | 18 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Steering Wheel Secondary/Configurable Control Schematics
Scheme 2
Scheme 2: Secondary/Configurable Control Component Views
| Callout | Component Name |
|---|
| 1 | Horn Switch |
| 2 | Steering Wheel Controls - Right |
| 3 | Steering Wheel Controls - Left |
Scheme 3
Scheme 3: Key Cylinder Lock Solenoid
| Connector Part Information OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
Key Cylinder Lock Solenoid Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | BK | 1450 | |
| B | PU/WH | 1630 | Steering Column Key Cylinder Lock Solenoid Control |
Key Cylinder Lock Solenoid Connector Terminal Identification
