Lighting Systems: Specifications Pontiac Solstice I

Exterior Lights 18 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Fog Lamp Nuts2.5 N.m22 lb in
Headlamp Bolts2 N.m18 lb in
High Mounted Stop Lamp Bolts2 N.m18 lb in
HVAC Control Screws2.5 N.m22 lb in
License Lamp Screws2 N.m18 lb in
Tail Lamp Screws2 N.m18 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics
Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics

Scheme 2

Scheme 2: Fog Lights Schematics
Scheme 2: Fog Lights Schematics

Scheme 3

Scheme 3: Exterior Lights Schematics
Scheme 3: Exterior Lights Schematics

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6: Interior Lights Schematics
Scheme 6: Interior Lights Schematics

Scheme 7

Scheme 7: Interior Lights Dimming Schematics
Scheme 7: Interior Lights Dimming Schematics

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9: Lighting Systems Component Views
Scheme 9: Lighting Systems Component Views
CalloutComponent Name
1Hazard Switch
2Ambient Light Sensor
3Inflatable Restraint Passenger Airbag On/Off Indicator
4Fog Lamp Switch (T96)
5I/P Dimmer Switch
6Traction Control Switch (if equipped)
7HVAC Control Module
8Inflatable Restraint I/P Module
9Rear Compartment Lid Release Switch
10Radio/Navigation Unit (UE1/U2K)
11Park Brake Lever
12Auxiliary Power Outlet
13Steering Wheel - Controls - Right
14Steering Wheel - Controls - Left
15Inflatable Restraint Steering Wheel Module
16Instrument Panel Cluster (IPC)

Scheme 10

Scheme 10
Scheme 10
CalloutComponent Name
1Brake Pedal Position Sensor
2Accelerator Pedal Position (APP) Sensor
3Data Link Connector (DLC)
4Data Link Connector (DLC) Resistor
5Clutch Pedal Position (CPP) Switch
6Clutch Start Switch
7C165
8C166

Scheme 11

Scheme 11
Scheme 11
CalloutComponent Name
1Inflatable Restraint Steering Wheel Module
2Turn Signal/Multifunction Switch C2
3Turn Signal/Multifunction Switch C1
4Inflatable Restraint Steering Wheel Module Coil C3
5Inflatable Restraint Steering Wheel Module Coil C2
6Ignition Switch
7Windshield Wiper/Washer Switch Connector
8Windshield Wiper/Washer Switch

Scheme 12

Scheme 12
Scheme 12
CalloutComponent Name
1Cellular Microphone (UE1)
2Inside Rearview Mirror
3Onstar Button Assembly (UE1)
4Inside Rearview Mirror Lamps
5Antenna
6Cellular and Navigational Antenna (U2K/UE1)
7Remote Control Door Lock Receiver (RCDLR)
8Vehicle Communication Interface Module (VCIM)

Scheme 13

Scheme 13
Scheme 13
CalloutComponent Name
1Headlamp - Left
2Marker Lamp - LF
3Park/Turn Lamp - LF
4Fog Lamp - LF (T96)
5Fog Lamp - RF (T96)
6Park/Turn Lamp - LF
7Marker Lamp - RF
8Headlamp - Right

Scheme 14

Scheme 14
Scheme 14
CalloutComponent Name
1Defogger Grid C2
2Center High Mounted Stop Lamp (CHMSL)
3Tail/Stop and Turn Signal Lamp - Right
4Backup Lamp - Right
5License Lamp
6Backup Lamp - Left
7Tail/Stop and Turn Signal Lamp - Left
8Defogger Grid C1

Scheme 15

Scheme 15
Scheme 15
CalloutComponent Name
1Digital Radio Receiver (U2K)
2Rear Compartment Lamp
3Rear Compartment Lid

Scheme 16

Scheme 16
Scheme 16
CalloutComponent Name
1Throttle Body
2Camshaft Position (CMP) Sensor 1 (Intake)
3Manual Transmission
4Vehicle Speed Sensor (VSS)
5Backup Lamp Switch
6Crankshaft Position (CKP) Sensor
7Engine Oil Pressure (EOP) Sensor
8Starter
9Knock Sensor Pigtail Connector
10Generator
11Fuel Injector Rail
12Manifold Absolute Pressure (MAP) Sensor

Scheme 17

Scheme 17: Ambient Light Sensor
Scheme 17: Ambient Light Sensor
Connector Part Information OEM: 12047662 Service: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-2A (GY)

Ambient Light Sensor Connector Part Information

PinWire ColorCircuit No.Function
AL-GN/BK1137DRL Ambient Light Sensor Signal
BYE/BK1138DRL Ambient Light Sensor Low Reference

Ambient Light Sensor Connector Terminal Identification

Scheme 18

Scheme 18: Backup Lamp - Left
Scheme 18: Backup Lamp - Left
Connector Part Information OEM: 15435155 Service: See Catalog Description: 3-Way F (NA)
Terminal Part Information Pins: A Terminal/Tray:7114-4102-08/9 Core/Insulation Crimp:0.35 E/1 Release Tool/Test Probe:12094430/J-35616-3 (GY) Pins: G Terminal/Tray: Service w/Pigtail Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A

Backup Lamp - Left Connector Part Information

PinWire ColorCircuit No.Function
AL-GN24Backup Lamp Supply Voltage
BNot Used
GBK750Ground

Backup Lamp - Left Connector Terminal Identification
