Calibration Criteria
| IMPORTANT | Do not apply the brake pedal during the brake pedal position sensor calibration procedure. Any movement of the brake pedal during this procedure will cause the calibration procedure to fail. If this occurs, the brake pedal position sensor calibration must be repeated. |
Brake pedal position sensor calibration must be performed after the brake pedal position sensor or body control module (BCM) have been serviced. The calibration procedure will set brake pedal position sensor home value. This value is used by the BCM to determine the action of the driver applying the brake system and to provide this information to the vehicle subsystems via the GMLAN communication bus.
Calibration Procedure
- Apply the parking brake.
- Place the transmission in the PARK position for automatic transmission or NEUTRAL for manual transmission.
- Install a scan tool.
- Clear all BCM DTCs before proceeding.
- Turn ON the ignition, with the engine OFF.
- Navigate to the BCM menu.
- Select Module Setup menu item.
- Select BPP Sensor Calibration procedure and follow the directions displayed on the screen.
Scheme 19
Scheme 19: Brake Pedal Position Sensor Replacement
| Callout | Component Name |
|---|
| NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . |
| 1 | Brake Pedal Position Sensor Assembly Tip: Disconnect the electrical connector. |
| 2 | Brake Pedal Position Sensor Bolt Tip: Calibrate the position sensor. Refer to Brake Pedal Position Sensor Calibration . Do not reuse the position sensor or bolt. Always use a new sensor and bolt. Tighten: 2 N.m (18 lb in) |
| NOTE |
|---|
| Refer to Fastener Notice . |
Brake Pedal Position Sensor Replacement
Scheme 20
Scheme 20: Fog Lamp Switch Replacement
| Callout | Component Name |
|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedure: Remove the instrument panel (I/P) center trim panel. Refer to Instrument Cluster Trim Panel Replacement . |
| 1 | Switch Assembly, Fog Lamp |
Fog Lamp Switch Replacement
Scheme 21
Scheme 21: Hazard Warning Switch Replacement
| Callout | Component Name |
|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedure: Remove the instrument panel (I/P) center trim panel. Refer to Instrument Cluster Trim Panel Replacement . |
| 1 | Switch Assembly, Hazard Warning |
Hazard Warning Switch Replacement
Scheme 22
Scheme 22: Instrument Panel Dimmer Switch Replacement
| Callout | Component Name |
|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedure: Remove the instrument panel (I/P) center trim panel. Refer to Instrument Cluster Trim Panel Replacement . |
| 1 | Switch Assembly, Instrument Panel Lamp Dimmer |
Instrument Panel Dimmer Switch Replacement
Scheme 23
Scheme 23: Ambient Light Sensor Replacement
| Callout | Component Name |
|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedure: Remove the instrument panel (I/P) top pad trim panel. Refer to Instrument Panel Trim Pad Replacement . |
| 1 | Ambient Light Control Sensor Assembly |
Ambient Light Sensor Replacement
Scheme 24
Scheme 24: Headlamp Replacement
| Callout | Component Name |
|---|
| NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures Open the hood. Release the connector positive assurance (CPA) connector at the headlamp bulb socket. Disconnect the electrical harness from the left side headlamp prior to removal. |
| 1 | Headlamp Assembly Socket Tip: Disengage the bulb socket from the headlamp assembly by rotating one quarter turn counterclockwise. |
| 2 | Headlamp Screws (Qty: 4) Tip: Hold the lamp assembly to the hood when removing the screws. Tighten: 8 N.m (71 lb in) |
| 3 | Headlamp Assembly Tip: On the left front headlamp assembly, disconnect the electrical harness from the rear of the headlamp composite. |
| NOTE |
|---|
| Refer to Fastener Notice . |
Scheme 25
Scheme 25: Headlamp Bulb Replacement
| Callout | Component Name |
|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures Open the hood. Lift upward on the connector positive assurance (CPA) to release the electrical harness from the bulb socket. Disconnect the electrical connector. |
| 1 | Socket, Headlamp Bulb CAUTION: Refer to Halogen Bulb Caution . Tip: Turn the bulb socket counterclockwise in order to remove. |
| CAUTION |
|---|
| Refer to Halogen Bulb Caution . |
Headlamp Bulb Replacement
