Configurable Customer Control System: Specifications

Configurable Customer Control System: Specifications Pontiac Solstice I

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Steering Wheel Control Switch Screw	2 N.m	18 lb in

Fastener Tightening Specifications

Scheme 1: Steering Wheel Secondary/Configurable Control Schematics

Scheme 2: Secondary/Configurable Control Component Views

Callout	Component Name
1	Hazard Switch
2	Ambient Light Sensor
3	Inflatable Restraint Passenger Airbag On/Off Indicator
4	Fog Lamp Switch (T96)
5	I/P Dimmer Switch
6	Traction Control Switch (if equipped)
7	HVAC Control Module
8	Inflatable Restraint I/P Module
9	Rear Compartment Lid Release Switch
10	Radio/Navigation Unit (UE1/U2K)
11	Park Brake Lever
12	Auxiliary Power Outlet
13	Steering Wheel - Controls - Right
14	Steering Wheel - Controls - Left
15	Inflatable Restraint Steering Wheel Module
16	Instrument Panel Cluster (IPC)

Callouts For (Scheme 2)

Scheme 3: Ignition Lock Cylinder Control Actuator (M82)

Connector Part Information OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Ignition Lock Cylinder Control Actuator Connector Part Information (M82)

Pin	Wire Color	Circuit No.	Function
A	D-GN/WH	1932	Ignition Lock Cylinder Control Actuator Signal
B	BN	4	Accessory Voltage

Ignition Lock Cylinder Control Actuator Connector Terminal Identification (M82)

Scheme 4: Steering Wheel Control Switch - Left

Connector Part Information OEM: 50-57-9407 Service: 88988695 Description: 7-Way F SL Series, Unsealed (BK)
Terminal Part Information Pins: 3-7 Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Steering Wheel Control Switch (Left) Connector Part Information

Pin	Wire Color	Circuit No.	Function
1-2			Not Used
3	BK	1150	Ground
4	PK	1539	Ignition 1 Voltage
5	GY	8	Instrument Panel Lamp Supply Voltage (K34/UK3)
6	GY	1884	Cruise Control Switch Signal
7	D-GN/WH	1358	DIC Switch Signal

Steering Wheel Control Switch (Left) Connector Terminal Identification

Scheme 5: Steering Wheel Control Switch - Right (UK3)

Connector Part Information OEM: 50-57-9404 Service: 88987918 Description: 4-Way F SL Series, Unsealed (BK)
Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Steering Wheel Control Switch (Right) Connector Part Information (UK3)

Pin	Wire Color	Circuit No.	Function
1	D-BU	1796	Steering Column Controls Signal
2	WH/BK	644	10-Volt Reference
3	GY	8	Instrument Panel Lamp Supply Voltage
4	BK	1150	Ground

Steering Wheel Control Switch (Right) Connector Terminal Identification (UK3)
