Configurable Customer Control System: Other Pontiac Solstice I

Memory Modules 1 illustration ~101 words

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Reference Information

Schematic Reference

Steering Wheel Secondary/Configurable Control Schematics

Connector End View Reference

  1. «Entertainment/Communication Connector End Views»(ref-267901-S29700416232007101700000)
  2. «Secondary/Configurable Control Connector End Views»(ref-267960-S11383394182007101700000)

Electrical Information Reference

  1. «Circuit Testing»(ref-267924-S30300380662007101700000)
  2. «Connector Repairs»(ref-267924-S40546396332007101700000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-267924-S30568029692007101700000)
  4. «Wiring Repairs»(ref-267924-S21063363232007101700000)

Repair Procedures

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Steering Wheel Control Switch Assembly Replacement»(ref-267960-S29554765622007101700000)
  2. «Control Module References»(ref-267925-S30181830442007101700000) for Radio replacement, setup, and programming

Scheme 6

Scheme 6: Steering Wheel Control Switch Assembly Replacement
Scheme 6: Steering Wheel Control Switch Assembly Replacement
CalloutComponent Name
NOTE: Refer to Fastener Notice . Preliminary Procedure: Remove the inflatable restraint steering wheel module. Refer to Inflatable Restraint Steering Wheel Module Replacement .
1Screw, Steering Wheel Control Assembly Tighten: 2 N.m (18 lb in)
2Control Assembly, Steering Wheel
NOTE
Refer to Fastener Notice .

Steering Wheel Control Switch Assembly Replacement
